2015 Hyundai i20 Active

South KoreaDieselFWDCrossover

Photos

Specifications

Vehicle Details

Year
2015
Make
Hyundai
Model
i20
Variant
Active
Body Style
Crossover
Generation
GB
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
FWD
Transmission
Manual, 6-speed

Powertrain

Engine Name
1.4 CRDi Manual
Engine Configuration
Inline
Power (hp)
90 hp
Power (kW)
66 kW
Torque
240 Nm (177 lb-ft)
Top speed
170 km/h (106 mph)
0–60 mph
11.7 seconds (estimated)
0–100 km/h
12.3 seconds
Displacement
1,396 cc

Dimensions

Length
4,065 mm (160.0 in)
Width
1,734 mm (68.3 in)
Height
1,474 mm (58.0 in)
Wheelbase
2,570 mm (101.2 in)
Curb weight
1,250 kg (2,756 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,000 rpm
Rev. at Max Torque
1,500 - 2,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Bore
75 mm (3.0 in)
Stroke
79 mm (3.1 in)
Engine Configuration
Inline
Turbocharger
Yes
Service Intervals
Air Filter
60,000 km / 4 years
Fuel Filter
60,000 km / 4 years
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
30,000 km / 2 years
Engine Coolant
40,000 km / 2 years
Interior Filter
30,000 km / 2 years

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 6
Emission Class
B
Fuel Consumption NEDC
City
5.3 litres / 100 km
Highway
3.8 litres / 100 km
Combined
4.3 litres / 100 km
Emission NEDC
CO₂, Combined
115 g/km

Dimensions & Weight

Exterior

Track, Front
1,511 mm (59.5 in)
Track, Rear
1,513 mm (59.6 in)
Overhang, Front
748 mm (29.4 in)
Overhang, Rear
748 mm (29.4 in)
Ground Clearance
170 mm (6.7 in)

Interior

Head Room (est.), Front
1,005 mm (39.6 in)
Head Room (est.), Rear
970 mm (38.2 in)
Leg Room (est.), Rear
794 mm (31.3 in)

Weight

Gross Weight
1,700 kg (3,748 lb)
Max Trailer Load, braked 12%
1,110 kg (2,447 lb)
Max Trailer Load, unbraked
450 kg (992 lb)
Cargo Capacity
450 kg (992 lb)
Max Roof Load
70 kg (154 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Hyundai-Kia Platforms
Small Automobile Platform (GB)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windscreen Wipers: Connector type, Front
Hook
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Yes
Windows › Window Lifts, Features
Pinch Protection
Yes
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Yes
Antenna
Yes
Mud Flaps
Optional
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Silver
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Daytime Running Light
LED
Fog Lights
Yes
Fog Lights
Front
Yes
Rear
Yes
Fog Lights › Front
Cornering Lights
Yes
Special Features
Headlight Range Adjustment
Manual

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Nut/Bolt Dimensions
M12x1.5
Fastening Type
Lug Nuts
Tightening Torque
88 - 107 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
  • RDS
Media Format
  • CD
  • MP3
  • WMA
Media Inputs
USB
Bluetooth
Phone
Connectivity › Radio
DAB
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Speakers
Total Number of Speakers
2 pcs
Interior Storage › Storage Compartments
Glove Compartment
  • Cooled
  • Light
  • Lockable
Sunglass Compartment
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Optional
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster
Other Equipment › Carpets
Colour
Black

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Scrolling Wheel
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Cover
Yes
Barrier Net/Grid
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
326 litres
Volume, Back Seat Collapsed
1,042 litres

Design

Transmission Knob Material
Leather

Seats

Colour & Material
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats
Heated Seats
Yes
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Split Fold Ratio
60/40

Features

Comfort Features

Keyless Start
Optional
Cruise Control
Yes
Speed Limiter
Yes
Cameras
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Yes
Horn
Dual Note

Safety & Security

Seat Belt

Height Adjustable Retractor
Optional
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Type of Belt
Three-Point-Belt
Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Hill Start Assist (HSA)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Child Safety Locks
Yes

Safety Testing

General
Test Year
2015
Adult Occupant
85 %
Child Occupant
73 %
Vulnerable Road Users
79 %
Safety Assist
64 %
Overall
5/5 stars
Test Year
2015
ANCAP Safety Rating
4
Adult Occupant
Protection
85 %
Protection
32.7
Full Width
7.79
Frontal Offset
7.68
Side Impact
7.5
Pole
7.5
Whiplash Protection (Front)
2.2
AEB (City)
0
Child Occupant
Protection
73 %
Protection
35.8
Pedestrian
Protection
79 %
Protection
28.5
Safety Assist
Safety Assist
64 %
Safety Assist
8.3
Speed Assistance System
1.3
ESC
3
Seat Belt Reminders
3
Lane Support System
1
AEB (Interurban)
0

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

Spare Parts BETA

Bulb Types
Low Beam
  • H4
  • HB3
Main Beam
  • H4
  • HB3
Datyime Running Light
BA15s (P21W)
Fog Light, Front
H8
Fog Light, Rear
BA15s (P21W)
Cornering Light
H7
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Type
Monoscape (M)

Awards

Golden Steering Wheel
Subcompact
2015
