2009 Daihatsu Terios

JapanGasoline4WDMinivan

Photos

Specifications

Vehicle Details

Year
2009
Make
Daihatsu
Model
Terios
Body Style
Minivan
Generation
J200 Facelift
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
4WD
Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Powertrain

Engine Name
1.5 DVVT 4WD
Engine Configuration
Inline
Power (hp)
105 hp
Power (kW)
77 kW
Torque
140 Nm (103 lb-ft)
Top speed
150 km/h (93 mph)
0–60 mph
11.8 seconds (estimated)
0–100 km/h
12.4 seconds
Displacement
1,495 cc

Dimensions

Length
4,095 mm (161.2 in)
Width
1,695 mm (66.7 in)
Height
1,680 mm (66.1 in)
Wheelbase
2,580 mm (101.6 in)
Curb weight
1,225 kg (2,701 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,400 rpm
Engine Configuration
Bore
72 mm (2.8 in)
Stroke
91.8 mm (3.6 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Fuel Injection
Service Intervals
Air Filter
45,000 km / 3 years
Spark Plug
90,000 km (55,923 mi)
Brake Fluid
2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
2 years
Transmission, Fluid
90,000 km / 6 years
Transmission, Fluid Filter
90,000 km / 6 years
Rear Axle, Oil
90,000 km (55,923 mi)

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 5
Fuel Consumption NEDC
City
9.5 – 9.7 litres / 100 km
Highway
6.6 litres / 100 km
Combined
7.7 litres / 100 km
Emission NEDC
CO₂, Combined
179 – 181 g/km

Dimensions & Weight

Exterior

Track, Front
1,450 mm (57.1 in)
Track, Rear
1,460 mm (57.5 in)
Ground Clearance
190 mm (7.5 in)

Weight

Gross Weight
1,720 kg (3,792 lb)
Max Trailer Load, braked 12%
1,350 kg (2,976 lb)
Max Trailer Load, unbraked
400 kg (882 lb)
Cargo Capacity
485 – 495 kg (1,069 – 1,091 lb)
Max Roof Load
80 kg (176 lb)
Max Towbar Download
55 kg (121 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Other Equipment
Roof Railing
Yes
Antenna
Whip
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Special Features
Headlight Range Adjustment
Rear Lights
Spot Light
Optional

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
66.7
Fastening Type
Lug Nuts
Tightening Torque
88 - 118 Nm
Rim Material
Alloy
Rim Type
Disc Wheel
Spare Wheel
Temporary

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
  • CD
  • MP3
Interior Storage › Storage Compartments
Glove Compartment
Yes
Lights
Read Light
Front
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front

Steering Wheel

Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
380 litres
Depth
747 mm (29.4 in)
Depth, Back Seat Collapsed
1,232 mm (48.5 in)
Width
1,027 mm (40.4 in)
Width, Between Wheel Arches
997 mm (39.3 in)
Height
967 mm (38.1 in)
Sill Height
640 mm (25.2 in)

Seats

Colour & Material
Upholstery
Textile
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Second Seat Row
Collapsible
Manual
Second Seat Row › Collapsible
Split Fold Ratio
60/40

Features

Other Features

GPS
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote

Safety Testing

General
Test Year
2008
Adult Occupant
4/5 stars
Child Occupant
3/5 stars
Pedestrian
3/4 stars

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Driver Seat
in Front of

Car Classification

American Classification
Mini SUV
British Classification
Mini 4x4
Australian Classification
Small SUV
European Segment
J-Segment
Car.info Classification
Small SUV
