2013 Kia Optima

South KoreaHybrid GasolineFWDSedan

Photos

Specifications

Vehicle Details

Year
2013
Make
Kia
Model
Optima
Body Style
Sedan
Generation
TF
Seats
5
Doors
4
Fuel
Hybrid Gasoline
Drivetrain
FWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
2.0 CVVL Hybrid Automatic
Engine Configuration
Inline
Power (hp)
190 hp
Power (kW)
140 kW
Torque
340 Nm (251 lb-ft)
Top speed
190 km/h (118 mph)
0–60 mph
9.0 seconds (estimated)
0–100 km/h
9.4 seconds
Displacement
1,999 cc

Dimensions

Length
4,845 mm (190.7 in)
Width
1,835 mm (72.2 in)
Height
1,455 mm (57.3 in)
Wheelbase
2,795 mm (110.0 in)
Curb weight
1,562 kg (3,444 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
1,400 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-20
Engine Oil, Volume
4 litres
Configuration Combustion
Bore
81 mm (3.2 in)
Stroke
97 mm (3.8 in)
Compression Ratio
10.5 :1
Engine Configuration
Inline
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Engine Cooling
Liquid Cooling
Configuration Electric
Type of Electric Car
Hybrid

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut

Fuel

General
Tank Volume
65 litres
Lockable Fuel Cap
Yes
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 5
Fuel Consumption NEDC
City
5.7 litres / 100 km
Highway
5.3 litres / 100 km
Combined
5.4 litres / 100 km
Emission NEDC
CO₂, Combined
123 g/km

Dimensions & Weight

Exterior

Track, Front
1,591 mm (62.6 in)
Track, Rear
1,591 mm (62.6 in)
Turning Circle
10.9 m
Ground Clearance
135 mm (5.3 in)

Interior

Head Room, Front
990 mm (39.0 in)
Head Room, Rear
920 mm (36.2 in)
Leg Room, Front
1,156 mm (45.5 in)
Leg Room, Rear
881 mm (34.7 in)
Hip Room, Front
1,389 mm (54.7 in)
Hip Room, Rear
1,384 mm (54.5 in)
Shoulder Room, Front
1,453 mm (57.2 in)
Shoulder Room, Rear
1,415 mm (55.7 in)

Weight

Gross Weight
2,050 kg (4,519 lb)
Cargo Capacity
488 kg (1,076 lb)
Max Roof Load
70 kg (154 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Hyundai-Kia Platforms
Y Platform (Y6)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Intermittent Control
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Safety Glass
Yes
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Electric
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Special Features
Come Home/Leaving Lights
Fog Lights
Front
Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
88 - 107 Nm
Rim Material
Alloy
Rim Colour
Silver
Rim Type
Disc Wheel
Spare Wheel
Yes

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
  • XM
Media Format
  • CD
  • MP3
  • WMA
Media Inputs
USB
Bluetooth
Phone
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Yes
Speakers
Total Number of Speakers
6 pcs
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Manual
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Cooled
  • Light
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Yes
Ashtray
Yes
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
Instrument Cluster

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Answer Phone
Yes
Volume
Yes
Mute Audio
Yes
Multifunction Steering Wheel
Menu Navigation
Yes
Cruise Control
Activate/Deactivate

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
505 litres
Volume, Back Seat Collapsed
1,080 litres
Sill Height
700 mm (27.6 in)

Design

Transmission Knob Material
Leather

Seats

Front Seats › Adjustments, Driver
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Yes
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Headrest, Height
Manual
Front Seats
Armrest
Middle
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes

Features

Comfort Features

Cruise Control
Yes
Speed Limiter
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Central Locking
Yes
Child Safety Locks
Yes
Active Headrests
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes
Overall Score
35.58
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
14.58
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
3
Frontal Crash
Front Driver Side
5/5 stars
Front Passenger Side
5/5 stars
Side Crash
Side Crash, Driver
3/5 stars
Side Crash, Passenger
5/5 stars
Front Seat Rating
3/5 stars
Combined Rear Seat Rating
5/5 stars
Side Barrier Rating
5/5 stars
Overall Side Pole Star Rating
5/5 stars
Rollover
Rollover Resistance
9.6 %
Overall Safety Rating
5/5 stars
Overall Frontal Rating
5/5 stars
Overall Side Rating
5/5 stars
Rollver
5/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
7 years
12V Battery
2 years
Paintwork
150,000 km / 5 years
Rust Damage
150,000 km / 7 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
150,000 km / 7 years

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of
On-board Diagnostic, Port Type
OBD-II

Car Classification

American Classification
Mid-Size Car
British Classification
Large Family Car
Australian Classification
Medium Car
European Segment
D-Segment
Car.info Classification
Large Family Car

Spare Parts BETA

Bulb Types
Low Beam
  • D1S (xenon)
  • H7
Main Beam
H1
Fog Light, Front
H8
Cornering Light
H1
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

Awards

International Car of the Year
2013
