2024 Maxus e-Deliver 5

ChinaElectricFWDLCV

Photos

Specifications

Vehicle Details

Year
2024
Make
Maxus
Model
e-Deliver 5
Body Style
LCV
Generation
1st Generation
Seats
2
Doors
4
Fuel
Electric
Drivetrain
FWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
64 kWh Single Speed
Engine Configuration
Electric
Power (hp)
163 hp
Power (kW)
120 kW
Torque
240 Nm (177 lb-ft)
Top speed
120 km/h (75 mph)
Electric range
335 km (208 mi)
Battery
64 kWh

Dimensions

Length
4,800 mm (189.0 in)
Width
1,874 mm (73.8 in)
Height
1,960 mm (77.2 in)
Wheelbase
3,100 mm (122.0 in)
Curb weight
1,850 kg (4,079 lb)

Engine & Performance

Engine

Engine Configuration
Type of Electric Car
Electric
Electric Engine Power
120 kW
Electric Engine Horsepower (Metric)
163 hp
Torque
240 Nm (177 lb-ft)
Battery Capacity, Gross
64 kWh
Type of Battery
LFP (Li-IP)
Vehicle to Load (V2L)
Yes
Engine Configuration › Charge AC
Charge Time
7.5 h / 450 min
Charge Power
11 kW
Engine Configuration › Charge DC
Charge Time, to 80%
42 min
Charge Power
70 kW
Engine Configuration › Vehicle to Load (V2L)
Max Discharge Power
6.6 kW

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes

Suspensions

Spring, Front
Coil
Spring, Rear
Leaf (Longitudinal Spring)
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Dependent
Yes

Energy & Range

WLTP Consumption
Energy consumption
21 kWh/100km
Electric Range
335 km (208 mi)
Fuel Consumption NEDC
Combined
0 litres / 100 km
Emission WLTP
CO₂, Combined
0 g/km
Emission NEDC
CO₂, Combined
0 g/km

Dimensions & Weight

Exterior

Track, Front
1,650 mm (65.0 in)
Track, Rear
1,650 mm (65.0 in)
Overhang, Front
650 mm (25.6 in)
Overhang, Rear
1,050 mm (41.3 in)
Turning Circle
11.5 m
Ground Clearance
146 mm (5.7 in)

Weight

Gross Weight
3,050 kg (6,724 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
1,200 kg (2,646 lb)

LCV Specific

General
Version
L1H1
Side Door › Side Door Height
H1
1,243 mm (48.9 in)
Side Door › Side Door Width
L1
873 mm (34.4 in)
Cargo Space › Cargo Volume
L1H1
6,600 litres

Exterior

Chassis & Body

Chassis
Chassis
LCV
Doors
Front Doors
Conventional
Rear Doors
Sliding (Left | Right)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Manual
Heated
Yes
Windows
Window Lifts, Front
Powered
Windows › Window Lifts, Features
One-touch up/down
  • Driver
  • Passenger

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
Halogen
Fog Lights
Yes
Special Features
Main Beam Assist
Fog Lights
Rear
Halogen

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes

Interior

Equipment

Connectivity
Radio
  • AM
  • FM
  • DAB
App-Connect
  • Android Auto
  • Apple CarPlay (Wireless)
Bluetooth
  • Phone
  • Audio
Connectivity › Media Inputs
USB
Yes
Connectivity › Media Inputs › USB
Placement
Front
Displays
Center Display
12.3"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
2 pcs
Climate Control
Climate Control
Manual
Number of Climate Zones
1
Air Condition
Yes
Climate Control › Air Condition
Refrigerant
R1234yf
Refrigerant, Capacity
450 g
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Manual
Rear-view Mirror: Mirror Type
Standard
Lights
Read Light
Front
Other Equipment
12V Outlet
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Number of Spokes
2
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Buttons
Mute Audio
Yes

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
6
Number of Passenger Seat Adjustments, Manual
6
Heated Seats
  • Driver
  • Passenger
Dual Passenger Seat
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Optional
Seat Height
Optional
Backrest Angle
Optional

Trunk

Rear Trunk
Yes
Light
Yes
Rear Trunk
Depth
2,654 mm (104.5 in)
Width
1,704 mm (67.1 in)
Width, Between Wheel Arches
1,250 mm (49.2 in)
Height
1,455 mm (57.3 in)

Features

Comfort Features

Cruise Control
Adaptive Cruise Control
Cameras
  • Front
  • Sides
  • Rear
Cameras
360° Camera
Yes
View Location
Center Display

Other Features

Horn
Single Note

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Lane Assist System
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes
Emergency Lane Keeping (ELK)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes

Sensors

Parking Sensors
Rear

Other Features

Emergency Call
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag

Seat Belt

Belt Load Limiter
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Car Classification

European Segment
M-Segment
Car.info Classification
Cargo Van (Light)
