2013 Nissan Leaf

JapanElectricFWDHatchback

Photos

Specifications

Vehicle Details

Year
2013
Make
Nissan
Model
Leaf
Body Style
Hatchback
Generation
ZE0 1st Facelift
Seats
5
Doors
5
Fuel
Electric
Drivetrain
FWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
24 kWh Single Speed
Engine Configuration
Electric
Power (hp)
109 hp
Power (kW)
80 kW
Torque
280 Nm (207 lb-ft)
Top speed
145 km/h (90 mph)
0–60 mph
11.3 seconds (estimated)
0–100 km/h
11.9 seconds
Electric range
95 km (59 mi)
Battery
24 kWh

Dimensions

Length
4,445 mm (175.0 in)
Width
1,770 mm (69.7 in)
Height
1,550 mm (61.0 in)
Wheelbase
2,700 mm (106.3 in)
Curb weight
1,642 kg (3,620 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,150 rpm
Rev. at Max Torque
2,730 rpm
Configuration Combustion
Bore
0 mm (0.0 in)
Stroke
0 mm (0.0 in)
Compression Ratio
0 :1
Configuration Electric
Type of Electric Car
Electric
Electric Engine Power
80 kW
Electric Engine Horsepower (Metric)
109 hp
Torque
280 Nm (207 lb-ft)
Front Engines
Yes
Battery Capacity, Gross
24 kWh
Battery Capacity, Net
22 kWh
Number of Batterycells
48
Type of Battery
Li-ion
AC Charge Type
Single-phase
Charging Plugs
  • CHAdeMO
  • Type 1
Vehicle to Load (V2L)
Yes
Configuration Electric › Front Engines
Power (kW)
80 kW
Horsepower
109 hp
RPM at Max Power
6,150 rpm
Number of Engines
1
Configuration Electric › Charge AC
Charge Time
4 h / 240 min
Charge Power
6.6 kW
Charge Ampere
32 A
Configuration Electric › Charge DC
Charge Time, to 80%
37 min
Charge Power
46 kW
Configuration Electric › Vehicle to Load (V2L)
Max Discharge Power
7 kW
Service Intervals
Interior Filter
15,000 km / 1 years

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Suspension, Front
Independent
MacPherson Strut

Energy & Range

Emission
Emission Class
A+
WLTP Consumption
Energy consumption
16.3 - 19.1 kWh/100km
Electric Range
95 - 115 km (59 - 71 mi)
Electric Range, City
135 km (84 mi)
Fuel Consumption NEDC
Combined
0 litres / 100 km
Energy consumption
17.3 kWh/100km
Electric Range
199 km (124 mi)
Emission WLTP
CO₂, Combined
0 g/km
Emission NEDC
CO₂, Combined
0 g/km

Dimensions & Weight

Exterior

Track, Front
1,540 mm (60.6 in)
Track, Rear
1,535 mm (60.4 in)
Turning Circle
10.4 m
Ground Clearance
159 mm (6.3 in)

Interior

Head Room, Front
1,045 mm (41.1 in)
Head Room, Rear
946 mm (37.2 in)
Leg Room, Front
1,070 mm (42.1 in)
Leg Room, Rear
847 mm (33.3 in)
Hip Room, Front
1,313 mm (51.7 in)
Hip Room, Rear
1,271 mm (50.0 in)
Shoulder Room, Front
1,378 mm (54.3 in)
Shoulder Room, Rear
1,334 mm (52.5 in)

Weight

Gross Weight
1,965 kg (4,332 lb)
Cargo Capacity
323 kg (712 lb)
Max Roof Load
35 kg (77 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Renault-Nissan Platforms
B Platform (EV)

Equipment

Side Mirrors
Adjustments
Electrical
Heated
Optional
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Front
Heat-Insulating Windows
  • Front
  • First Row
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Normal Roof
Yes
Antenna
Roof-integrated

Lights

Rear Lights
LED
Daytime Running Light
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes
Special Features
Automatic Headlight Activation
Optional
Come Home/Leaving Lights
Optional
Headlight Range Adjustment
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
66.1
Fastening Type
Lug Nuts
Tightening Torque
112 Nm
Rim Colour
Silver

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Secondary Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
  • CD
  • MP3
Bluetooth
Yes
Connectivity › Media Inputs
AUX
Yes
USB
Optional
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Speakers
Total Number of Speakers
4 - 7 pcs
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Yes
Lights
Read Light
Front
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Carpets
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Hydraulic
Adjustments
Tilt
Colour
Black
Voice Command
Yes
Answer Phone
Yes
Volume
Yes

Trunk

Rear Trunk
Yes
Carpet
Optional
Light
Optional
Rear Trunk
Volume
355 litres
Volume, Back Seat Collapsed
680 litres
Carpet
Rug
Optional

Design

Colour
Grey
Colour
Black
Optional

Seats

Front Seats › Adjustments, Driver
Seat Height
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Headrest, Height
Yes
Front Seats
Heated Seats
Optional
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Split Fold Ratio
60/40
Heated Seats
Optional

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Optional
Speed Limiter
Optional
Cameras
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Rain Sensors
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Yes

Safety Testing

General
Test Year
2012
Adult Occupant
89 %
Child Occupant
83 %
Vulnerable Road Users
65 %
Safety Assist
84 %
Overall
5/5 stars
Side Crash
Side Crash, Driver
5/5 stars
Side Crash, Passenger
3/5 stars
Front Seat Rating
5/5 stars
Combined Rear Seat Rating
3/5 stars
Side Barrier Rating
4/5 stars
Overall Side Pole Star Rating
5/5 stars
Rollover
Rollover Resistance
10.9 %
Overall Safety Rating
4/5 stars
Overall Side Rating
4/5 stars
Rollver
4/5 stars
Teknikens Världs Moose Test
Test Year
2014
Speed
61 km/h (38 mph)

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

EV Battery
160,000 km / 8 years

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Right Side Casing of Window
Yes

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car

Spare Parts BETA

Bulb Types
Main Beam
  • H9
  • H13
Fog Light, Front
H11
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Rear
WX3×16d (WY21W)
