2015 Mercedes-Benz B-Class

GermanyDieselAWDHatchback

Photos

Specifications

Vehicle Details

Year
2015
Make
Mercedes-Benz
Model
B-Class
Body Style
Hatchback
Generation
W246 Facelift
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
AWD
Transmission
Automatic

Powertrain

Engine Name
B 200 d 4MATIC 7G-DCT
Engine Configuration
Inline
Power (hp)
136 hp
Power (kW)
100 kW
Torque
300 Nm (221 lb-ft)
Top speed
207 km/h (129 mph)
0–60 mph
8.5 seconds (estimated)
0–100 km/h
8.9 seconds
Displacement
2,143 cc

Dimensions

Length
4,393 mm (173.0 in)
Width
1,786 mm (70.3 in)
Height
1,557 mm (61.3 in)
Wheelbase
2,699 mm (106.3 in)
Curb weight
1,575 kg (3,472 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
3,600 - 4,400 rpm
Rev. at Max Torque
1,600 - 3,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
Engine Oil, Volume
6.5 litres
Engine Configuration
Compression Ratio
16.2 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Engine Mount
Transversally
Service Intervals
Air Filter
80,000 km / 4 years
Fuel Filter
200,000 km / 10 years
Brake Fluid
2 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
200,000 km / 10 years

Transmission & Drivetrain

Transmission
Automatic

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
Yes

Fuel

General
Tank Volume
56 litres
Emission
Emission Standard
Euro 6
Emission Class
B
Emission WLTP
CO₂, Combined
173 g/km
Emission NEDC
CO₂, Combined
130 - 131 g/km
Fuel Consumption NEDC
City
5.8 - 5.9 litres / 100 km
Highway
4.5 litres / 100 km
Combined
5 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,552 mm (61.1 in)
Track, Rear
1,549 mm (61.0 in)
Turning Circle
11 m
Ground Clearance
127 mm (5.0 in)

Interior

Head Room, Front
1,047 mm (41.2 in)
Head Room, Rear
985 mm (38.8 in)
Leg Room, Front
1,060 mm (41.7 in)
Leg Room, Rear
975 mm (38.4 in)
Hip Room, Front
1,330 mm (52.4 in)
Hip Room, Rear
1,446 mm (56.9 in)
Shoulder Room, Front
1,411 mm (55.6 in)
Shoulder Room, Rear
1,382 mm (54.4 in)

Weight

Gross Weight
2,095 kg (4,619 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
520 kg (1,146 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Side Mirrors › Adjustments
Driver side
Optional
Windscreen Wipers
Windscreen Wipers: Connector type, Front
Mercedes-Benz Fit
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Yes
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Normal Roof
Yes
Antenna
Glass-integrated

Lights

Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
Main Beam Assist
Fog Lights
Rear
Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
112
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.6
Fastening Type
Lug Bolts
Tightening Torque
130 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Phone
Connectivity › Media Format
CD
Optional
DVD
Optional
Memory Card Reader
SD
Connectivity › Media Inputs
USB
Yes
Connectivity › Media Inputs › USB
Number of Ports
2 pcs
Displays
Center Display
7"
Speakers
Total Number of Speakers
6 pcs
Interior Storage › Storage Compartments
Armrest Hatch
Yes
Back Pocket
Optional
Sunglass Compartment
Optional
Interior Storage
Cup Holders
Optional
Interior Storage › Cup Holders
Front
Yes
Other Equipment
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Adjustments
  • Tilt
  • Telescope
Sport
Yes
Number of Spokes
3
Colour
Grey
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
488 litres
Volume, Back Seat Collapsed
1,547 litres
Depth
744 mm (29.3 in)
Depth, Back Seat Collapsed
1,421 mm (55.9 in)
Sill Height
538 mm (21.2 in)

Design

Silver
Optional

Seats

Front Seats › Adjustments, Driver
Seat Depth
Optional
Seat Height
Manual
Cushion Edge
Yes
Cushion Tilt
Yes
Backrest Angle
Manual
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
Middle
Front Seats › Heated Seats
Cushion
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Heated Seats
Optional
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Comfort Features

Keyless Start
Yes
Cruise Control
Yes
Cruise Control
Rear
Optional

Other Features

Start & Stop
Yes

Accessories

Warning Triangle
Yes
First Aid Kit
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Manual
Collision Avoidance System
Yes
Emergency Call
Yes
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2011
Adult Occupant
97 %
Child Occupant
81 %
Vulnerable Road Users
56 %
Safety Assist
86 %
Overall
5/5 stars
Overall Score
36.78
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
15.78
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
3

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
  • A-Pillar, Right
  • B-Pillar, Right
Passenger Seat
in Front of

Car Classification

American Classification
MPV
British Classification
Compact MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Medium MPV

Spare Parts BETA

Bulb Types
Low Beam
  • D1S (xenon)
  • H7
Main Beam
H7
Bi-Xenon
D1S
Fog Light, Front
H11
Fog Light, Rear
  • BA15s (P21W)
  • BAY9s (H21W)
Cornering Light
H7
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BA15s (P21W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
Read Light
W2.1×9.5d (W5W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
SV8.5 (C5W)

ACRISS

Category
Intermediate Elite (J)
Type
4-5 Doors (D)
