2015 Fiat 500X

ItalyGasolineFWDCrossover

Photos

Specifications

Vehicle Details

Year
2015
Make
Fiat
Model
500X
Body Style
Crossover
Generation
334
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 9-speed

Powertrain

Engine Name
2.4 MultiAir Automatic
Engine Configuration
Inline
Power (hp)
182 hp
Power (kW)
134 kW
Torque
237 Nm (175 lb-ft)
Displacement
2,360 cc

Dimensions

Length
4,250 mm (167.3 in)
Width
1,796 mm (70.7 in)
Height
1,608 mm (63.3 in)
Wheelbase
2,570 mm (101.2 in)
Curb weight
1,405 kg (3,097 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,400 rpm
Rev. at Max Torque
3,900 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Bore
88 mm (3.5 in)
Stroke
97 mm (3.8 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Fuel Filter
60,000 km (37,282 mi)
Spark Plug
30,000 km (18,641 mi)
Brake Fluid
2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
4 years
Interior Filter
30,000 km / 1 years

Transmission & Drivetrain

Transmission
Automatic, 9-speed
Gear Ratio
1st Gear
4.71 :1
2nd Gear
2.84 :1
3rd Gear
1.91 :1
4th Gear
1.38 :1
5th Gear
1 :1
6th Gear
0.81 :1
7th Gear
0.7 :1
8th Gear
0.58 :1
Final Drive
3.73 :1
Reverse
3.83 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
48 litres
Emission
Emission Control
Catalyst
Fuel Consumption NEDC
City
10.7 litres / 100 km
Highway
7.6 litres / 100 km
Combined
9.4 litres / 100 km

Dimensions & Weight

Exterior

Width, with Mirrors
2,025 mm (79.7 in)
Track, Front
1,545 mm (60.8 in)
Track, Rear
1,545 mm (60.8 in)
Turning Circle
11.1 m
Ground Clearance
160 mm (6.3 in)

Interior

Head Room, Front
993 mm (39.1 in)
Head Room, Rear
961 mm (37.8 in)
Leg Room, Front
1,053 mm (41.5 in)
Leg Room, Rear
883 mm (34.8 in)
Hip Room, Front
1,354 mm (53.3 in)
Hip Room, Rear
1,326 mm (52.2 in)

Weight

Gross Weight
1,940 kg (4,277 lb)
Cargo Capacity
535 kg (1,179 lb)
Max Roof Load
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Fiat Platforms
Small Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Windscreen Wipers
Heated Wiper Blades
Optional
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
  • Second Row
  • Rear Window
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Spoiler
Fixed
Antenna
Whip
Number of Exhaust Pipes
1

Lights

Main Beam
Xenon
Low Beam
Xenon
Rear Lights
Halogen
Daytime Running Light
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes
Rear
Yes
Fog Lights › Front
Cornering Lights
Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
110
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
65.1
Fastening Type
Lug Bolts
Tightening Torque
120 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
  • Analogue
  • Digital
Tachometer
Analogue
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
3.5"
Climate Control
Climate Control
Automatic
Air Condition
Yes
Micro Filter
Yes
Number of Vents, Front
4 pcs
Connectivity
Radio
  • AM
  • FM
Media Format
MP3
Media Inputs
USB
Bluetooth
Phone
Connectivity › Radio
DAB
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
6.5"
Center Display Controls
Touchscreen
Speakers
Total Number of Speakers
6 - 8 pcs
Speakers Max. Watt
506 W
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Optional
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Lights
Guide Light
Yes
Other Equipment
12V Outlet
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Material
Leather
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Yes
Multifunction Steering Wheel
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down
  • Resume

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
350 litres
Volume, Back Seat Collapsed
1,000 litres

Design

Transmission Knob Material
Leather

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Front Seats
Heated Seats
Optional
Armrest
Yes
Second Seat Row
Armrest
Yes
Number of Seats
3
Split Fold Ratio
60/40

Features

Comfort Features

Garage Remote Control
Optional
Cruise Control
Yes
Cameras
Optional
Phone
Yes
Cruise Control
Adaptive Cruise Control
Optional
Cameras
Rear
Optional

Other Features

GPS
Yes
Start & Stop
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Centre Rear Seat
Rear Centre Seat Belt
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Light Sensor
Optional
Rain Sensors
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Yes

Safety Testing

General
Test Year
2015
Adult Occupant
86 %
Child Occupant
85 %
Vulnerable Road Users
74 %
Safety Assist
64 %
Overall
4/5 stars
Test Year
2016
Overall Score
36.12
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
15.12
Side Impact
16
Pole
2
Whiplash Protection (Assessment)
Good
Pedestrian
Protection (Assessment)
Acceptable
Safety Assist
Seat Belt Reminders
3
IIHS
Test Year
2016
Small Overlap Front: Driver Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Headlight
Poor
Latch Ease of Use
Marginal

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact SUV
European Segment
J-Segment JB-Segment
Car.info Classification
Small SUV

ACRISS

Type
Crossover (G)
