2010 Toyota RAV4

Japan Gasoline FWD SUV

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2010
Make: Toyota
Model: RAV4
Body Style: SUV

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2010
Make: Toyota
Model: RAV4
Body Style: SUV

Generation

XA30 2nd Facelift

Seats

5

Doors

5

Fuel

Gasoline

Drivetrain

FWD

Transmission

Manual, 6-speed

Powertrain

Engine Name: 2.0 VVT-i Manual
Engine Configuration: Inline
Power (hp): 158 hp
Power (kW): 116 kW
Torque: 198 Nm (146 lb-ft)
Top speed: 185 km/h (115 mph)
0–60 mph: 9.7 seconds (estimated)
0–100 km/h: 10.2 seconds
Displacement

Dimensions

Length: 4,620 mm (181.9 in)
Width: 1,815 mm (71.5 in)
Height: 1,745 mm (68.7 in)
Wheelbase: 2,660 mm (104.7 in)
Curb weight: 1,400 kg (3,086 lb)

Engine & Performance

Engine

Engine Specification

Rev. at Max Torque: 4,000 rpm

Engine Fluids

Synthetic Oil (viscosity): 5W-30
10W-30
Semi-synthetic Oil (viscosity): 5W-30
10W-30
Engine Oil, Volume: 4.2 litres

Engine Configuration

Similar suvs

Suggested vehicles

View all

2010 Honda CR-V

1,987 cc

Bore: 80.5 mm (3.2 in)
Stroke: 97.6 mm (3.8 in)
Compression Ratio: 10 :1
Engine Configuration: Inline
Synchronization: Timing Chain
Engine Placement: Front
Type of Combustion Engine: Piston
Fuel System: Electronic Fuel Injection

Service Intervals

Air Filter: 60,000 km / 4 years
Spark Plug: 90,000 km (55,923 mi)
Brake Fluid: 30,000 km / 2 years
Oil Change & Engine Filter: 15,000 km / 1 years
Engine Coolant: 90,000 km (55,923 mi)
Interior Filter: 30,000 km (18,641 mi)

Brakes

Front Brakes: Disc Brakes
Rear Brakes: Disc Brakes

Front Brakes

Cooling: Ventilated

Fuel

General

Tank Volume: 60 litres

Emission

Emission Standard: Euro 5

Fuel Consumption NEDC

City: 9.4 litres / 100 km
Highway: 6.2 litres / 100 km
Combined: 7.4 litres / 100 km

Emission NEDC

Dimensions & Weight

Exterior

Track, Front: 1,560 mm (61.4 in)
Track, Rear: 1,560 mm (61.4 in)
Turning Circle: 10.2 m
Ground Clearance: 190 mm (7.5 in)

Interior

Exterior

Chassis & Body

Chassis

Chassis: SUV
Pillars: A-D
Chassis Construction: Unibody

Doors

Front Doors: Conventional
Rear Doors: Conventional

Platform

Interior

Equipment

Instrument Cluster

Trip Computer: Yes
Tachometer: Analogue

Instrument Cluster › Trip Computer

Display: Yes

Climate Control

Air Condition: Yes

Features

Comfort Features

Keyless Entry: Optional
Keyless Start: Optional
Cruise Control: Optional
Cameras: Optional

Cameras

Rear: Optional

Safety & Security

Seat Belt

Type of Belt

Three-Point-Belt: Centre Rear Seat

Rear Centre Seat Belt: Yes
Seat Belt Colour: Black

Feature

Driver

Passenger

Rear

Other

Warranty

Manufacturer: 100,000 km / 3 years
Body Protection: 3 years
Paintwork: 3 years
Rust Damage: 12 years
Roadside Assistance: Yes

Roadside Assistance

Roadside Assistance

CO₂, Combined

174 g/km

Head Room, Front

1,037 mm (40.8 in)

Head Room, Rear

1,008 mm (39.7 in)

Leg Room, Front

1,062 mm (41.8 in)

Leg Room, Rear

973 mm (38.3 in)

Hip Room, Front

1,367 mm (53.8 in)

Hip Room, Rear

1,331 mm (52.4 in)

Shoulder Room, Front

1,450 mm (57.1 in)

Shoulder Room, Rear

1,405 mm (55.3 in)

Weight

Gross Weight: 2,070 kg (4,564 lb)
Max Trailer Load, braked 12%: 2,000 kg (4,409 lb)
Max Trailer Load, unbraked: 750 kg (1,653 lb)
Cargo Capacity: 670 kg (1,477 lb)
Max Roof Load: 100 kg (220 lb)
Max Towbar Download: 80 kg (176 lb)

Toyota Platform: MC Platform (New MC)

Equipment

Side Mirrors

Mirror Type: Conventional
Adjustments: Electrical
Turning Signal: Yes
House Colour: Same as Car

Windscreen Wipers

Number of Wiper Speeds: 2
Rear Wiper: Yes

Windows

Lights

Main Beam: Halogen
Low Beam: Halogen
Fog Lights: Yes

Fog Lights

Front: Yes
Main Beam Assist: Optional

Rims & Tires

Number of Bolts: 5 pcs
Bolt Distance: 114.3
Nut/Bolt Dimensions: M12x1.5
Central Bore (CB), front: 60.1
Fastening Type: Lug Nuts
Tightening Torque: 103 Nm
Rim Material: Steel
Rim Type: Disc Wheel

