2016 Honda Civic

JapanDieselFWDWagon

Photos

Specifications

Vehicle Details

Year
2016
Make
Honda
Model
Civic
Body Style
Wagon
Generation
9th Generation
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
FWD
Transmission
Manual, 6-speed

Powertrain

Engine Name
Tourer 1.6 i-DTEC Manual
Engine Configuration
Inline
Power (hp)
120 hp
Power (kW)
88 kW
Torque
300 Nm (221 lb-ft)
Top speed
195 km/h (121 mph)
0–60 mph
9.8 seconds (estimated)
0–100 km/h
10.3 seconds
Displacement
1,597 cc

Dimensions

Length
4,535 mm (178.5 in)
Width
1,770 mm (69.7 in)
Height
1,480 mm (58.3 in)
Wheelbase
2,595 mm (102.2 in)
Curb weight
1,342 kg (2,959 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,000 rpm
Rev. at Max Torque
2,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 5W-30
Engine Oil, Volume
4.7 litres
Engine Configuration
Bore
76 mm (3.0 in)
Stroke
88 mm (3.5 in)
Compression Ratio
16 :1
Engine Configuration
Inline
Supercharger
Yes
Turbocharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Air Filter
60,000 km (37,282 mi)
Fuel Filter
60,000 km (37,282 mi)
Brake Fluid
3 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
100,000 km / 5 years
Interior Filter
40,000 km / 2 years

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 6
Emission Class
A+
Fuel Consumption NEDC
City
4.2 - 4.3 litres / 100 km
Highway
3.6 - 3.7 litres / 100 km
Combined
3.8 - 3.9 litres / 100 km
Emission NEDC
CO₂, Combined
99 - 103 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,065 mm (81.3 in)
Track, Front
1,540 mm (60.6 in)
Track, Rear
1,540 mm (60.6 in)
Turning Circle
11.24 m
Ground Clearance
145 mm (5.7 in)

Weight

Gross Weight
1,910 kg (4,211 lb)
Max Trailer Load, braked 12%
1,400 kg (3,086 lb)
Max Trailer Load, unbraked
500 kg (1,102 lb)
Cargo Capacity
568 kg (1,252 lb)
Max Roof Load
75 kg (165 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Turning Signal
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Yes
Antenna
Shark Fin
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Lights

Fog Lights
Yes
Fog Lights
Main Beam Assist
Optional

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
64.1
Fastening Type
Lug Nuts
Tightening Torque
108 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
Optional
Media Inputs
USB
App-Connect
Optional
Bluetooth
Optional
Connectivity › Radio
CD
Optional
MP3
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional

Steering Wheel

Multifunction Steering Wheel
Optional

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
624 litres
Volume, Back Seat Collapsed
1,668 litres

Seats

Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Second Seat Row
Collapsible
Yes

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Yes
Parking Heater
Optional
Parking Heater
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Rear Centre Seat Belt
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes
Sign Assist
Optional
Lane Departure Warning (LDW)
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Manual
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2012
Adult Occupant
94 %
Child Occupant
83 %
Vulnerable Road Users
69 %
Safety Assist
86 %
Overall
5/5 stars
Overall Score
36.03
ANCAP Safety Rating
5
ASEAN NCAP
Test Year
2013
Adult Occupant
5/5 stars
Adult Occupant, Points
14.63
Child Occupant
82 %
Adult Occupant
Frontal Offset
15.03
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
3
Teknikens Världs Moose Test
Test Year
2014
Speed
76 km/h (47 mph)

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car

ACRISS

Category
Compact (C)
Type
Wagon/Estate (W)
