2017 Cadillac XT5

United StatesGasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2017
Make
Cadillac
Model
XT5
Body Style
SUV
Generation
1st Generation
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Electrohydraulic), 8-speed

Powertrain

Engine Name
3.6 V6 AFM AWD Automatic
Engine Configuration
V
Power (hp)
314 hp
Power (kW)
231 kW
Torque
368 Nm (271 lb-ft)
Displacement
3,649 cc

Dimensions

Length
4,813 mm (189.5 in)
Width
1,905 mm (75.0 in)
Height
1,676 mm (66.0 in)
Wheelbase
2,857 mm (112.5 in)
Curb weight
1,931 kg (4,257 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,600 rpm
Rev. at Max Torque
5,000 rpm
Redline
7,200 rpm
Engine Fluids
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
11.4 litres
Engine Configuration
Bore
95 mm (3.7 in)
Stroke
85.6 mm (3.4 in)
Compression Ratio
11.5 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
72,000 km / 4 years
Spark Plug
156,000 km (96,934 mi)
Brake Fluid
5 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 8-speed
Gear Selector
Joystick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
5.25 :1
2nd Gear
3.23 :1
3rd Gear
1.95 :1
4th Gear
1.45 :1
5th Gear
1.22 :1
6th Gear
1 :1
7th Gear
0.81 :1
8th Gear
0.67 :1
Final Drive
3.2 :1
Reverse
4.01 :1

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
345 mm (13.6 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 mm (12.4 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
82 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Control
  • Catalyst
  • Adaptive Cylinder Management
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption EPA
City
18 MPG
Highway
25 MPG

Dimensions & Weight

Exterior

Track, Front
1,636 mm (64.4 in)
Track, Rear
1,636 mm (64.4 in)
Overhang, Front
987 mm (38.9 in)
Overhang, Rear
971 mm (38.2 in)
Turning Circle
11.8 m
Ground Clearance
200 mm (7.9 in)

Interior

Head Room, Front
1,009 mm (39.7 in)
Head Room, Rear
976 mm (38.4 in)
Leg Room, Front
1,046 mm (41.2 in)
Leg Room, Rear
1,004 mm (39.5 in)
Hip Room, Front
1,424 mm (56.1 in)
Hip Room, Rear
1,391 mm (54.8 in)
Shoulder Room, Front
1,482 mm (58.3 in)
Shoulder Room, Rear
1,429 mm (56.3 in)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Epsilon Platform (C1XX)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Side Mirrors › Adjustments
Driver side
Optional
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Roof Railing
Yes
Spoiler
Yes

Lights

Rear Lights
LED
Daytime Running Light
LED

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
6 pcs
Bolt Distance
120
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.9
Fastening Type
Lug Nuts
Tightening Torque
190 Nm
Spare Wheel
Yes

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Compass
Yes
Instrument Cluster › Trip Computer
Display
5.7"
Climate Control
Climate Control
Automatic
Micro Filter
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
CD
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Phone
Connectivity › Media Inputs
USB
Yes
Connectivity › Media Inputs › USB
Number of Ports
2 pcs
Displays
Center Display
8"
Center Display Controls
Touchscreen
Speakers
Total Number of Speakers
8 pcs
Speaker Brand
Bose
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Yes
Material
Leather
Volume
Yes
Mute Audio
Yes
Multifunction Steering Wheel
Cruise Control
Yes

Trunk

Rear Trunk
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
849 litres
Volume, Back Seat Collapsed
1,784 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Front Seats
Power Seat, Driver
Optional
Armrest
Yes
Second Seat Row
Collapsible
Yes

Features

Comfort Features

Keyless Entry
Yes
Remote Engine Start
Yes
Cruise Control
Yes
Cameras
Rear

Other Features

Start & Stop
Yes

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Hill Start Assist (HSA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Pedestrian/Bicycle Detection
Optional

Other Features

Anti-theft Alarm
Optional
Central Locking
Yes
Collision Avoidance System
Optional

Safety Testing

General
Not Tested by Euro NCAP
Yes
IIHS
Test Year
2017
Small Overlap Front: Driver Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag

Other

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV
