2024 Ford Kuga Hybrid AWD

United StatesHybrid Gasoline4WDSUV

Photos

Specifications

Vehicle Details

Year
2024
Make
Ford
Model
Kuga
Variant
Hybrid AWD
Body Style
SUV
Generation
MF Facelift
Seats
5
Doors
5
Fuel
Hybrid Gasoline
Drivetrain
4WD
Transmission
Automatic (Continuously variable)

Powertrain

Engine Name
Hybrid AWD E-CVT
Power (hp)
184 hp
Power (kW)
135 kW
Torque
280 Nm (207 lb-ft)
Top speed
196 km/h (122 mph)
0–60 mph
7.9 seconds (estimated)
0–100 km/h
8.3 seconds
Battery
1.1 kWh
Displacement
2,488 cc

Dimensions

Length
4,604 mm (181.3 in)
Width
1,882 mm (74.1 in)
Height
1,651 mm (65.0 in)
Wheelbase
2,711 mm (106.7 in)
Curb weight
1,765 kg (3,891 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
2,000 - 4,500 rpm
Configuration Combustion
Bore
89 mm (3.5 in)
Stroke
100 mm (3.9 in)
Compression Ratio
13 :1
Fuel System
Electronic (Direct | Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Configuration Electric
Type of Electric Car
Hybrid
Battery Capacity, Gross
1.1 kWh
Type of Battery
Li-ion

Transmission & Drivetrain

Transmission
Automatic (Continuously variable)

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front (2)
  • Rear (1)
Front Brakes
Diameter
308 - 330 mm (12.1 - 13.0 in)
Width
27 mm (1.1 in)
Cooling
Ventilated
Rear Brakes
Diameter
302 mm (11.9 in)
Width
11 mm (0.4 in)
Cooling
Solid

Suspensions

Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Fuel

General
Tank Volume
54 litres
Emission
Emission Standard
Euro 6d
WLTP Consumption
Combined (l/100km)
5.7 - 6.4 litres / 100 km
Emission WLTP
CO₂, Combined
130 - 146 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,177 mm (85.7 in)
Width, with Mirrors (folded)
2,000 mm (78.7 in)
Track, Front
1,599 mm (63.0 in)
Track, Rear
1,590 mm (62.6 in)
Approach Angle
20 °
Departure Angle
24.7 °
Turning Circle
11.38 m
Ground Clearance
152 - 191 mm (6.0 - 7.5 in)

Interior

Head Room, Front
1,021 mm (40.2 in)
Head Room, Rear
998 mm (39.3 in)
Leg Room, Front
1,076 mm (42.4 in)
Leg Room, Rear
986 - 1,035 mm (38.8 - 40.7 in)
Hip Room, Front
1,405 mm (55.3 in)
Hip Room, Rear
1,352 mm (53.2 in)
Shoulder Room, Front
1,464 mm (57.6 in)
Shoulder Room, Rear
1,423 mm (56.0 in)

Weight

Gross Weight
2,315 kg (5,104 lb)
Max Trailer Load, braked 12%
2,100 kg (4,630 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
550 kg (1,213 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Windscreen Wipers
Rear Wiper
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Other Equipment
Roof Railing
Yes
Antenna
Shark Fin
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Colour
Black

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
63.4
Central Bore (CB), rear
63.4
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
135 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Tachometer
Digital
Odometer Limit
1,000,000 km/miles
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Rear-view Mirror
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Lights
Read Light
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electro-mechanical
Adjustments
Tilt
Colour
Black
Steering Ratio
13.75 :1

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
435 litres
Depth
865 mm (34.1 in)
Depth, Back Seat Collapsed
1,688 mm (66.5 in)
Width, Between Wheel Arches
1,051 mm (41.4 in)
Opening Width
1,071 mm (42.2 in)
Height
885 mm (34.8 in)
Trunk Door Opening Height
773 mm (30.4 in)

Seats

Second Seat Row
Number of Seats
3
Type of Seat
Adult

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Belt Load Limiter
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Assist Systems

Electronic Stability Control (ESC)
Yes
Trailer Stability Assist (TSA)
Yes
Electronic Stability Control (ESC)
Roll Stability Control (RSC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Four-channel
Electronic Brakeforce Distribution (EBD)
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV
