2011 Honda Fit Shuttle

JapanGasolineFWDWagon

Photos

Specifications

Vehicle Details

Year
2011
Make
Honda
Model
Fit
Variant
Shuttle
Body Style
Wagon
Generation
1st Generation
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic (Continuously variable)

Powertrain

Engine Name
1.5 i-VTEC CVT
Engine Configuration
Inline
Power (hp)
120 hp
Power (kW)
88 kW
Torque
145 Nm (107 lb-ft)
Displacement
1,496 cc

Dimensions

Length
4,410 mm (173.6 in)
Width
1,695 mm (66.7 in)
Height
1,540 mm (60.6 in)
Wheelbase
2,500 mm (98.4 in)
Curb weight
1,150 kg (2,535 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,600 rpm
Rev. at Max Torque
4,800 rpm
Engine Configuration
Bore
73 mm (2.9 in)
Stroke
89.4 mm (3.5 in)
Compression Ratio
10.4 :1
Engine Configuration
Inline
Synchronization
Timing Chain

Transmission & Drivetrain

Transmission
Automatic (Continuously variable)

Fuel

General
Tank Volume
42 litres
WLTP Consumption
Combined (l/100km)
5.4 litres / 100 km
Emission WLTP
CO
1.15 mg/km
NMHC
0.01 mg/km
NOx
0.01 mg/km
Emission NEDC
CO₂, Combined
124.8 g/km

Dimensions & Weight

Exterior

Track, Front
1,480 mm (58.3 in)
Track, Rear
1,465 mm (57.7 in)
Turning Circle
9.8 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
990 mm (39.0 in)
Head Room, Rear
970 mm (38.2 in)
Knee Room, Front
500 mm (19.7 in)
Knee Room, Rear
455 mm (17.9 in)
Hip Room, Rear
1,260 mm (49.6 in)
Shoulder Room, Rear
1,415 mm (55.7 in)

Weight

Max Roof Load
75 kg (165 lb)
Max Towbar Download
45 kg (99 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon

Interior

Trunk

Rear Trunk
Yes
