2017 Volkswagen Tiguan

GermanyGasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2017
Make
Volkswagen
Model
Tiguan
Body Style
SUV
Generation
II (Type BW/BJ)
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Dual-clutch), 7-speed

Powertrain

Engine Name
2.0 TSI 4Motion DSG Sequential
Engine Configuration
Inline
Power (hp)
220 hp
Power (kW)
162 kW
Torque
350 Nm (258 lb-ft)
Top speed
223 km/h (139 mph)
0–60 mph
6.5 seconds (estimated)
0–100 km/h
6.8 seconds
Displacement
1,984 cc

Dimensions

Length
4,705 mm (185.2 in)
Width
1,859 mm (73.2 in)
Height
1,658 mm (65.3 in)
Wheelbase
2,790 mm (109.8 in)
Curb weight
1,796 kg (3,960 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,300 - 6,200 rpm
Rev. at Max Torque
1,600 - 4,200 rpm
Engine Fluids
Engine Oil, Volume
5.7 litres
Engine Configuration
Bore
82.5 mm (3.2 in)
Stroke
92.8 mm (3.7 in)
Compression Ratio
9.6 :1
Engine Configuration
Inline
Turbocharger
Single-turbo
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic (Dual-clutch), 7-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console

Fuel

General
Tank Volume
60 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Performance

Acceleration
0-80 km/h
4.9 sec

Dimensions & Weight

Exterior

Width, with Mirrors
2,099 mm (82.6 in)
Height (Bonnet Open)
1,815 mm (71.5 in)
Track, Front
1,585 mm (62.4 in)
Track, Rear
1,574 mm (62.0 in)
Turning Circle
11.9 m
Ground Clearance
201 mm (7.9 in)

Weight

Gross Weight
2,440 kg (5,379 lb)
Max Trailer Load, braked 12%
2,300 kg (5,071 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Gross Train Weight
4,740 kg (10,450 lb)
Cargo Capacity
644 kg (1,420 lb)
Permitted Axle Load, front
1,170 kg (2,579 lb)
Permitted Axle Load, rear
1,320 kg (2,910 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Volkswagen Group
MQB A2

Interior

Steering Wheel

Power Steering
Electro-mechanical
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Hatch Opening Type
From Roof
Rear Trunk
Trunk Door Opening Height
2,097 mm (82.6 in)

Seats

Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
