2017 Chevrolet City Express

United StatesGasolineFWDLCV

Photos

Specifications

Vehicle Details

Year
2017
Make
Chevrolet
Model
City Express
Body Style
LCV
Generation
1st Generation
Seats
2
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic (Continuously variable)

Powertrain

Engine Name
2.0 XTRONIC-CVT
Engine Configuration
Inline
Power (hp)
133 hp
Power (kW)
98 kW
Torque
187 Nm (138 lb-ft)
Displacement
1,997 cc

Dimensions

Length
4,732 mm (186.3 in)
Width
1,730 mm (68.1 in)
Height
1,872 mm (73.7 in)
Wheelbase
2,925 mm (115.2 in)
Curb weight
1,483 kg (3,269 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,200 rpm
Rev. at Max Torque
4,800 rpm
Redline
6,400 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
4.4 litres
Engine Coolant, Volume
7.6 litres
Car Battery
Voltage
12 V
Battery Capacity
55 Ah
Cold Start Power
600 - 750 A
Alternator Charge Current
150 A
Alternator Voltage
14 V
Engine Configuration
Bore
84 mm (3.3 in)
Stroke
90.1 mm (3.5 in)
Compression Ratio
9.7 :1
Engine Configuration
Inline
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
48,000 km / 3 years
Spark Plug
168,000 km (104,390 mi)
Brake Fluid
32,000 km / 2 years
Engine Coolant
168,000 km / 10 years
Transmission, Fluid
96,000 km (59,652 mi)

Transmission & Drivetrain

Transmission
Automatic (Continuously variable)
Gear Selector
Stick
Gear Selector Location
Dashboard (Right of Steering Wheel)
Gear Ratio
Final Drive
4.83 :1
Reverse
0.75 :1

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Brake Caliper Pistons
Front (1)
Brakes Material
Steel
Front Brakes
Diameter
283 mm (11.1 in)
Width
28 mm (1.1 in)
Cooling
Ventilated
Rear Brakes
Diameter
228 mm (9.0 in)

Suspensions

Spring, Front
Coil
Spring, Rear
Leaf (Longitudinal Spring)
Anti-roll Bar
Front
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Dependent
Beam Axle (Dead Axle)

Fuel

General
Tank Volume
55 litres
General › Fuel Cap Position
Front
Right
B-Pillar
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption EPA
City
24 MPG
Highway
26 MPG
Combined
25 MPG

Dimensions & Weight

Exterior

Track, Front
1,524 mm (60.0 in)
Track, Rear
1,519 mm (59.8 in)
Approach Angle
17.3 °
Departure Angle
24.8 °
Turning Circle
11.2 m
Ground Clearance
155 mm (6.1 in)

Interior

Head Room, Front
1,059 mm (41.7 in)
Leg Room, Front
1,082 mm (42.6 in)
Hip Room, Front
1,303 mm (51.3 in)
Shoulder Room, Front
1,374 mm (54.1 in)

Weight

Gross Weight
2,155 kg (4,751 lb)
Cargo Capacity
680 kg (1,499 lb)

LCV Specific

General
Version
L1H1
Cargo Space › Cargo Volume
L1H1
3,475 litres
Cargo Space › Depth
L1
2,103 mm (82.8 in)
Cargo Space › Height
H1
1,346 mm (53.0 in)
Cargo Space
Space Width
1,392 mm (54.8 in)
Cargo Space › Space Width, Between Wheel Arches
L1
1,219 mm (48.0 in)

Exterior

Chassis & Body

Chassis
Chassis
LCV (Panel Van)
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Sliding (Left | Right)
Door Handles
Pull-up

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Manual
Heated
Optional
Windscreen Wipers
Number of Wiper Speeds
2
Windows
Window Lifts, Front
Powered
Heated Windows
Optional
Tinted Windows
Optional
Windows › Window Lifts, Features
Pinch Protection
Yes
Windows › Heated Windows
Rear
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Optional
Antenna
Whip
Number of Exhaust Pipes
1

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen

Colour

Finish
Solid
Finish
Bumper
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Fastening Type
Lug Nuts
Tightening Torque
113 Nm
Rim Colour
Silver
Rim Type
Disc Wheel
Spare Wheel
  • Full-size (Steel)
  • Temporary

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Fuel Gauge
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Climate Control
Manual
Number of Climate Zones
1
Air Condition
Yes
Number of Vents, Front
4 pcs
Controls
  • Buttons
  • Faders
  • Rotary Dials
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Media Format
  • CD
  • MP3
  • WMA
Bluetooth
Optional
Connectivity › Radio
XM
Optional
Connectivity › Media Inputs
AUX
Yes
USB
USB-C
Connectivity › Media Inputs › USB
Number of Ports
1 pcs
Connectivity › Bluetooth
Phone
Optional
Audio
Optional
Displays
Center Display
5"
Displays › Center Display
Touchscreen
Optional
Speakers
Total Number of Speakers
2 pcs
Interior Storage › Storage Compartments
Glove Compartment
Yes
Under Seats
Front
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Other Equipment
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Clock
Digital
Center Display
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electro-hydraulic
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Material
Plastic
Colour
Black
Steering Ratio
18.3 :1
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Cargo Hooks
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
Two-parted Doors

Design

Interior Decor Material
Plastic
Transmission Knob Material
Plastic
Entry Guard Material
Plastic

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Lumbar Support
Manual
Headrest, Height
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
6
Number of Driver Seat Adjustments, Total
6
Number of Passenger Seat Adjustments, Manual
6
Number of Passenger Seat Adjustments, Total
6
Armrest
Driver
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Lumbar Support
Manual
Headrest, Height
Manual
Collapsible
Yes

Features

Comfort Features

Keyless Entry
Yes
Cruise Control
Optional
Cameras
Optional
Voice Control
Optional
Cameras
Rear
Optional
Voice Control
Media
Optional
Phone
Optional

Other Features

GPS
Optional

Accessories

Tool Kit and Jack
Yes
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
  • Yes
  • Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
  • Yes
  • Optional
Anti-theft Alarm
Interior Monitoring
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Curtain Airbag

Other

Warranty

Manufacturer
57,936 km / 3 years
Powertrain
96,561 km / 5 years
Rust Damage
160,934 km / 6 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
160,934 km / 5 years

Identification

VIN Location
Left Side Casing of Window
Yes
On-board Diagnostic, Port Location
Steering Wheel, Lower Left

Car Classification

American Classification
Cargo Van
British Classification
Van
Australian Classification
Van
European Segment
M-Segment
Car.info Classification
Cargo Van
