2016 Cadillac ATS

United StatesGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2016
Make
Cadillac
Model
ATS
Body Style
Sedan
Generation
1st Generation Facelift
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic (Electrohydraulic), 8-speed

Powertrain

Engine Name
ATS-V (EU) Hydra-Matic
Engine Configuration
V
Power (hp)
470 hp
Power (kW)
346 kW
Torque
603 Nm (445 lb-ft)
Top speed
304 km/h (189 mph)
0–60 mph
3.7 seconds (estimated)
0–100 km/h
3.9 seconds
Displacement
3,564 cc

Dimensions

Length
4,689 mm (184.6 in)
Width
1,828 mm (72.0 in)
Height
1,421 mm (55.9 in)
Wheelbase
2,775 mm (109.3 in)
Curb weight
1,700 kg (3,748 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,850 rpm
Rev. at Max Torque
3,500 rpm
Redline
6,500 rpm
Engine Fluids
Engine Oil, Volume
6.6 litres
Engine Coolant, Volume
10.2 litres
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
85.6 mm (3.4 in)
Compression Ratio
10.2 :1
Engine Configuration
V-Engine
Turbocharger
Twin-turbo
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
36,000 km / 4 years
Spark Plug
96,000 km (59,652 mi)
Brake Fluid
240,000 km / 10 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 8-speed
Gear Selector
  • Stick
  • Paddles
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.56 :1
2nd Gear
2.97 :1
3rd Gear
2.08 :1
4th Gear
1.69 :1
5th Gear
1.27 :1
6th Gear
1 :1
7th Gear
0.85 :1
8th Gear
0.65 :1
Final Drive
2.85 :1
Reverse
3.82 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
370 mm (14.6 in)
Width
34 mm (1.3 in)
Cooling
Ventilated
Rear Brakes
Diameter
339 - 336 mm (13.3 - 13.2 in)
Width
29 mm (1.1 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Electronic Damper Control (EDC)
Yes
Suspension, Front
Independent
Multi-link
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
62.5 litres
Lockable Fuel Cap
Yes
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 6
Emission Class
G
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
17.3 litres / 100 km
Highway
8.2 litres / 100 km
Combined
11.6 litres / 100 km
Emission NEDC
CO₂, City
397 g/km
CO₂, Highway
189 g/km
CO₂, Combined
265 g/km

Dimensions & Weight

Exterior

Track, Front
1,538 mm (60.6 in)
Track, Rear
1,537 mm (60.5 in)
Turning Circle
11.7 m

Interior

Head Room, Front
980 mm (38.6 in)
Head Room, Rear
935 mm (36.8 in)
Leg Room, Front
1,079 mm (42.5 in)
Leg Room, Rear
851 mm (33.5 in)
Hip Room, Front
1,345 mm (53.0 in)
Hip Room, Rear
1,328 mm (52.3 in)
Shoulder Room, Front
1,345 mm (53.0 in)
Shoulder Room, Rear
1,370 mm (53.9 in)

Weight

Gross Weight
2,200 kg (4,850 lb)
Cargo Capacity
500 kg (1,102 lb)
Max Roof Load
75 kg (165 lb)
Weight Distribution, front
51 %
Weight Distribution, rear
49 %

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Alpha Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
User Memory
Yes
Heated
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Windows › Window Lifts, Features
One-touch up/down
  • Driver
  • Passenger
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Spoiler
Optional
Other Equipment › Sunroof
Sun Blind
Optional

Lights

Main Beam
LED
Daytime Running Light
LED

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Instrument Cluster › Trip Computer
Display
5.7"
Instrument Cluster › Trip Computer › Display
Type
Colour
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
  • DAB+
Media Format
CD
Media Inputs
USB
Bluetooth
  • Phone
  • Audio
  • Siri Eyes Free
Connectivity › Media Format
Memory Card Reader
SD
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
8"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
7 - 10 pcs
Speaker Brand
Bose
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Back Pocket
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
2
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
  • Front
  • Rear
Guide Light
Bottom of the Doors
Ambient Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Yes
230V Outlet
Yes
Ashtray
Yes
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Electric
Adjustments
User Memory
Material
Leather
Multifunction Steering Wheel
Cruise Control
Yes
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Volume
Yes
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Automatic Open
From Inside Car
Automatic Close
Yes
Light
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
295 litres

Design

Aluminium
Optional
Aluminium
Sport
Optional

Seats

Colour & Material
Upholstery
Leather
Front Seats › Adjustments, Driver
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Number of Driver Seat Adjustments, Powered
8
Power Seat, Driver
Yes
Heated Seats
  • Driver
  • Passenger
Front Seats › Adjustments, Passenger
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Power Seat, Driver
User Memory
Yes
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Yes
Centre Seat
Yes

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Yes
Cameras
Rear
Cruise Control
Adaptive Cruise Control
Optional

Other Features

GPS
Navigation

Accessories

Tire Repair Kit
Yes

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Optional
Lane Assist System
Yes
Sign Assist
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Traction Control System (TCS)
Yes
Differential Lock
  • Limited Slip Differential (LSD)
  • Electronic

Sensors

Parking Sensors
  • Front
  • Rear

Other Features

Anti-theft Alarm
Yes
Central Locking
Yes
Child Safety Locks
Yes
Anti-theft Alarm
Back-up Horn
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Knee Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes
