2023 Jeep Renegade

United StatesPlug In Hybrid GasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2023
Make
Jeep
Model
Renegade
Body Style
SUV
Generation
BU Facelift
Seats
5
Doors
5
Fuel
Plug In Hybrid Gasoline
Drivetrain
AWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
4XE Automatic
Engine Configuration
Inline
Power (hp)
190 hp
Power (kW)
140 kW
Torque
270 Nm (199 lb-ft)
Top speed
183 km/h (114 mph)
0–60 mph
7.5 seconds (estimated)
0–100 km/h
7.9 seconds
Electric range
40 km (25 mi)
Battery
11.4 kWh
Displacement
1,332 cc

Dimensions

Length
4,236 mm (166.8 in)
Width
1,805 mm (71.1 in)
Height
1,667 mm (65.6 in)
Wheelbase
2,570 mm (101.2 in)
Curb weight
1,860 kg (4,101 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
1,850 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-30
Engine Oil, Volume
4.5 litres
Configuration Combustion
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Belt
Type of Combustion Engine
Piston
Configuration Electric
Type of Electric Car
Plug-in Hybrid
Electric Engine Power
32 kW
Electric Engine Horsepower (Metric)
44 hp
Torque
270 Nm (199 lb-ft)
Battery Capacity, Gross
11.4 kWh
Type of Battery
Li-ion
AC Charge Type
Single-phase
Service Intervals
Oil Change & Engine Filter
15,000 km / 1 years
Interior Filter
30,000 km / 1 years

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
36.5 litres
Emission
Emission Standard
Euro 6d
Emission Class
A+
WLTP Consumption
Weighted, Combined
2.2 - 2.4 litres / 100 km
Electric Range
40.4 - 42.3 km (25 - 26 mi)
Fuel Consumption NEDC
Combined
1.9 litres / 100 km
Emission WLTP
CO₂, Weighted, Combined
47.7 - 52.8 g/km
Emission NEDC
CO₂, Combined
44 g/km

Dimensions & Weight

Exterior

Track, Front
1,541 mm (60.7 in)
Track, Rear
1,541 mm (60.7 in)
Turning Circle
11.07 m
Ground Clearance
160 - 166 mm (6.3 - 6.5 in)

Interior

Head Room, Front
990 - 1,044 mm (39.0 - 41.1 in)
Head Room, Rear
1,029 mm (40.5 in)
Leg Room, Front
1,047 mm (41.2 in)
Leg Room, Rear
892 mm (35.1 in)
Hip Room, Front
1,349 mm (53.1 in)
Hip Room, Rear
1,318 mm (51.9 in)
Shoulder Room, Front
1,420 mm (55.9 in)
Shoulder Room, Rear
1,400 mm (55.1 in)

Weight

Gross Weight
2,440 kg (5,379 lb)
Max Trailer Load, braked 12%
1,150 kg (2,535 lb)
Max Trailer Load, unbraked
600 kg (1,323 lb)
Cargo Capacity
580 kg (1,279 lb)
Max Roof Load
68 kg (150 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Fiat Platforms
Small Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Turning Signal
Yes
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Antenna
Whip
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Black

Lights

Special Features
Headlight Range Adjustment

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
110
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
65.1
Central Bore (CB), rear
65.1
Fastening Type
Lug Bolts
Tightening Torque
120 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Square
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
  • DAB
Media Format
  • MP3
  • WMA
Media Inputs
USB
Bluetooth
Yes
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
6 - 8 pcs
Speakers Max. Watt
560 W
Subwoofer
Optional
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable
Armrest Hatch
  • Front
  • Back
Back Pocket
Yes
Door
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
  • Front
  • Rear
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
Carpets
Yes
Ashtray
Yes

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electro-hydraulic
Adjustments
  • Tilt
  • Telescope
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Cargo Hooks
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
351 litres
Volume, Back Seat Collapsed
1,297 litres
Depth
787 mm (31.0 in)
Width
1,346 mm (53.0 in)
Width, Between Wheel Arches
1,062 mm (41.8 in)

Seats

Colour & Material
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats
Armrest
Middle
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes

Features

Comfort Features

Cruise Control
Yes

Other Features

GPS
Optional
Start & Stop
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Centre Rear Seat
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Sign Assist
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Optional
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote

Safety Testing

General
Test Year
2019
Adult Occupant
82 %
Child Occupant
84 %
Vulnerable Road Users
55 %
Safety Assist
58 %
Overall
3/5 stars
IIHS
Test Year
2020
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Acceptable
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
3 years
Rust Damage
7 years
EV Battery
160,000 km / 8 years
Roadside Assistance
Yes

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact SUV
British Classification
Mini 4x4
Australian Classification
Small SUV
European Segment
J-Segment JB-Segment
Car.info Classification
Small SUV

Spare Parts BETA

Bulb Types
Low Beam
  • D5S (xenon)
  • H4
Main Beam
H4
Bi-Xenon
D5S
Datyime Running Light
BAY15d (P21/5W)
Fog Light, Front
H11
Fog Light, Rear
W2.1×9.5d (W16W)
Rear/Brake Light
BA15s (P21W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
W2.1×9.5d (W16W)
Glove Compartment
W2.1×9.5d (W5W)
Read Light
SV8.5 (C5W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Type
Crossover (G)
