2010 Kia Venga

South KoreaGasolineFWDMinivan

Photos

Specifications

Vehicle Details

Year
2010
Make
Kia
Model
Venga
Body Style
Minivan
Generation
YN
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.4 CVVT Manual
Engine Configuration
Inline
Power (hp)
90 hp
Power (kW)
66 kW
Torque
137 Nm (101 lb-ft)
Top speed
168 km/h (104 mph)
0–60 mph
12.2 seconds (estimated)
0–100 km/h
12.8 seconds
Displacement
1,396 cc

Dimensions

Length
4,068 mm (160.2 in)
Width
1,765 mm (69.5 in)
Height
1,600 mm (63.0 in)
Wheelbase
2,615 mm (103.0 in)
Curb weight
1,180 kg (2,601 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,300 rpm
Rev. at Max Torque
4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
3.3 litres
Engine Configuration
Bore
77 mm (3.0 in)
Stroke
75 mm (3.0 in)
Compression Ratio
10.5 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Air Filter
40,000 km / 2 years
Spark Plug
40,000 km / 2 years
Brake Fluid
40,000 km / 2 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
210,000 km / 10 years
Interior Filter
20,000 km / 1 years

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
280 mm (11.0 in)
Cooling
Ventilated
Rear Brakes
Diameter
258 mm (10.2 in)

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 5
Fuel Consumption NEDC
City
7.2 litres / 100 km
Highway
5.3 litres / 100 km
Combined
6 litres / 100 km
Emission NEDC
CO₂, Combined
140 g/km

Dimensions & Weight

Exterior

Track, Front
1,550 mm (61.0 in)
Track, Rear
1,550 mm (61.0 in)
Turning Circle
10.4 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
1,020 mm (40.2 in)
Head Room, Rear
980 mm (38.6 in)
Leg Room, Front
1,080 mm (42.5 in)
Leg Room, Rear
901 mm (35.5 in)
Shoulder Room, Front
1,388 mm (54.6 in)
Shoulder Room, Rear
1,367 mm (53.8 in)

Weight

Gross Weight
1,710 kg (3,770 lb)
Max Trailer Load, braked 12%
1,300 kg (2,866 lb)
Max Trailer Load, unbraked
550 kg (1,213 lb)
Cargo Capacity
457 kg (1,008 lb)
Max Roof Load
70 kg (154 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Hyundai-Kia Platforms
Small Automobile Platform (PB)

Equipment

Side Mirrors
Mirror Type
Conventional
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
Front
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Spoiler
Fixed
Antenna
Whip
Electric
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen

Colour

Finish
Solid

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
88 - 107 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Optional
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
CD
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Card Holder
Yes
Interior Storage › Storage Compartments › Glove Compartment
Cooled
Optional
Light
Optional
Interior Storage
Cup Holders
Yes
Lights
Read Light
Front
Other Equipment
Make-up Mirror
Passenger Side
Clock
Digital
12V Outlet
  • Front
  • Trunk
Carpets
Yes
Ashtray
Yes
Cigarette Lighter
Yes

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Release Button
Yes
Cover
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
315 litres
Volume, Back Seat Collapsed
1,255 litres

Design

Interior Decor Material
Plastic
Transmission Knob Material
Plastic

Seats

Colour & Material
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Heated Seats
Optional
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Split Fold Ratio
60/40

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional
Cruise Control
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Dynamic Steering Response (DSR)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Manual
Active Headrests
Yes
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2010
Adult Occupant
79 %
Child Occupant
66 %
Vulnerable Road Users
64 %
Safety Assist
71 %
Overall
4/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
7 years
12V Battery
2 years
Paintwork
150,000 km / 5 years
Rust Damage
150,000 km / 7 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
150,000 km / 7 years

Identification

VIN Location
Left Side Casing of Window
Yes
Right Side Casing of Window
Yes
Passenger Seat
in Front of

Car Classification

British Classification
Mini MPV
European Segment
M-Segment
Car.info Classification
Small MPV

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H1
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
Read Light
SV8.5 (C5W)
Trunk
SV8.5 (C5W)
License Plate Light
W2.1×9.5d (W5W)
