2014 Cadillac ELR

United StatesRex ElectricgasolineFWDCoupe

Photos

Specifications

Vehicle Details

Year
2014
Make
Cadillac
Model
ELR
Body Style
Coupe
Generation
1st Generation
Seats
4
Doors
2
Fuel
Rex Electricgasoline
Drivetrain
FWD
Transmission
Automatic (Continuously variable)

Powertrain

Engine Name
1.4 + 16.5 kWh e-CVT
Engine Configuration
Inline
Power (hp)
209 hp
Power (kW)
154 kW
Torque
400 Nm (295 lb-ft)
Top speed
161 km/h (100 mph)
Electric range
480 km (298 mi)
Battery
16.5 kWh
Displacement
1,398 cc

Dimensions

Length
4,724 mm (186.0 in)
Width
1,847 mm (72.7 in)
Height
1,420 mm (55.9 in)
Wheelbase
2,695 mm (106.1 in)
Curb weight
1,846 kg (4,070 lb)

Engine & Performance

Engine

Engine Fluids
Engine Oil, Volume
3.5 litres
Engine Coolant, Volume
7.3 litres
Battery Coolant, Volume
5.8 litres
Configuration Combustion
Bore
73.4 mm (2.9 in)
Stroke
82.6 mm (3.3 in)
Compression Ratio
10.5 :1
Engine Configuration
Inline
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Configuration Combustion › ICE Specifications
Power
63 kW
Horsepower (Metric)
85 hp (84 bhp)
Configuration Electric
Type of Electric Car
Range Extender (REX)
Electric Engine Power
63 kW
Electric Engine Horsepower (Metric)
85 hp (84 bhp)
Front Engines
Yes
Battery Capacity, Gross
16.5 kWh
Type of Battery
Li-ion
Configuration Electric › Front Engines
Number of Engines
2
Service Intervals
Air Filter
72,000 km / 4 years
Spark Plug
156,000 km (96,934 mi)
Brake Fluid
240,000 km / 10 years
Oil Change & Engine Filter
2 years
Engine Coolant
240,000 km / 5 years
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Continuously variable)
Gear Selector
Stick
Gear Selector Location
Mid-Console

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
321 - 345 mm (12.6 - 13.6 in)
Width
60 mm (2.4 in)
Cooling
Ventilated
Rear Brakes
Diameter
292 - 315 mm (11.5 - 12.4 in)
Width
38 mm (1.5 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Fuel

General
Tank Volume
35 litres
General › Fuel Cap Position
Rear
Right
General › Charging Socket Position
Front
Left
Fuel Consumption EPA
Electric Range
480 km (298 mi)
Electric Range (EPA)
300 miles

Dimensions & Weight

Exterior

Track, Front
1,578 mm (62.1 in)
Track, Rear
1,585 mm (62.4 in)
Turning Circle
11.7 m

Interior

Head Room, Front
938 mm (36.9 in)
Head Room, Rear
882 mm (34.7 in)
Leg Room, Front
1,403 mm (55.2 in)
Leg Room, Rear
1,268 mm (49.9 in)
Hip Room, Front
1,344 mm (52.9 in)
Hip Room, Rear
1,234 mm (48.6 in)
Shoulder Room, Front
1,403 mm (55.2 in)
Shoulder Room, Rear
1,268 mm (49.9 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-C
Chassis Construction
Unibody
Roof Material
  • Aluminium
  • Steel
Doors
Front Doors
Conventional
Door Handles
Handle-less
Platform
General Motors Platforms
Delta Platform (Delta II)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Manual
Turning Signal
Yes
House Colour
Same as Car
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Frameless Windows
First Row
Other Equipment
Normal Roof
Yes
Spoiler
Yes
Antenna
Shark Fin

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Special Features
Main Beam Assist

Colour

Finish
Metallic

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
115
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
70.3
Fastening Type
Lug Nuts

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Micro Filter
Yes
Connectivity
Radio
Yes
Media Inputs
USB
App-Connect
Yes
Bluetooth
Phone
Connectivity › Media Format
Memory Card Reader
SD
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Speakers
Speaker Brand
Bose
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Yes
Interior Storage
Cup Holders
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
  • Make-up Light

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Yes
Adjustments
Telescope
Material
Leather
Channels
Yes
Volume
Yes
Mute Audio
Yes
Multifunction Steering Wheel
Cruise Control
Yes

Trunk

Rear Trunk
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
295 litres

Seats

Colour & Material
Upholstery
Leather
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats
Power Seat, Driver
Yes
Heated Seats
Yes
Armrest
Yes
Second Seat Row
Number of Seats
2
Type of Seat
Adult

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Remote Engine Start
Yes
Cruise Control
Yes
Cameras
Rear
Cruise Control
Adaptive Cruise Control
Optional

Other Features

Start & Stop
Yes

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Lane Assist System
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Yes
Pedestrian/Bicycle Detection
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag

Seat Belt

Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car
