2017 Ravon Nexia R3

UzbekistanGasolineFWDSedan

Specifications

Vehicle Details

Year
2017
Make
Ravon
Model
Nexia R3
Body Style
Sedan
Generation
1st Generation
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 5
  • 6-speed

Powertrain

Engine Name
1.5
Engine Configuration
Inline
Power (hp)
106 hp
Power (kW)
78 kW
Torque
141 Nm (104 lb-ft)
Top speed
178 km/h (111 mph)
0–60 mph
11.6 seconds (estimated)
0–100 km/h
12.2 seconds
Displacement
1,485 cc

Dimensions

Length
4,330 mm (170.5 in)
Width
1,690 mm (66.5 in)
Height
1,505 mm (59.3 in)
Wheelbase
2,480 mm (97.6 in)
Curb weight
1,090 kg (2,403 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,800 rpm
Rev. at Max Torque
3,800 rpm
Engine Configuration
Bore
74.7 mm (2.9 in)
Stroke
84.7 mm (3.3 in)
Compression Ratio
10.2 :1
Engine Configuration
Inline
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Fuel Injection
Camshaft Type
DOHC

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 5
  • 6-speed
Gear Ratio
1st Gear
3.73 – 4.45 :1
2nd Gear
1.95 – 2.91 :1
3rd Gear
1.28 – 1.89 :1
4th Gear
0.97 – 1.45 :1
5th Gear
0.76 – 1 :1
6th Gear
0.74 :1
Final Drive
3.72 – 4.18 :1
Reverse
2.87 – 3.55 :1

Fuel

General
Tank Volume
45 litres
Emission
Emission Standard
Euro 5
Fuel Consumption NEDC
City
8 – 9.3 litres / 100 km
Combined
6.5 – 7 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,454 mm (57.2 in)
Track, Rear
1,444 mm (56.9 in)
Turning Circle
10.06 m

Weight

Gross Weight
1560 – 1585 kg (3,439 – 3,494 lb)
Cargo Capacity
470 kg (1,036 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Doors
Front Doors
Conventional

Equipment

Other Equipment
Number of Exhaust Pipes
1

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
56.6
Fastening Type
Lug Nuts

Interior

Steering Wheel

Steering Ratio
15.2 :1

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
400 litres
Volume, Back Seat Collapsed
980 litres

Other

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car
