2009 Ford Flex

United StatesGasolineFWDCrossover

Photos

Specifications

Vehicle Details

Year
2009
Make
Ford
Model
Flex
Body Style
Crossover
Generation
1st Generation (D471)
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
3.5 V6 iVCT Automatic
Engine Configuration
V
Power (hp)
266 hp
Power (kW)
196 kW
Torque
366 Nm (270 lb-ft)
Displacement
3,496 cc

Dimensions

Length
5,130 mm (202.0 in)
Width
2,032 mm (80.0 in)
Height
1,727 mm (68.0 in)
Wheelbase
2,995 mm (117.9 in)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Bore
92.5 mm (3.6 in)
Stroke
86.7 mm (3.4 in)
Compression Ratio
10.3 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Fuel

Emission
Emission Standard
Euro 4

Brakes

Front Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Dimensions & Weight

Exterior

Track, Front
1,661 mm (65.4 in)
Track, Rear
1,661 mm (65.4 in)
Turning Circle
12.4 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
1,062 mm (41.8 in)
Head Room, Rear
1,029 mm (40.5 in)
Head Room, Third Row
983 mm (38.7 in)
Leg Room, Front
1,082 mm (42.6 in)
Leg Room, Rear
1,125 mm (44.3 in)
Leg Room, Third Row
846 mm (33.3 in)
Hip Room, Front
1,410 mm (55.5 in)
Hip Room, Rear
1,410 mm (55.5 in)
Hip Room, Third Row
1,044 mm (41.1 in)
Shoulder Room, Front
1,483 mm (58.4 in)
Shoulder Room, Rear
1,476 mm (58.1 in)
Shoulder Room, Third Row
1,290 mm (50.8 in)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Platform
Ford Motor Company
D3 Platform (D4)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Optional
Other Equipment
Normal Roof
Yes
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
70.6
Fastening Type
Lug Nuts
Tightening Torque
135 Nm
Rim Material
Aluminium
Rim Type
Disc Wheel

Interior

Equipment

Connectivity
Radio
  • AM
  • FM
Media Format
CD
Climate Control
Outside Temperature Indicator
Yes
Interior Storage › Storage Compartments
Glove Compartment
Yes
Door
  • Driver Side
  • Passenger Side

Seats

Front Seats › Adjustments, Driver
Seat Depth
Optional
Seat Height
Optional
Backrest Angle
Optional
Front Seats › Adjustments, Passenger
Seat Depth
Optional
Backrest Angle
Optional
Front Seats
Heated Seats
Optional

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
565 litres
Volume, Back Seat Collapsed
2,355 litres

Safety & Security

Safety Testing

General
Not Tested by Euro NCAP
Yes

Other

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment
Car.info Classification
Large SUV

Awards

Canadian
Utility Vehicle of the Year
2009
