2021 Volkswagen Crafter e-Crafter

GermanyElectricFWDLCV

Specifications

Vehicle Details

Year
2021
Make
Volkswagen
Model
Crafter
Variant
e-Crafter
Body Style
LCV
Generation
Typ SY/SZ
Seats
2
Doors
4
Fuel
Electric
Drivetrain
FWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
e-Crafter Single Speed
Engine Configuration
Electric
Power (hp)
136 hp
Power (kW)
100 kW
Torque
290 Nm (214 lb-ft)
Top speed
90 km/h (56 mph)
Battery
35.8 kWh

Dimensions

Width
2,040 mm (80.3 in)
Curb weight
2,507 kg (5,527 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
3,300 - 17,100 rpm
Rev. at Max Torque
0 - 3,300 rpm
Car Battery
Voltage
12 V
Configuration Combustion
Engine Placement
Front
Configuration Electric
Type of Electric Car
Electric
Electric Engine Power
100 kW
Electric Engine Horsepower (Metric)
136 hp
Torque
290 Nm (214 lb-ft)
Battery Capacity, Gross
35.8 kWh
Number of Batterycells
264
Type of Battery
Li-ion
AC Charge Type
Single-phase
Charging Plugs
Type 2
Configuration Electric › Charge AC
Charge Time
17 h
Charge Power
2.3 kW
Configuration Electric › Charge DC
Charge Time, to 80%
45 min
Charge Power
40 kW

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front
  • Rear
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Leaf (Longitudinal Spring)
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Dependent
Beam Axle

Energy & Range

General
Lockable Fuel Cap
Yes
General › Fuel Cap Position
B-Pillar
Left
Fuel Consumption NEDC
Energy consumption
21.54 kWh/100km
Emission NEDC
CO₂, Combined
0 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,427 mm (95.6 in)
Overhang, Front
1,000 mm (39.4 in)
Ground Clearance
195 mm (7.7 in)

Weight

Gross Weight
3,500 kg (7,716 lb)
Permitted Axle Load, front
2,100 kg (4,630 lb)
Permitted Axle Load, rear
2,100 kg (4,630 lb)

LCV Specific

General
Version
  • L3H2
  • L3H3
  • L4H3
  • L4H4
  • L5H3
  • L5H4
Dimensions › Length
L3
5,986 mm (235.7 in)
L4
6,836 mm (269.1 in)
L5
7,391 mm (291.0 in)
Dimensions › Height
L3H2
2,355 mm (92.7 in)
L3H3
2,590 mm (102.0 in)
L4H3
2,590 mm (102.0 in)
L4H4
2,798 mm (110.2 in)
L5H3
2,590 mm (102.0 in)
L5H4
2,798 mm (110.2 in)
Dimensions › Wheel Base
L3
3,640 mm (143.3 in)
L4
4,490 mm (176.8 in)
L5
4,490 mm (176.8 in)
Dimensions › Overhang, Rear
L3
1,346 mm (53.0 in)
L4
1,346 mm (53.0 in)
L5
1,901 mm (74.8 in)
Dimensions
Ground Clearance (LCV)
  • 195
  • 195
  • 195
  • 195
  • 195
  • 195 mm (7.7 in)
Side Door › Side Door Height
H3
1,722 mm (67.8 in)
Side Door › Side Door Width
L3
1,311 mm (51.6 in)
L4
1,311 mm (51.6 in)
L5
1,311 mm (51.6 in)
Rear Doors › Rear Doors Height
H3
1,740 mm (68.5 in)
H4
1,840 mm (72.4 in)
Rear Doors
Rear Doors Width
1,552 mm (61.1 in)
Rear Doors › Sill Height
L3H2
570 mm (22.4 in)
L3H3
570 mm (22.4 in)
L4H3
570 mm (22.4 in)
L4H4
570 mm (22.4 in)
L5H3
570 mm (22.4 in)
L5H4
570 mm (22.4 in)
Cargo Space › Cargo Volume
L3H3
10,700 litres
L4H4
16,100 litres
L5H3
16,400 litres
L5H4
18,400 litres
Cargo Space › Depth
L3
3,201 mm (126.0 in)
L4
4,051 mm (159.5 in)
L5
4,606 mm (181.3 in)
Cargo Space › Height
H3
1,861 mm (73.3 in)
Cargo Space
Space Width
1,832 mm (72.1 in)
Cargo Space › Space Width, Between Wheel Arches
L3
1,380 mm (54.3 in)
L4
1,380 mm (54.3 in)
L5
1,380 mm (54.3 in)
Weight
Curb Weight
2507 kg (5,527 lb)
Weight › Cargo Capacity
L3H3
993 kg (2,189 lb)
Weight › Max Roof Load
H3
150 kg (331 lb)

Exterior

Chassis & Body

Chassis
Chassis
LCV
Pillars
A-B
Body Material
Steel
Roof Material
Steel
Protective Moldings
Yes
Chassis › Protective Moldings
Front
Bottom-Strip
Rear
Bottom-Strip
Sides
Mid-Strip
Colour
Non-Painted
Doors
Front Doors
Conventional
Rear Doors
Sliding (Right)
Door Handles
Pull-out

