2024 Zeekr 009

ChinaElectricAWDMinivan

Photos

Specifications

Vehicle Details

Year
2024
Make
Zeekr
Model
009
Body Style
Minivan
Generation
1st Generation
Seats
6
Doors
5
Fuel
Electric
Drivetrain
AWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
116 kWh AWD Single Speed
Engine Configuration
Electric
Power (hp)
544 hp
Power (kW)
400 kW
Torque
686 Nm (506 lb-ft)
Top speed
190 km/h (118 mph)
0–60 mph
4.3 seconds (estimated)
0–100 km/h
4.5 seconds
Electric range
702 km (436 mi)
Battery
116 kWh

Dimensions

Length
5,209 mm (205.1 in)
Width
2,024 mm (79.7 in)
Height
1,848 mm (72.8 in)
Wheelbase
3,205 mm (126.2 in)
Curb weight
2,830 kg (6,239 lb)

Engine & Performance

Engine

Engine Configuration
Type of Electric Car
Electric
Electric Engine Power
400 kW
Electric Engine Horsepower (Metric)
544 hp
Torque
686 Nm (506 lb-ft)
Front Engines
Yes
Rear Engines
Yes
Battery Capacity, Gross
116 kWh
Type of Battery
Li-ion
Charging Plugs
GB/T
Engine Configuration › Front Engines
Power (kW)
200 kW
Horsepower
272 hp
Number of Engines
1
Engine Configuration › Rear Engines
Electric Power (kW)
200 kW
Horsepower
272 hp
Number of Engines
1
Engine Configuration › Charge DC
Charge Time, to 80%
0.47 h / 28 min

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Multi-link
Anti-roll Bar
  • Front
  • Rear

Energy & Range

Emission
Emission Class
A
WLTP Consumption
Energy consumption
18.3 kWh/100km
Electric Range
702 km (436 mi)
Fuel Consumption NEDC
Combined
0 litres / 100 km
Emission WLTP
CO₂, Combined
0 g/km
Emission NEDC
CO₂, Combined
0 g/km

Dimensions & Weight

Exterior

Track, Front
1,701 mm (67.0 in)
Track, Rear
1,713 mm (67.4 in)
Ground Clearance
139 mm (5.5 in)

Interior

Leg Room (est.), Rear
1,030 - 1,100 mm (40.6 - 43.3 in)
Leg Room (est.), Third Row
845 mm (33.3 in)

Weight

Gross Weight
3,320 kg (7,319 lb)
Cargo Capacity
490 kg (1,080 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Sliding
Platform
Geely Holding
SEA (SEA1)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical (Automatic Parking Fold)
Automatic Anti-glare
  • Driver side
  • Passenger side
User Memory
Yes
Windscreen Wipers
Intermittent Control
Yes
Rear Wiper
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
  • Rear
One-touch up/down
  • Driver
  • Passenger
  • Rear

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Special Features
  • Main Beam Assist
  • Adaptive Headlights

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Rim Type
Disc Wheel

Interior

Equipment

Connectivity
Radio
  • AM
  • FM
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
  • Phone
  • Audio
Cellular Network
  • 5G
  • 4G
WiFi
Yes
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Climate Control
Climate Control
Automatic
Air Condition
Yes
Micro Filter
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Lights
Read Light
  • Front
  • Rear
Guide Light
Entry Guard
Ambient Light
Yes
Selectable Light Colour
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
User Memory
Multifunction Steering Wheel
Media
Yes
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Automatic Open
Yes
Automatic Close
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
376 litres
Volume, Back Seat Collapsed
2,979 litres

Seats

Third/Fourth Seat Row
Third Seat Row
Yes

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Collision Warning (RCW)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Sign Assist
Yes
Emergency Stop Signal (ESS)
Yes
Electronic Stability Control (ESC)
Roll Stability Control (RSC)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes
Emergency Lane Keeping (ELK)
Yes
Active Lane Change
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Cornering Brake Control (CBC)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Yes
Door Open Warning
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Central Locking
  • Remote
  • Auto Lock
Emergency Call
Yes
Immobiliser
Electronic
Yes

Other

Warranty

EV Battery
200,000 km / 8 years

Car Classification

European Segment
M-Segment
Car.info Classification
Large MPV
