2021 Mazda CX-30

JapanGasolineAWDCrossover

Photos

Specifications

Vehicle Details

Year
2021
Make
Mazda
Model
CX-30
Body Style
Crossover
Generation
DM
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
2.5 SKYACTIV-G AWD Automatic
Power (hp)
260 hp
Power (kW)
191 kW
Displacement
2,488 cc

Dimensions

Length
4,395 mm (173.0 in)
Width
1,795 mm (70.7 in)
Height
1,540 mm (60.6 in)
Wheelbase
2,655 mm (104.5 in)

Engine & Performance

Engine

Service Intervals
Air Filter
60,000 km / 3 years
Spark Plug
120,000 km (74,565 mi)
Brake Fluid
40,000 km / 2 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
100,000 km / 5 years
Interior Filter
40,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Fuel

General › Fuel Cap Position
Rear
Left

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Torsion
Suspension, Front
Independent
MacPherson Strut

Dimensions & Weight

Exterior

Width, with Mirrors
2,040 mm (80.3 in)
Track, Front
1,565 mm (61.6 in)
Track, Rear
1,565 mm (61.6 in)
Overhang, Front
915 mm (36.0 in)
Overhang, Rear
825 mm (32.5 in)
Ground Clearance
175 mm (6.9 in)

Interior

Head Room, Front
967 mm (38.1 in)
Head Room, Rear
973 mm (38.3 in)
Leg Room, Rear
921 mm (36.3 in)
Hip Room, Front
1,388 mm (54.6 in)
Hip Room, Rear
1,352 mm (53.2 in)
Shoulder Room, Front
1,412 mm (55.6 in)
Shoulder Room, Rear
1,361 mm (53.6 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Archaic

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical (Automatic Parking Fold)
User Memory
Optional
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Side Mirrors › Folding
Driver side
Optional
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Normal Roof
Yes
Roof Railing
Optional
Spoiler
Fixed
Antenna
Glass-integrated

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
Halogen
Special Features
  • Main Beam Assist
  • Come Home/Leaving Lights
Special Features
Headlight Range Adjustment
Automatic

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Tightening Torque
108 - 147 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Oil Temperature
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Square
Climate Control
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
  • DAB
Media Format
  • MP3
  • WMA
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
  • Phone
  • Audio
Displays
Center Display
Yes
Speakers
Total Number of Speakers
8 - 12 pcs
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Sunglass Compartment
Yes
Door
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
  • Front
  • Rear
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Sport
Yes
Number of Spokes
3
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Menu Navigation
Buttons
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Automatic Open
Optional
Cover
Yes
Flat Surface
Yes
Hatch Through Rear Seats
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
430 litres
Volume, Back Seat Collapsed
1,406 litres
Depth
809 mm (31.9 in)
Opening Width
1,030 mm (40.6 in)
Height, to Trunk Cover
570 mm (22.4 in)
Sill Height
533 mm (21.0 in)

Design

Transmission Knob Material
Leather
Transmission Knob Material
Brown
Optional

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
Middle
Front Seats › Heated Seats
Cushion
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40

Features

Comfort Features

Keyless Entry
Optional
Cruise Control
Adaptive Cruise Control
Cameras
Optional
Media
Yes
Phone
Yes
Cameras
Rear
Optional

Other Features

GPS
Navigation
Start & Stop
Yes

Accessories

Fire Extinguisher
Optional
Warning Triangle
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Rear Cross-Traffic Alert (RCTA)
Optional
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Parking Assist
Yes
Sign Assist
Yes
Emergency Assist
Yes
Emergency Stop Signal (ESS)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes
Emergency Lane Keeping (ELK)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes
Differential Lock
Electronic
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Reverse
No
Pedestrian
Yes
Cyclist
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Pedestrian/Bicycle Detection
Yes
Driver Alertness Warning (DAW)
Yes
Light Sensor
Yes
Rain Sensors
Yes
Parking Sensors
Front
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Manual
Active Bonnet
No
Emergency Call
Yes
Speed Sensitive
Yes
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2019
Adult Occupant
99 %
Child Occupant
86 %
Vulnerable Road Users
80 %
Safety Assist
77 %
Overall
5/5 stars
IIHS
Test Year
2020
Award
Top Safety Pick
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Front Crash Prevention: Vehicle-to-pedestrian
Superior
Latch Ease of Use
Good

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Warranty

Manufacturer
100,000 km / 3 years
Paintwork
3 years
Rust Damage
12 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
1 years

Car Classification

American Classification
Subcompact SUV
European Segment
J-Segment JB-Segment
Car.info Classification
Small SUV

ACRISS

Type
Crossover (G)

Awards

Golden Steering Wheel
Small SUV
2019