Equipment

Side Mirrors
Mirror Type
Conventional
Heated
Optional
Turning Signal
Yes
Mirror Shape, Driver side
Convex
Mirror Shape, Passenger side
Convex
Windscreen Wipers
Heated Washer Nozzles
Optional
Intermittent Control
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Heat-Insulating Windows
  • Front
  • First Row
Safety Glass
Yes
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
One-touch up/down
  • Driver
  • Passenger
Windows › Safety Glass
Front
Laminated
Side
Tempered
Other Equipment
Tow Hook
Optional
Roof Railing
Optional
Antenna
Glass-integrated
Mud Flaps
Optional
Other Equipment › Tow Hook
Front
Optional
Rear
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Fog Lights
Yes
Fog Lights
Rear
Yes
Special Features
Automatic Headlight Activation
Optional
Main Beam Assist
Optional
Come Home/Leaving Lights
Optional
Headlight Washers
Optional
Headlight Range Adjustment
Yes

Colour

Non-painted
Bumper (Front | Rear)
Door Handles
Non-painted

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Fastening Type
Lug Bolts
Tightening Torque
180 Nm
Rim Type
Disc Wheel
Spare Wheel
Optional
Tire Pressure Monitoring System (TPMS)
Direct
Optional
Spare Wheel
Full-size
Optional
Spare Wheel › Full-size
Steel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Air Condition
Optional
Pollen Filter
Optional
Outside Temperature Indicator
Optional
Controls
  • Buttons
  • Rotary Dials
Connectivity
Radio
Optional
Radio Preparation
Yes
App-Connect
Optional
Bluetooth
Optional
Cellular Network
Optional
Connectivity › Radio
AM
Optional
FM
Optional
DAB
Optional
Connectivity › Media Format
CD
Optional
Memory Card Reader
Optional
MP3
Optional
WMA
Optional
Connectivity › Media Format › Memory Card Reader
SD
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Connectivity › Media Inputs › USB
Front
Optional
USB-A
Optional
USB-C
Optional
Connectivity › App-Connect
Android Auto
Optional
Apple CarPlay
Optional
MirrorLink
Optional
Connectivity › Bluetooth
Phone
Optional
Audio
Optional
Connectivity › Cellular Network
4G
Optional
Connectivity › Cellular Network › 4G
3G
Optional
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Buttons
Optional
Speakers
Total Number of Speakers
2 - 6 pcs
Tweeters
2 pcs
Midrange Speakers
2 pcs
Bass Speakers
2 pcs
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Yes
Coin Holder
Optional
Card Holder
Optional
Under Seats
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Glove Compartment
Light
Optional
Lockable
Optional
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
4
Interior Storage › Cup Holders › Front
Placement
  • Left of Steering Wheel
  • Side of Glove Compartment
Lights
Read Light
Front
Guide Light
Entry Guard
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
230V Outlet
Optional
Carpets
Front
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Make-up Mirror
Make-up Light
Optional
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › 230V Outlet
Front
Optional
Other Equipment › Carpets
Colour
Black
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Heated
Optional
Power Steering
Electro-mechanical
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Light
Yes
Hatch Opening Type
Two-parted Doors
Rear Trunk
Width
1,832 mm (72.1 in)
Width, Between Wheel Arches
1,380 mm (54.3 in)

Design

Accent
Aluminium
Entry Guard Material
Plastic
Pedals
Standard
Colour
  • Black
  • Grey

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Optional
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Optional
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Optional
Front Seats
Heated Seats
Optional
Armrest
Optional
Dual Passenger Seat
Optional
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Heated Seats › Cushion
Backrest
Optional
Colour & Material
Seat Colour
Black
Stitching Colour
Black

Features

Comfort Features

Cruise Control
Optional
Speed Limiter
Optional
Parking Heater
Optional
Parking Heater Preparation
Optional
Cameras
Optional
Rear Camera Preparation
Optional
Voice Control
Optional
Parking Heater
Remote
Optional
Cameras
Rear
Optional
Voice Control
Media
Optional
Navigation
Optional
Phone
Optional

Other Features

GPS
Optional
GPS Preparation
Optional
Start & Stop
Yes
Horn
Dual Note
GPS
USB
Optional

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Yes
Compressor
Yes
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Parking Assist
Optional
Sign Assist
Optional
Trailer Assist
Optional
Trailer Stability Assist (TSA)
Optional
Emergency Stop Signal (ESS)
Yes
Crosswind Assist
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Optional
Driver Alertness Warning (DAW)
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Yes
Child Safety Locks
Optional
Child Safety Locks
Manual
Optional

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Other

Warranty

Manufacturer
2 years
EV Battery
160,000 km / 8 years

Car Classification

American Classification
Cargo Van
British Classification
Van
Australian Classification
Van
European Segment
M-Segment
Car.info Classification
Cargo Van

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H15
Datyime Running Light
H15
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BA15s (P21W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BAY9s (H21W)
Turn Indicators, Rear
BAU15s (PY21W)
Glove Compartment
W2.1×9.5d (W3W)
Read Light
SV8.5 (C5W)
Entry Light
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)

Similar lcvs

Suggested vehicles