Outside Temperature Indicator

Yes

Connectivity

Radio: AM
FM
Media Format: CD
MP3
Bluetooth: Optional

Connectivity › Media Inputs

AUX: Yes
USB: Optional

Connectivity › Media Inputs › USB

USB-A: Optional

Displays

Center Display: 6.1"

Displays › Center Display

Touchscreen: Optional

Speakers

Total Number of Speakers: 6 pcs

Interior Storage › Storage Compartments

Glove Compartment: Lockable
Back Pocket: Yes

Interior Storage › Storage Compartments › Glove Compartment

Cooled: Optional

Interior Storage

Cup Holders: Yes

Interior Storage › Cup Holders

Front: 2
Rear: 2

Lights

Read Light: Front
Guide Light: Yes

Other Equipment

Make-up Mirror: Driver Side
Passenger Side
12V Outlet: Front
Ashtray: Yes
Cigarette Lighter: Yes

Other Equipment › Make-up Mirror

Make-up Light: Driver
Passenger

Steering Wheel

Multifunction Steering Wheel: Optional
Adjustments: Tilt
Telescope

Trunk

Rear Trunk: Yes
Second Trunk Compartment: Yes
Light: Yes

Rear Trunk

Volume: 586 litres
Volume, Back Seat Collapsed: 1,752 litres
Depth: 800 mm (31.5 in)
Width: 1,335 mm (52.6 in)

Seats

Front Seats › Adjustments, Driver

Seat Height: Yes
Backrest Angle: Yes
Headrest, Height: Yes

Front Seats › Adjustments, Passenger

Backrest Angle: Yes
Headrest, Height: Yes

Front Seats

Power Seat, Driver

Other Features

GPS: Optional

Seat Belt Reminder

DriverYes

PassengerYes

Rear-

Belt Pretensioner

DriverYes

PassengerYes

Rear-

Assist Systems

Electronic Stability Control (ESC): Yes
Hill Start Assist (HSA): Yes
Hill Descent Control (HDC): Optional
Lane Departure Warning (LDW): Optional

Brake Systems

Anti-lock Braking System (ABS): Yes
Traction Control System (TCS): Yes
Electronic Brakeforce Distribution (EBD): Yes
Electronic Brake Assist (BA/EBA): Yes

Sensors

Parking Sensors: Optional
Rain Sensors: Optional

Parking Sensors

Front: Optional
Rear: Optional

Other Features

Immobiliser: Yes
Central Locking: Yes

Safety Testing

General

Test Year: 2006
Adult Occupant: 4/5 stars
Child Occupant: 4/5 stars
Pedestrian: 3/4 stars

Frontal Crash

Front Driver Side: 4/5 stars
Front Passenger Side: 2/5 stars

Side Crash

Airbags

Feature

Driver

Passenger

Rear

Frontal Airbag

DriverYes

PassengerYes

Rear-

Side Chest Airbag

Driver

Child Protection

Isofix: Passenger: -
Rear: Yes

3 years

Identification

VIN Location

Left Side Casing of Window: Yes
Pillar: B-Pillar, Left
Passenger Seat: in Front of

Car Classification

American Classification: Compact SUV
British Classification: Compact SUV
Australian Classification: Medium SUV
European Segment: J-Segment
Car.info Classification: Medium SUV

Spare Parts BETA

Bulb Types

Low Beam: H11
Main Beam: HB3
Fog Light, Front: H11
Fog Light, Rear: BA15s (P21W)
Positioning-/Parking Lights, Front: W2.1×9.5d (W5W)
Reversing Light: W2.1×9.5d (W16W)
Turn Indicators, Front: WX3×16d (WY21W)
Turn Indicators, Rear

RAV4

8.9

€67,000

MSRP · EUR

Body

Window Lifts, Front

Powered

Window Lifts, Rear

Powered

Heated Windows

Rear

Heat-Insulating Windows

Front
First Row
Second Row
Rear

Tinted Windows

Optional

Windows › Tinted Windows

Second Row: Optional
Rear Window: Optional

Other Equipment

Sunroof: Optional
Tow Hook: Front
Rear
Roof Railing: Optional

Optional

Heated Seats

Optional

Second Seat Row

Collapsible: Yes
Adjustments: Backrest Angle
Number of Seats: 3
Type of Seat: Adult
Height Adjustment: Yes

Second Seat Row › Collapsible

Split Fold Ratio: 60/40

Third/Fourth Seat Row

Third Seat Row: Optional

Side Crash, Driver

5/5 stars

Side Crash, Passenger

3/5 stars

Front Seat Rating

5/5 stars

Combined Rear Seat Rating

3/5 stars

Side Barrier Rating

4/5 stars

Overall Side Pole Star Rating

2/5 stars

Rollover

Rollover Resistance: 17.4 %
Overall Safety Rating: 3/5 stars
Overall Frontal Rating: 3/5 stars
Overall Side Rating: 4/5 stars
Rollver: 4/5 stars

Yes

PassengerYes

Rear-

Knee Airbag

DriverYes

Passenger-

Rear-

Curtain Airbag

DriverYes

PassengerYes

RearYes

WX3×16d (WY21W)

License Plate Light

W2.1×9.5d (W5W)
