2013 Audi A1

GermanyGasolineFWDHatchback

Specifications

Vehicle Details

Year
2013
Make
Audi
Model
A1
Body Style
Hatchback
Generation
8X
Seats
5
Doors
3
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 7-speed

Powertrain

Engine Name
1.4 TFSI COD
Engine Configuration
Inline
Power (hp)
140 hp
Power (kW)
103 kW
Torque
250 Nm (184 lb-ft)
Top speed
212 km/h (132 mph)
0–60 mph
7.5 seconds (estimated)
0–100 km/h
7.9 seconds
Displacement
1,390 cc

Dimensions

Length
3,954 mm (155.7 in)
Width
1,740 mm (68.5 in)
Height
1,416 mm (55.7 in)
Wheelbase
2,469 mm (97.2 in)
Curb weight
1,185 kg (2,612 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,000 rpm
Rev. at Max Torque
1,500 - 3,500 rpm
Engine Configuration
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 7-speed

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Steel
Front Brakes
Diameter
256 - 312 mm (10.1 - 12.3 in)
Cooling
Ventilated
Rear Brakes
Diameter
230 - 232 mm (9.1 - 9.1 in)
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Fuel

General
Tank Volume
45 litres
Lockable Fuel Cap
Yes
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 5
Emission Class
B
Fuel Consumption NEDC
City
5.7 – 5.8 litres / 100 km
Highway
4.1 litres / 100 km
Combined
4.7 litres / 100 km
Emission NEDC
CO₂, Combined
109 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
1,906 mm (75.0 in)
Track, Front
1,477 mm (58.1 in)
Track, Rear
1,471 mm (57.9 in)
Overhang, Front
808 mm (31.8 in)
Overhang, Rear
677 mm (26.7 in)
Turning Circle
10.6 m
Ground Clearance
121 - 122 mm (4.8 - 4.8 in)

Interior

Head Room, Front
1,014 mm (39.9 in)
Head Room, Rear
925 - 926 mm (36.4 - 36.5 in)
Hip Room, Front
1,404 mm (55.3 in)
Hip Room, Rear
1,347 mm (53.0 in)
Shoulder Room, Front
1,335 mm (52.6 in)
Shoulder Room, Rear
1,266 mm (49.8 in)

Weight

Gross Weight
1560 – 1570 kg (3,439 – 3,461 lb)
Max Roof Load
75 kg (165 lb)
Max Towbar Download
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Platform
Volkswagen Group
A05

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Manual
Windscreen Wipers
Intermittent Control
Yes
Rear Wiper
Yes
Windscreen Wipers: Connector type, Front
Slim Push Button
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Front
Laminated
Side
Tempered
Rear
Tempered
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Spoiler
Fixed
Antenna
Whip

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Optional
Fog Lights
Rear
Yes
Special Features
Headlight Range Adjustment
Manual

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
5 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
57.1
Fastening Type
Lug Bolts
Anti-Theft Locking Lug Nuts/Bolts
Yes
Tightening Torque
125 Nm
Rim Material
Alloy
Rim Type
Disc Wheel
Tire Pressure Monitoring System (TPMS)
Indirect
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Oil Temperature
Digital
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
  • MP3
  • WMA
Connectivity › Radio
DAB
Optional
Internet Radio
Optional
Connectivity › Media Format
CD
Yes
DVD
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Optional
Coin Holder
Optional
Card Holder
Yes
Under Seats
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Guide Light
Entry Guard
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Make-up Mirror
Make-up Light
Optional
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Colour
Black
Steering Ratio
14.8 :1
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Cover
Foldable
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
270 litres
Volume, Back Seat Collapsed
920 litres
Depth
633 mm (24.9 in)
Depth, Back Seat Collapsed
1,330 mm (52.4 in)
Width
921 mm (36.3 in)
Opening Width
922 mm (36.3 in)
Sill Height
663 mm (26.1 in)

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Comfort Features

Cruise Control
Optional
Speed Limiter
Optional
Cameras
Optional
Cruise Control
Adaptive Cruise Control
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional
Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Yes
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Yes
First Aid Kit
Yes
Trunk Modules
Optional
Bicycle Holder
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2010
Adult Occupant
90 %
Child Occupant
79 %
Vulnerable Road Users
49 %
Safety Assist
86 %
Overall
5/5 stars
Test Year
2011
Overall Score
32.75
ANCAP Safety Rating
5
Adult Occupant
Total Points
32.2 /38
Frontal Impact
14.9 /16
Lateral Impact
14.4 /16
Rear Impact
2.9 /4
Frontal Offset
14.9
Side Impact
13.85
Pole
2
Whiplash Protection (Assessment)
Good
Child Occupant
Total Points
38.9 /49
Safety Features
3 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Total Points
17.7 /49
Pedestrian
  • 11.6
  • 0.2
  • 6
Safety Assist
Speed Assistance (points)
0 /3
Lane Support (points)
0 /4
Seat Belt Reminders
2
Pedestrian
Protection (Assessment)
Marginal

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
2 years
Body Protection
3 years
Paintwork
3 years
Rust Damage
12 years

Identification

VIN Location
Engine Compartment, Inner Wing
Right
Left Side Casing of Window
Yes
Trunk
on Floor
On-board Diagnostic, Port Location
Steering Wheel, Lower Left

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

Spare Parts BETA

Bulb Types
Low Beam
  • D3S (xenon)
  • D8S (xenon)
  • H7
Main Beam
H1
Bi-Xenon
  • D3S
  • D8S
Datyime Running Light
W3×16d (W21W)
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Rear/Brake Light
BA15s (P21W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAW9s (HY21W)
Turn Indicators, Rear
W2.1×9.5d (W16W)
Glove Compartment
W2.1×9.5d (W5W)
Read Light
W2.1×9.5d (W5W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
SV8.5 (C5W)

ACRISS

Category
Economy Elite (H)
Type
2-3 Doors (B)

Awards

Golden Steering Wheel
Subcompact
2010
