2012 Toyota iQ GRMN

JapanGasoline2WDHatchback

Photos

Specifications

Vehicle Details

Year
2012
Make
Toyota
Model
iQ
Variant
GRMN
Body Style
Hatchback
Generation
AJ10
Seats
4
Doors
3
Fuel
Gasoline
Drivetrain
2WD
Transmission
Manual, 6-speed

Powertrain

Engine Name
GRMN Manual
Power (hp)
122 hp
Power (kW)
90 kW
Displacement
1,329 cc

Dimensions

Length
2,985 mm (117.5 in)
Width
1,680 mm (66.1 in)
Height
1,500 mm (59.1 in)
Wheelbase
2,000 mm (78.7 in)

Engine & Performance

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Dimensions & Weight

Exterior

Track, Front
1,480 mm (58.3 in)
Track, Rear
1,460 mm (57.5 in)
Turning Circle
7.8 m
Ground Clearance
135 mm (5.3 in)

Interior

Head Room, Front
970 mm (38.2 in)

Weight

Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Number of Wiper Speeds
2
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Tinted Windows
  • Second Row
  • Rear Window
Other Equipment
Normal Roof
Yes
Antenna
Optional
Number of Exhaust Pipes
1

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen

Colour

Colour
White

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
54.1
Fastening Type
Lug Nuts
Tightening Torque
103 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
4 pcs
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
Media Format
  • CD
  • MP3
  • WMA
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes

Steering Wheel

Multifunction Steering Wheel
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
232 litres
Volume, Back Seat Collapsed
395 litres
Width
935 mm (36.8 in)

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Second Seat Row
Collapsible
Yes

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Two-Point-Belt (Shoulder)
Yes

Assist Systems

Electronic Stability Control (ESC)
Yes
Speed Assist
No

Brake Systems

Autonomous Emergency Brake System (AEB)
No
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
No
Reverse
No
Pedestrian
No
Cyclist
No
City
No
Inter-urban
No

Sensors

Parking Sensors
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Active Bonnet
No
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2009
Adult Occupant
91 %
Child Occupant
71 %
Vulnerable Road Users
54 %
Safety Assist
86 %
Overall
5/5 stars
Adult Occupant
Total Points
32.8 /38
Frontal Impact
15.5 /16
Lateral Impact
14.6 /16
Rear Impact
2.7 /4
Child Occupant
Total Points
34.8 /49
Safety Features
5 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Pedestrian
  • 11.8
  • 1.7
  • 6

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Identification

VIN Location
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
City Car
Australian Classification
Microcar
European Segment
A-Segment
Car.info Classification
Mini Car

Spare Parts BETA

Bulb Types
Low Beam
HIR2
Main Beam
HIR2
Fog Light, Front
H11
Fog Light, Rear
W3×16d (W21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
W3×16q (W21/5W)
Reversing Light
W3×16d (W21W)
Turn Indicators, Front
WX3×16d (WY21W)
Turn Indicators, Rear
WX3×16d (WY21W)
License Plate Light
W2.1×9.5d (W5W)

Awards

Car of the Year Japan
2009 - 2008
