2024 Kia EV5

South KoreaElectricFWDSUV

Photos

Specifications

Vehicle Details

Year
2024
Make
Kia
Model
EV5
Body Style
SUV
Generation
1st Generation
Seats
5
Doors
5
Fuel
Electric
Drivetrain
FWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
Standard Range
Engine Configuration
Electric
Power (hp)
218 hp
Power (kW)
160 kW
Torque
310 Nm (229 lb-ft)
Top speed
185 km/h (115 mph)
0–60 mph
8.1 seconds (estimated)
0–100 km/h
8.5 seconds
Electric range
490 km (304 mi)
Battery
64.2 kWh

Dimensions

Length
4,615 mm (181.7 in)
Width
1,875 mm (73.8 in)
Height
1,715 mm (67.5 in)
Wheelbase
2,750 mm (108.3 in)
Curb weight
1,870 kg (4,123 lb)

Engine & Performance

Engine

Engine Configuration
Type of Electric Car
Electric
Electric Engine Power
160 kW
Electric Engine Horsepower (Metric)
218 hp
Torque
310 Nm (229 lb-ft)
Battery Capacity, Gross
64.2 kWh

Energy & Range

Emission
Emission Class
A
Emission WLTP
CO₂, Combined
0 g/km
Fuel Consumption NEDC
Electric Range
490 km (304 mi)

Dimensions & Weight

Exterior

Overhang, Front
910 mm (35.8 in)
Overhang, Rear
955 mm (37.6 in)
Turning Circle
11.7 m
Ground Clearance
175 mm (6.9 in)

Interior

Head Room, Front
1,000 mm (39.4 in)
Head Room, Rear
960 mm (37.8 in)
Leg Room, Front
1,050 mm (41.3 in)
Leg Room, Rear
950 mm (37.4 in)

Weight

Gross Weight
2,320 kg (5,115 lb)
Max Trailer Load, braked 12%
300 kg (661 lb)
Max Trailer Load, unbraked
300 kg (661 lb)
Cargo Capacity
450 kg (992 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV

Equipment

Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Central Bore (CB), rear
67.1
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
107 - 127 Nm
Rim Material
Alloy

Interior

Trunk

Total Trunk Volume
580 litres
Rear Trunk
Yes
Front Trunk
Yes
Rear Trunk
Volume
513 litres
Volume, Back Seat Collapsed
1,713 litres
Depth
2,000 mm (78.7 in)
Width
1,343 mm (52.9 in)
Front Trunk
Volume
67 litres

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Sign Assist
Yes
Emergency Stop Signal (ESS)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Brake Energy Regeneration
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes
Cyclist
Yes

Sensors

Parking Sensors
  • Front
  • Rear
  • Side
Driver Alertness Warning (DAW)
Yes
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Central Locking
Remote
Active Bonnet
No
Emergency Call
Yes
Type of Keys
  • Keycards (NFC)
  • Smartphone as a Key
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2025
Adult Occupant
83 %
Child Occupant
85 %
Vulnerable Road Users
74 %
Safety Assist
80 %
Overall
5/5 stars
Adult Occupant
Total Points
33.3 /38
Frontal Impact
12.4 /16
Lateral Impact
14.9 /16
Rear Impact
4 /4
Rescue and Extrication
2 /2
Child Occupant
Total Points
42 /49
Crash Test Performance
  • 16
  • 8 /16
Safety Features
6 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Total Points
47.2 /49
Pedestrian
  • 10.5
  • 0.6
  • 8.9
AEB Pedestrian
5.7 /9
AEB Pedestrian (assesment)
Adequate
AEB Cyclist
7.3 /9
AEB Cyclist (assesment)
Good
Safety Assist
Speed Assistance (points)
2.2 /3
Speed Assistance (assesment)
Adequate
Occupant Status Monitoring (points)
2.2 /3
Occupant Status Monitoring (assesment)
Adequate
Seat Belt Reminder (points)
0.7 /2
Seat Belt Reminder (assesment)
Adequate
Driver Monitoring (points)
1.5
Driver Monitoring (assesment)
Good
Lane Support (points)
3 /4
Lane Support (assesment)
Good
Emergency Lane Keeping (assesment)
Good
Lane Keep Assist (assesment)
Good
Human Machine Interface (assesment)
Good
AEB Car-to-Car (points)
7 /6
AEB Car-to-Car (assesment)
Good

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV
