2015 Ram ProMaster City

United StatesGasolineFWDLCV

Photos

Specifications

Vehicle Details

Year
2015
Make
Ram
Model
ProMaster
Variant
City
Body Style
LCV
Generation
Type 636
Seats
2
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic (Electrohydraulic), 9-speed

Powertrain

Engine Name
2.4 Automatic
Engine Configuration
Inline
Power (hp)
181 hp
Power (kW)
133 kW
Torque
263 Nm (194 lb-ft)
Displacement
2,360 cc

Dimensions

Length
4,752 mm (187.1 in)
Width
1,831 mm (72.1 in)
Height
1,880 mm (74.0 in)
Wheelbase
3,109 mm (122.4 in)
Curb weight
1,592 kg (3,510 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,400 rpm
Rev. at Max Torque
3,800 rpm
Redline
6,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-20
Engine Oil, Volume
5.2 litres
Engine Coolant, Volume
6.8 litres
Engine Fluids › Engine Coolant
OAT
Mopar OEM Coolant (red)
Car Battery
Voltage
12 V
Cold Start Power
700 A
Alternator Charge Current
160 A
Alternator Voltage
14 V
Engine Configuration
Bore
88 mm (3.5 in)
Stroke
97 mm (3.8 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
48,000 km / 3 years
Spark Plug
160,000 km / 10 years
Brake Fluid
2 years
Oil Change & Engine Filter
16,000 km / 1 years
Engine Coolant
240,000 km / 10 years
Interior Filter
32,000 km / 2 years
Accessory Belt
240,000 km / 15 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 9-speed
Gear Selector
Stick
Gear Selector Location
Dashboard (Right of Steering Wheel)
Overdrive
Yes
Gear Ratio
1st Gear
4.7 :1
2nd Gear
2.84 :1
3rd Gear
1.9 :1
4th Gear
1.38 :1
5th Gear
1 :1
6th Gear
0.8 :1
7th Gear
0.69 :1
8th Gear
0.58 :1
9th Gear
0.47 :1
Final Drive
3.73 :1
Reverse
3.81 :1

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Brake Caliper Pistons
Front (1)
Brakes Material
Cast Iron
Front Brakes
Diameter
305 mm (12.0 in)
Width
28 mm (1.1 in)
Cooling
Ventilated
Rear Brakes
Diameter
254 mm (10.0 in)

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
Yes
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Double Wishbone
Anti-roll Bar
Front
26 mm (1.0 in)
Rear
16 mm (0.6 in)

Fuel

General
Tank Volume
60.6 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
11.2 litres / 100 km
Highway
8.1 litres / 100 km
Combined
9.8 litres / 100 km

Dimensions & Weight

Exterior

Width, with Mirrors
2,149 mm (84.6 in)
Track, Front
1,523 mm (60.0 in)
Track, Rear
1,548 mm (60.9 in)
Overhang, Front
903 mm (35.6 in)
Overhang, Rear
740 mm (29.1 in)
Approach Angle
13.3 °
Departure Angle
30.8 °
Turning Circle
12.8 m
Ground Clearance
131 mm (5.2 in)

Interior

Head Room, Front
1,169 mm (46.0 in)
Leg Room, Front
1,036 mm (40.8 in)
Hip Room, Front
1,340 mm (52.8 in)
Shoulder Room, Front
1,506 mm (59.3 in)

Weight

Gross Weight
2,447 kg (5,395 lb)
Max Trailer Load, braked 12%
907 kg (2,000 lb)
Max Trailer Load, unbraked
453 kg (999 lb)
Cargo Capacity
855 kg (1,885 lb)
Max Roof Load
68 kg (150 lb)
Max Towbar Download
91 kg (201 lb)

LCV Specific

General
Version
L1H1
Side Door › Side Door Height
H1
1,107 mm (43.6 in)
Side Door › Side Door Width
L1
655 mm (25.8 in)
Side Door › Ground to Door Height
L1H1
546 mm (21.5 in)
Rear Doors › Rear Doors Height
L1H1
1,204 mm (47.4 in)
Rear Doors
Rear Doors Width
1,234 mm (48.6 in)
Rear Doors › Sill Height
L1H1
592 mm (23.3 in)
Cargo Space › Cargo Volume
L1H1
3,710 litres
Cargo Space › Depth
L1
2,215 mm (87.2 in)
Cargo Space › Height
H1
1,316 mm (51.8 in)
Cargo Space
Space Width
1,534 mm (60.4 in)
Cargo Space › Space Width, Between Wheel Arches
L1
1,229 mm (48.4 in)

Exterior

Chassis & Body

Chassis
Chassis
LCV (Panel Van)
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Protective Moldings
Yes
Chassis › Protective Moldings
Sides
Mid-Strip
Colour
Non-Painted
Doors
Front Doors
Conventional
Rear Doors
Sliding (Left | Right)
Door Handles
Pull-out

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Manual
Heated
Optional
Turning Signal
Yes
Mirror Shape, Driver side
  • Flat
  • Spheric
Mirror Shape, Passenger side
  • Flat
  • Spheric
Windscreen Wipers
Number of Wiper Speeds
2
Rear Wiper
Optional
Rear Washer System
Optional
Windows
Window Lifts, Front
Powered
Heated Windows
Optional
Heat-Insulating Windows
  • Front
  • First Row
Tinted Windows
Optional
Rear Windows, Pop-out
Optional
Windows › Window Lifts, Features
Pinch Protection
Yes
Windows › Heated Windows
Rear
Optional
Windows › Tinted Windows
Rear Window
Optional
Windows › Rear Windows, Pop-out
Manual
Optional
Other Equipment
Roof Railing
Optional
Antenna
Whip
Number of Exhaust Pipes
1
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Optional
Special Features
Come Home/Leaving Lights

Colour

Bumper
Optional
Door Handles
Non-painted

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
98
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
58.1
Fastening Type
Lug Nuts
Tightening Torque
120 - 86 Nm
Rim Colour
Silver
Rim Type
Disc Wheel
Spare Wheel
Optional
Spare Wheel
Full-size
Optional
Spare Wheel › Full-size
Steel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Climate Control
Manual
Number of Climate Zones
1
Air Condition
Yes
Number of Vents, Front
4 pcs
Controls
  • Buttons
  • Rotary Dials
Climate Control › Air Condition
Refrigerant
HF01234yf
Connectivity
Radio
  • AM
  • FM
Media Format
MP3
Bluetooth
Optional
Cellular Network
4G
WiFi
Optional
Connectivity › Radio
XM
Optional
Connectivity › Media Inputs
AUX
Yes
USB
USB-C
Connectivity › Media Inputs › USB
Number of Ports
1 pcs
Connectivity › Bluetooth
Phone
Optional
Displays
Center Display
5"
Displays › Center Display
Colour
  • Yes
  • Optional
Displays › Center Display Controls
Touchscreen
  • Yes
  • Optional
Buttons
  • Yes
  • Optional
Displays › Center Display Controls › Buttons
Side of Screen
9 pcs
Speakers
Total Number of Speakers
4 pcs
Interior Storage › Storage Compartments
Glove Compartment
Lockable (Manual)
Door
  • Driver Side
  • Passenger Side
Total Number of Compartments
5 pcs
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
1
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Other Equipment
Make-up Mirror
Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Optional
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster
Other Equipment › 12V Outlet
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electro-hydraulic
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Number of Buttons
6 - 10 pcs
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Release Button
Yes
Cargo Hooks
Yes
Light
Yes
Hatch Opening Type
Two-parted Doors

Design

Interior Decor Material
Textile
Interior Decor Colour
Black
Transmission Knob Material
Plastic
Entry Guard Material
Plastic

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Manual
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
2 - 4
Number of Passenger Seat Adjustments, Manual
2 - 4
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
Driver
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Manual
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats › Heated Seats
Cushion
Optional
Number of Heat Levels
1
Front Seats › Heated Seats › Cushion
Backrest
Optional

Features

Comfort Features

Keyless Entry
Yes
Remote Engine Start
Optional
Cruise Control
Optional
Parking Heater
Optional
Cameras
  • Yes
  • Optional
Voice Control
  • Yes
  • Optional
Parking Heater
Engine Heater
Optional
Cameras
Rear
  • Yes
  • Optional
Cameras › Rear
Center Display
  • Yes
  • Optional
Voice Control
Media
  • Yes
  • Optional
Phone
  • Yes
  • Optional

Other Features

GPS
Optional
Smartphone App
Optional

Accessories

Tool Kit and Jack
Optional
Tire Repair Kit
Yes
Compressor
Yes
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Ski/Snowboard-bag
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes
Trailer Assist
Optional
Electronic Stability Control (ESC)
Roll Stability Control (RSC)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Differential Lock
Electronic

Sensors

Parking Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Yes
Child Safety Locks
Manual
Emergency Call
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Knee Airbag
Curtain Airbag

Other

Warranty

Powertrain
96,560 km / 5 years

Identification

VIN Location
Left Side Casing of Window
Yes
On-board Diagnostic, Port Location
Steering Wheel, Lower Left

Car Classification

American Classification
Cargo Van
British Classification
Van
Australian Classification
Van
European Segment
M-Segment
Car.info Classification
Cargo Van

Similar lcvs

Suggested vehicles
