2012 Hyundai Veloster

South KoreaGasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2012
Make
Hyundai
Model
Veloster
Body Style
Hatchback
Generation
FS
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 6-speed

Powertrain

Engine Name
1.6 GDI blue Manual
Engine Configuration
Inline
Power (hp)
140 hp
Power (kW)
103 kW
Torque
167 Nm (123 lb-ft)
Top speed
201 km/h (125 mph)
0–60 mph
9.2 seconds (estimated)
0–100 km/h
9.7 seconds
Displacement
1,591 cc

Dimensions

Length
4,219 mm (166.1 in)
Width
1,791 mm (70.5 in)
Height
1,400 mm (55.1 in)
Wheelbase
2,649 mm (104.3 in)
Curb weight
1,260 kg (2,778 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,300 rpm
Rev. at Max Torque
4,850 rpm
Engine Configuration
Bore
77 mm (3.0 in)
Stroke
85.4 mm (3.4 in)
Compression Ratio
11 :1
Engine Configuration
Inline
Service Intervals
Air Filter
60,000 km / 2 years
Spark Plug
160,000 km / 10 years
Oil Change & Engine Filter
30,000 km / 1 years
Engine Coolant
30,000 km / 2 years
Interior Filter
30,000 km / 2 years

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 5
Fuel Consumption NEDC
Combined
5.9 litres / 100 km
Emission NEDC
CO₂, Combined
137 g/km

Dimensions & Weight

Exterior

Track, Front
1,550 mm (61.0 in)
Track, Rear
1,570 mm (61.8 in)
Turning Circle
10.6 m
Ground Clearance
143 mm (5.6 in)

Interior

Head Room, Front
945 mm (37.2 in)
Head Room, Rear
896 mm (35.3 in)
Leg Room, Front
1,114 mm (43.9 in)
Leg Room, Rear
805 mm (31.7 in)
Hip Room, Front
1,351 mm (53.2 in)
Hip Room, Rear
1,337 mm (52.6 in)
Shoulder Room, Front
1,412 mm (55.6 in)
Shoulder Room, Rear
1,371 mm (54.0 in)

Weight

Gross Weight
1,700 kg (3,748 lb)
Cargo Capacity
440 kg (970 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Platform
Hyundai-Kia Platforms
Small Automobile Platform (PB)

Equipment

Side Mirrors
Turning Signal
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Electric
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
88 - 107 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
Yes
Media Format
  • CD
  • MP3
  • WMA
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional

Steering Wheel

Multifunction Steering Wheel
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
320 litres
Volume, Back Seat Collapsed
1,015 litres

Seats

Front Seats
Heated Seats
Optional
Second Seat Row
Collapsible
Yes

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional
Cruise Control
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2011
Adult Occupant
96 %
Child Occupant
89 %
Vulnerable Road Users
49 %
Safety Assist
71 %
Overall
5/5 stars
Test Year
2013
Overall Score
35.47
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
15.47
Side Impact
16
Pole
2
Whiplash Protection (Assessment)
Good
Pedestrian
Protection (Assessment)
Marginal
Safety Assist
Seat Belt Reminders
2
Frontal Crash
Front Driver Side
4/5 stars
Front Passenger Side
5/5 stars
Side Crash
Side Crash, Driver
5/5 stars
Side Crash, Passenger
5/5 stars
Front Seat Rating
5/5 stars
Combined Rear Seat Rating
5/5 stars
Side Barrier Rating
5/5 stars
Overall Side Pole Star Rating
5/5 stars
Rollover
Rollover Resistance
10.5 %
Overall Safety Rating
5/5 stars
Overall Frontal Rating
4/5 stars
Overall Side Rating
5/5 stars
Rollver
4/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Seat Belt

Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
  • B-Pillar, Left
  • B-Pillar, Right
Passenger Seat
in Front of

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H7
Fog Light, Front
H27W/2
Fog Light, Rear
BA15s (P21W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
Read Light
SV8.5 (C5W)
License Plate Light
W2.1×9.5d (W5W)
