2015 Toyota Sienna

JapanGasolineFWDMinivan

Photos

Specifications

Vehicle Details

Year
2015
Make
Toyota
Model
Sienna
Body Style
Minivan
Generation
XL30 1st Facelift
Seats
7
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
3.5 V6 Automatic
Engine Configuration
V
Power (hp)
269 hp
Power (kW)
198 kW
Torque
332 Nm (245 lb-ft)
Top speed
236 km/h (147 mph)
0–60 mph
7.9 seconds (estimated)
0–100 km/h
8.3 seconds
Displacement
4 cc

Dimensions

Length
5,085 mm (200.2 in)
Width
1,985 mm (78.1 in)
Height
1,810 mm (71.3 in)
Wheelbase
3,030 mm (119.3 in)
Curb weight
1,940 kg (4,277 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,200 rpm
Rev. at Max Torque
4,700 rpm
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
83 mm (3.3 in)
Compression Ratio
10.8 :1
Engine Configuration
V-Engine

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Fuel

General
Tank Volume
79 litres
Fuel Consumption NEDC
City
13 litres / 100 km
Highway
9.5 litres / 100 km
Combined
11.4 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,720 mm (67.7 in)
Track, Rear
1,720 mm (67.7 in)
Turning Circle
11.4 m
Ground Clearance
157 mm (6.2 in)

Interior

Head Room, Front
1,041 mm (41.0 in)
Head Room, Rear
1,008 mm (39.7 in)
Head Room, Third Row
973 mm (38.3 in)
Leg Room, Front
1,029 mm (40.5 in)
Leg Room, Rear
955 mm (37.6 in)
Leg Room, Third Row
922 mm (36.3 in)
Shoulder Room, Front
1,650 mm (65.0 in)
Shoulder Room, Rear
1,642 mm (64.6 in)
Shoulder Room, Third Row
1,552 mm (61.1 in)

Weight

Max Trailer Load, braked 12%
1,588 kg (3,501 lb)
Max Trailer Load, unbraked
680 kg (1,499 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Platform
Toyota Platform
K Platform

Equipment

Other Equipment
Tow Hook
  • Front
  • Rear
Roof Railing
Optional

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
60.1
Fastening Type
Lug Nuts
Tightening Torque
103 Nm

Interior

Equipment

Climate Control
Air Condition
Yes
Outside Temperature Indicator
Yes
Controls
  • Buttons
  • Rotary Dials
Climate Control › Air Condition
Refrigerant
R134A

Seats

Third/Fourth Seat Row
Third Seat Row
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
1,110 litres
Volume, Back Seat Collapsed
2,470 litres

Safety & Security

Safety Testing

General
Not Tested by Euro NCAP
Yes
Frontal Crash
Front Driver Side
5/5 stars
Front Passenger Side
4/5 stars
Side Crash
Side Crash, Driver
5/5 stars
Side Crash, Passenger
5/5 stars
Front Seat Rating
5/5 stars
Combined Rear Seat Rating
5/5 stars
Side Barrier Rating
5/5 stars
Overall Side Pole Star Rating
5/5 stars
Rollover
Rollover Resistance
14 %
Overall Safety Rating
5/5 stars
Overall Frontal Rating
4/5 stars
Overall Side Rating
5/5 stars
Rollver
4/5 stars
IIHS
Test Year
2015
Small Overlap Front: Driver Side
Acceptable
Small Overlap Front: Passenger Side
Marginal
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Headlight
Acceptable
Latch Ease of Use
Acceptable

Other

Warranty

Manufacturer
100,000 km / 3 years
Body Protection
3 years
Paintwork
3 years
Rust Damage
12 years
Roadside Assistance
Yes

Car Classification

American Classification
Minivan
British Classification
Large MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Large MPV
