2021 Cadillac CT5

United StatesGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2021
Make
Cadillac
Model
CT5
Body Style
Sedan
Generation
1st Generation
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic (Electrohydraulic), 10-speed

Powertrain

Engine Name
550T Hydra-Matic
Engine Configuration
V
Power (hp)
340 hp
Power (kW)
250 kW
Torque
550 Nm (406 lb-ft)
Displacement
2,994 cc

Dimensions

Length
4,923 mm (193.8 in)
Width
1,882 mm (74.1 in)
Height
1,453 mm (57.2 in)
Wheelbase
2,946 mm (116.0 in)
Curb weight
1,660 kg (3,660 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,400 rpm
Rev. at Max Torque
2,350 - 4,000 rpm
Engine Fluids
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
12.1 litres
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
85.8 mm (3.4 in)
Compression Ratio
9.8 :1
Engine Configuration
V-Engine
Turbocharger
Twin-turbo
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
36,000 km / 2 years
Spark Plug
96,000 km (59,652 mi)
Brake Fluid
5 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Interior Filter
72,000 km / 4 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 10-speed
Gear Selector
Joystick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.7 :1
2nd Gear
2.99 :1
3rd Gear
2.15 :1
4th Gear
1.8 :1
5th Gear
1.52 :1
6th Gear
1.28 :1
7th Gear
1 :1
8th Gear
0.85 :1
9th Gear
0.69 :1
10th Gear
0.64 :1
Final Drive
2.85 :1
Reverse
4.87 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
321 - 345 mm (12.6 - 13.6 in)
Width
28 mm (1.1 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 mm (12.4 in)
Width
23 mm (0.9 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
66 litres
General › Fuel Cap Position
Rear
Right
Fuel Consumption EPA
City
19 MPG
Highway
27 MPG

Dimensions & Weight

Exterior

Width, with Mirrors
2,040 mm (80.3 in)
Track, Front
1,595 mm (62.8 in)
Track, Rear
1,623 mm (63.9 in)
Turning Circle
11.9 m

Interior

Head Room, Front
990 mm (39.0 in)
Head Room, Rear
930 mm (36.6 in)
Leg Room, Front
1,078 mm (42.4 in)
Leg Room, Rear
963 mm (37.9 in)
Hip Room, Front
1,365 mm (53.7 in)
Hip Room, Rear
1,365 mm (53.7 in)
Shoulder Room, Front
1,440 mm (56.7 in)
Shoulder Room, Rear
1,416 mm (55.7 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Alpha Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Other Equipment
Sunroof
Optional
Normal Roof
Yes

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
120
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.9
Central Bore (CB), rear
66.9
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
190 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Climate Control
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
  • XM
  • HD Radio
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Yes
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Interior Storage › Storage Compartments
Glove Compartment
Yes
Back Pocket
Yes
Door
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Other Equipment
Clock
Digital
12V Outlet
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Multifunction Steering Wheel
Cruise Control
Yes
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
337 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Lumbar Support
Yes
Headrest, Height
Yes
Front Seats
Heated Seats
Optional
Second Seat Row
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Yes
Cameras
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Centre Rear Seat
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Central Locking
Remote
Child Safety Locks
Yes

Airbags

Feature
Frontal Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size Luxury Car
British Classification
Luxury Car
Australian Classification
Upper Large Car
European Segment
F-Segment
Car.info Classification
Luxury Car
