2011 Chrysler Voyager Grand Voyager

United StatesDieselFWDMinivan

Photos

Specifications

Vehicle Details

Year
2011
Make
Chrysler
Model
Voyager
Variant
Grand Voyager
Body Style
Minivan
Generation
RT Facelift
Seats
7
Doors
4
Fuel
Diesel
Drivetrain
FWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
Grand Voyager 2.8 CRD Automatic
Engine Configuration
Inline
Power (hp)
163 hp
Power (kW)
120 kW
Torque
360 Nm (266 lb-ft)
Top speed
185 km/h (115 mph)
0–60 mph
12.2 seconds (estimated)
0–100 km/h
12.8 seconds
Displacement
2,776 cc

Dimensions

Length
5,143 mm (202.5 in)
Width
1,954 mm (76.9 in)
Height
1,750 mm (68.9 in)
Wheelbase
3,078 mm (121.2 in)
Curb weight
2,100 kg (4,630 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
3,800 rpm
Rev. at Max Torque
1,600 rpm
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
100 mm (3.9 in)
Compression Ratio
17.5 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Belt
Engine Placement
Front
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
302 mm (11.9 in)
Width
28 mm (1.1 in)
Cooling
Ventilated
Rear Brakes
Diameter
328 mm (12.9 in)
Width
12 mm (0.5 in)
Cooling
Solid

Fuel

General
Tank Volume
75 litres
Fuel Consumption NEDC
City
11.8 litres / 100 km
Highway
7.1 litres / 100 km
Combined
8.8 litres / 100 km
Emission NEDC
CO₂, Combined
233 g/km

Dimensions & Weight

Exterior

Track, Front
1,651 mm (65.0 in)
Track, Rear
1,645 mm (64.8 in)
Turning Circle
11.9 m
Ground Clearance
140 mm (5.5 in)

Interior

Head Room, Front
1,011 mm (39.8 in)
Head Room, Rear
998 mm (39.3 in)
Head Room, Third Row
963 mm (37.9 in)
Leg Room, Front
1,034 mm (40.7 in)
Leg Room, Rear
927 mm (36.5 in)
Leg Room, Third Row
831 mm (32.7 in)
Hip Room, Front
1,483 mm (58.4 in)
Hip Room, Rear
1,651 mm (65.0 in)
Shoulder Room, Front
1,618 mm (63.7 in)
Shoulder Room, Rear
1,628 mm (64.1 in)
Shoulder Room, Third Row
1,575 mm (62.0 in)

Weight

Gross Weight
2,775 kg (6,118 lb)
Max Trailer Load, braked 12%
1,600 kg (3,527 lb)
Max Trailer Load, unbraked
450 kg (992 lb)
Cargo Capacity
675 kg (1,488 lb)
Max Roof Load
68 kg (150 lb)
Max Towbar Download
80 kg (176 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV

Equipment

Side Mirrors
Folding
Electrical
Heated
Yes
Turning Signal
Optional
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Colour
Silver

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Tightening Torque
135 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Connectivity
Radio
Yes
Media Format
  • CD
  • MP3
  • WMA
Connectivity › Media Format
DVD
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional

Steering Wheel

Multifunction Steering Wheel
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
638 litres
Volume, Back Seat Collapsed
3,296 litres

Seats

Colour & Material
Upholstery
Textile
Third/Fourth Seat Row
Third Seat Row
Yes

Features

Comfort Features

Keyless Entry
Yes
Keyless Entry
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Rain Sensors
Optional

Other Features

Anti-theft Alarm
Yes

Safety Testing

General
Test Year
2007
Adult Occupant
1/5 stars
Child Occupant
4/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Airbag cut-off Switch

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Passenger Seat
Door

Car Classification

American Classification
Minivan
British Classification
Large MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Large MPV
