2016 Cadillac CT6

United StatesGasolineAWDSedan

Photos

Specifications

Vehicle Details

Year
2016
Make
Cadillac
Model
CT6
Body Style
Sedan
Generation
1st Generation
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Electrohydraulic), 8-speed

Powertrain

Engine Name
3.0 V6 TT AWD Hydra-Matic
Engine Configuration
V
Power (hp)
417 hp
Power (kW)
307 kW
Torque
555 Nm (409 lb-ft)
Top speed
250 km/h (155 mph)
0–60 mph
5.4 seconds (estimated)
0–100 km/h
5.7 seconds
Displacement
2,994 cc

Dimensions

Length
5,184 mm (204.1 in)
Width
1,879 mm (74.0 in)
Height
1,472 mm (58.0 in)
Wheelbase
3,109 mm (122.4 in)
Curb weight
1,879 kg (4,142 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,700 rpm
Rev. at Max Torque
1,400 - 5,100 rpm
Engine Fluids
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
10.6 litres
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
85.8 mm (3.4 in)
Compression Ratio
9.8 :1
Engine Configuration
V-Engine
Turbocharger
Twin-turbo
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
72,000 km / 4 years
Spark Plug
96,000 km (59,652 mi)
Brake Fluid
5 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Rear Axle, Oil
240,000 km (149,129 mi)
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 8-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.62 :1
2nd Gear
3.04 :1
3rd Gear
2.07 :1
4th Gear
1.66 :1
5th Gear
1.26 :1
6th Gear
1 :1
7th Gear
0.85 :1
8th Gear
0.66 :1
Final Drive
3.27 :1
Reverse
3.93 :1

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
345 mm (13.6 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 mm (12.4 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
73 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 6
Emission Class
E
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
13.2 - 1.6 litres / 100 km
Highway
7.4 - 7.5 litres / 100 km
Combined
9.6 - 9.8 litres / 100 km
Fuel Consumption EPA
City
20.8 MPG
Highway
37.7 MPG
Combined
28.8 MPG
Emission NEDC
CO₂, City
300 g/km
CO₂, Highway
170 g/km
CO₂, Combined
218 - 223 g/km

Dimensions & Weight

Exterior

Track, Front
1,610 mm (63.4 in)
Track, Rear
1,626 mm (64.0 in)
Turning Circle
11.3 m

Interior

Head Room, Front
1,020 mm (40.2 in)
Head Room, Rear
965 mm (38.0 in)
Leg Room, Front
1,074 mm (42.3 in)
Leg Room, Rear
1,027 mm (40.4 in)
Hip Room, Front
1,417 mm (55.8 in)
Hip Room, Rear
1,356 mm (53.4 in)
Shoulder Room, Front
1,481 mm (58.3 in)
Shoulder Room, Rear
1,425 mm (56.1 in)

Weight

Gross Weight
2,425 kg (5,346 lb)
Cargo Capacity
546 kg (1,204 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Omega Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Automatic Anti-glare
  • Driver side
  • Passenger side
User Memory
Yes
Heated
Yes
Turning Signal
Yes
Windscreen Wipers
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Noise Reducing Windows
  • Front
  • First Row
Sun Visors
Yes
Windows › Window Lifts, Features
One-touch up/down
  • Driver
  • Passenger
Windows › Sun Visors
Second Row Windows
Manual
Other Equipment
Sunroof
Panoramic (Openable (Electric))
Normal Roof
Yes
Other Equipment › Sunroof
Shading
Sun Blind

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
  • Automatic Headlight Activation
  • Main Beam Assist
Fog Lights
Rear
Yes
Special Features
Headlight Range Adjustment
Automatic

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Rim Material
Aluminium
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Coolant Temperature
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
8 - 12.3"
Instrument Cluster › Trip Computer › Display
Type
Colour
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Air Ionizer
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
  • DAB+
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
  • Phone
  • Audio
Cellular Network
4G
WiFi
Yes
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
10"
Center Display Controls
Touchscreen
Entertainment Screens
Optional
Displays › Center Display
Type
Colour
Displays › Entertainment Screens
Back of Headrest
Optional
Features
Active Noise Cancellation
Yes
Speakers
Total Number of Speakers
10 - 34 pcs
Speaker Brand
Bose
Rear-view Mirror
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
2
Lights
Read Light
  • Front
  • Rear
Guide Light
  • Entry Guard
  • Footwell (Front)
  • Door Handles (Exterior)
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Analogue
230V Outlet
Yes
Carpets
  • Front
  • Rear
Ashtray
Front
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Carpets
Material
Textile

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
  • User Memory
Rear-axle Steering
Optional
Material
Leather
Colour
Black
Multifunction Steering Wheel
Menu Navigation
Yes
Cruise Control
Yes
Media
Yes

Trunk

Rear Trunk
Yes
Automatic Open
Yes
Automatic Close
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
435 litres

Design

Interior Decor Material
Leather

Seats

Colour & Material
Upholstery
Leather (Perforated)
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Powered
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
4
Number of Driver Seat Adjustments, Powered
16 - 20
Power Seat, Driver
Yes
Heated Seats
  • Driver
  • Passenger
Ventilated Seats
  • Driver
  • Passenger
Front Seats › Power Seat, Driver
User Memory
Yes
Second Seat Row
Armrest
Yes
Features
Heated Seats
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Features
Ventilated Seats
Optional
Massage
Optional
Powered Seats
Optional
Second Seat Row › Headrests
Outer Seats
Yes
Centre Seat
Yes

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Garage Remote Control
Yes
Cruise Control
Yes
Cameras
Rear
Voice Control
Yes
Wireless Phone Charger
Yes
Cruise Control
Adaptive Cruise Control
Optional
Cameras
360° Camera
Yes
View Location
Center Display

Other Features

GPS
Navigation
Start & Stop
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Belt Load Limiter
  • Driver: Yes
  • Passenger: Yes
  • Rear: Yes

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Yes
Lane Assist System
Yes
Hill Start Assist (HSA)
Yes
Parking Assist
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes
Parking Assist
Autonomous
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
Pedestrian
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Yes
Pedestrian/Bicycle Detection
Yes
Light Sensor
Yes
Rain Sensors
Yes
Night Vision
Yes

Other Features

Central Locking
Remote
Child Safety Locks
Yes
Active Bonnet
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Knee Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes
