2024 Renault Rafale E-TECH MultiMode

FranceHybrid Gasoline2WDSUV

Photos

Specifications

Vehicle Details

Year
2024
Make
Renault
Model
Rafale
Variant
E-TECH MultiMode
Body Style
SUV
Generation
1st Generation
Seats
5
Doors
5
Fuel
Hybrid Gasoline
Drivetrain
2WD
Transmission
Automatic (Sequential)

Powertrain

Engine Name
E-TECH MultiMode
Power (hp)
200 hp
Power (kW)
147 kW
Torque
205 Nm (151 lb-ft)
Top speed
180 km/h (112 mph)
0–60 mph
8.5 seconds (estimated)
0–100 km/h
8.9 seconds
Displacement
1,199 cc

Dimensions

Length
4,710 mm (185.4 in)
Width
1,860 mm (73.2 in)
Height
1,610 mm (63.4 in)
Wheelbase
2,740 mm (107.9 in)
Curb weight
1,653 kg (3,644 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,500 rpm
Rev. at Max Torque
1,750 rpm
Configuration Combustion
Turbocharger
Yes
Configuration Electric
Type of Electric Car
Hybrid
Front Engines
Yes

Transmission & Drivetrain

Transmission
Automatic (Sequential)

Fuel

General
Tank Volume
55 - 58 litres
Emission
Emission Standard
Euro 6 (Euro 6e)
WLTP Consumption
Combined (l/100km)
4.7 - 4.9 litres / 100 km
Emission WLTP
CO₂, Combined
105 - 107 g/km

Dimensions & Weight

Exterior

Overhang, Front
942 mm (37.1 in)
Overhang, Rear
1,029 mm (40.5 in)
Ground Clearance
180 mm (7.1 in)

Weight

Gross Weight
2,175 - 2,180 kg (4,795 - 4,806 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Cargo Capacity
522 kg (1,151 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV

Equipment

Other Equipment
Normal Roof
Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Indirect
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.1
Central Bore (CB), rear
66.1

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Cockpit
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Controls
Buttons
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
647 litres
Width
1,125 mm (44.3 in)

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Parking Assist
Optional
Emergency Assist
Yes
Emergency Stop Signal (ESS)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes
Emergency Lane Keeping (ELK)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes
Cyclist
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Child Safety Locks
Electrical
Immobiliser
Electronic
Yes
Anti-theft Alarm
Interior Monitoring
Yes

Safety Testing

General
Test Year
2022
Adult Occupant
87 %
Child Occupant
83 %
Vulnerable Road Users
69 %
Safety Assist
87 %
Overall
5/5 stars
Adult Occupant
Total Points
33.4 /38
Frontal Impact
13.4 /16
Lateral Impact
15.5 /16
Rear Impact
3.6 /4
Rescue and Extrication
1 /2
Child Occupant
Total Points
40.7 /49
Crash Test Performance
  • 15.5
  • 8 /16
Safety Features
6 /13
CRS Installation Check
11.3 /12
Vulnerable Road Users
Total Points
37.7 /49
Pedestrian
  • 14.1
  • 2.7
  • 6
AEB Pedestrian
7 /9
AEB Pedestrian (assesment)
Good
AEB Cyclist
7.9 /9
AEB Cyclist (assesment)
Good
Safety Assist
Speed Assistance (points)
2.4 /3
Speed Assistance (assesment)
Good
Occupant Status Monitoring (points)
3 /3
Occupant Status Monitoring (assesment)
Good
Seat Belt Reminder (points)
2 /2
Seat Belt Reminder (assesment)
Good
Driver Monitoring (points)
1
Driver Monitoring (assesment)
Poor
Lane Support (points)
3 /4
Lane Support (assesment)
Good
Emergency Lane Keeping (assesment)
Adequate
Lane Keep Assist (assesment)
Good
Human Machine Interface (assesment)
Good
AEB Car-to-Car (points)
5.5 /6
AEB Car-to-Car (assesment)
Good

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: Optional
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment JD-Segment
Car.info Classification
Large SUV
