2016 Kia Carens

South KoreaDieselFWDMinivan

Photos

Specifications

Vehicle Details

Year
2016
Make
Kia
Model
Carens
Body Style
Minivan
Generation
RP
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
FWD
Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 7-speed

Powertrain

Engine Name
1.7 CRDi
Engine Configuration
Inline
Power (hp)
141 hp
Power (kW)
104 kW
Torque
340 Nm (251 lb-ft)
Top speed
189 km/h (117 mph)
0–60 mph
9.9 seconds (estimated)
0–100 km/h
10.4 seconds
Displacement
1,685 cc

Dimensions

Length
4,525 mm (178.1 in)
Width
1,805 mm (71.1 in)
Height
1,610 mm (63.4 in)
Wheelbase
2,750 mm (108.3 in)
Curb weight
1,492 kg (3,289 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,000 rpm
Rev. at Max Torque
1,750 - 2,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
Semi-synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
5.3 litres
Engine Configuration
Bore
77.2 mm (3.0 in)
Stroke
90 mm (3.5 in)
Compression Ratio
15.7 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Air Filter
60,000 km / 4 years
Fuel Filter
60,000 km / 4 years
Oil Change & Engine Filter
30,000 km / 2 years
Engine Coolant
210,000 km / 10 years
Interior Filter
30,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 7-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Steel
Brake Caliper Colour
Grey
Front Brakes
Diameter
300 mm (11.8 in)
Cooling
Ventilated
Rear Brakes
Diameter
284 mm (11.2 in)
Cooling
Solid

Suspensions

Suspension, Front
Independent
MacPherson Strut

Fuel

General
Tank Volume
58 litres
Emission
Emission Standard
Euro 6
Fuel Consumption NEDC
City
5.3 – 5.7 litres / 100 km
Highway
4.3 – 4.5 litres / 100 km
Combined
4.8 litres / 100 km
Emission NEDC
CO₂, Combined
126 – 127 g/km

Dimensions & Weight

Exterior

Track, Front
1,570 mm (61.8 in)
Track, Rear
1,580 mm (62.2 in)
Turning Circle
10.9 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
960 - 1,050 mm (37.8 - 41.3 in)
Head Room, Rear
980 mm (38.6 in)
Leg Room, Front
1,034 mm (40.7 in)
Leg Room, Rear
940 mm (37.0 in)
Shoulder Room, Front
1,470 mm (57.9 in)
Shoulder Room, Rear
1,485 mm (58.5 in)

Weight

Gross Weight
2110 – 2130 kg (4,652 – 4,696 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
618 kg (1,362 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Hyundai-Kia Platforms
J Platform (J5)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Turning Signal
Optional
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Roof Railing
Optional
Spoiler
Fixed
Antenna
Whip
Electric
Optional

Lights

Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes
Fog Lights › Front
Cornering Lights
Yes

Colour

Finish
Solid

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
88 - 107 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Number of Climate Zones
1
Air Condition
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Refrigerant, Capacity
550 g
Connectivity
Radio
  • AM
  • FM
Media Format
  • CD
  • MP3
  • WMA
Media Inputs
USB
Bluetooth
Yes
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Other Equipment
Clock
Digital
Ashtray
Optional

Steering Wheel

Multifunction Steering Wheel
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
100 litres
Volume, Back Seat Collapsed
1,820 litres
Depth
1,004 mm (39.5 in)
Depth, Back Seat Collapsed
1,812 mm (71.3 in)
Width
1,084 mm (42.7 in)
Width, Between Wheel Arches
1,052 mm (41.4 in)
Height
787 mm (31.0 in)
Sill Height
682 mm (26.9 in)

Seats

Front Seats
Heated Seats
Optional
Second Seat Row
Collapsible
Yes
Third/Fourth Seat Row
Third Seat Row
Optional

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Yes
Cruise Control
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Rear
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Manual
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2013
Adult Occupant
94 %
Child Occupant
76 %
Vulnerable Road Users
64 %
Safety Assist
81 %
Overall
5/5 stars
Overall Score
36.2
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
15.2
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
3

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
7 years
12V Battery
2 years
Paintwork
150,000 km / 5 years
Rust Damage
150,000 km / 7 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
150,000 km (93,206 mi)

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
MPV
British Classification
Compact MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Medium MPV

Spare Parts BETA

Bulb Types
Low Beam
  • D3S (xenon)
  • H7
Main Beam
H7
Fog Light, Front
H8
Fog Light, Rear
BA15s (P21W)
Cornering Light
H7
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (WY5W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Type
Passenger Van (V)
