2009 Ford Ranger

United StatesDiesel4WDPickup

Photos

Specifications

Vehicle Details

Year
2009
Make
Ford
Model
Ranger
Body Style
Pickup
Generation
PK
Seats
2
Doors
2
Fuel
Diesel
Drivetrain
4WD
Transmission
Manual, 5-speed

Powertrain

Engine Name
2.5 TDCi 4x4 Manual
Engine Configuration
Inline
Power (hp)
143 hp
Power (kW)
105 kW
Torque
330 Nm (243 lb-ft)
Top speed
158 km/h (98 mph)
0–60 mph
11.3 seconds (estimated)
0–100 km/h
11.9 seconds
Displacement
2,499 cc

Dimensions

Length
5,075 mm (199.8 in)
Width
1,805 mm (71.1 in)
Height
1,745 mm (68.7 in)
Wheelbase
2,985 mm (117.5 in)
Curb weight
1,775 kg (3,913 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
3,500 rpm
Rev. at Max Torque
1,800 rpm
Engine Configuration
Bore
92 mm (3.6 in)
Stroke
92 mm (3.6 in)
Compression Ratio
18 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Belt
Engine Placement
Front
Type of Combustion Engine
Piston
Service Intervals
Timing Interval
120,000 km / 6 years
Oil Change & Engine Filter
20,000 km / 1 years

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
70 litres
Fuel Consumption NEDC
City
10.9 litres / 100 km
Highway
7.8 litres / 100 km
Combined
8.9 litres / 100 km
Emission NEDC
CO₂, Combined
244 g/km

Dimensions & Weight

Exterior

Track, Front
1,445 mm (56.9 in)
Track, Rear
1,440 mm (56.7 in)
Overhang, Front
885 mm (34.8 in)
Overhang, Rear
1,190 - 1,205 mm (46.9 - 47.4 in)
Turning Circle
12 m
Ground Clearance
205 - 180 mm (8.1 - 7.1 in)

Interior

Head Room, Front
1,014 mm (39.9 in)
Leg Room, Front
1,049 mm (41.3 in)

Weight

Gross Weight
2,800 kg (6,173 lb)
Max Trailer Load, braked 12%
3,000 kg (6,614 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
1,115 kg (2,458 lb)

Exterior

Chassis & Body

Chassis
Chassis
Pickup

Equipment

Windows
Window Lifts, Front
Powered

Lights

Main Beam
Halogen
Low Beam
Halogen

Rims & Tires

Number of Bolts
6 pcs
Bolt Distance
139.7
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
93.1
Fastening Type
Lug Nuts

Interior

Equipment

Instrument Cluster
Tachometer
Analogue
Climate Control
Air Condition
Optional
Outside Temperature Indicator
Yes
Connectivity
Radio
Yes
Media Format
  • CD
  • MP3

Seats

Colour & Material
Upholstery
Textile

Trunk

Rear Trunk
Yes
Rear Trunk
Depth
2,280 mm (89.8 in)
Width
1,456 mm (57.3 in)
Height
457 mm (18.0 in)
Sill Height
829 mm (32.6 in)

Safety & Security

Brake Systems

Anti-lock Braking System (ABS)
Yes

Other Features

Immobiliser
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2008
Adult Occupant
2/5 stars
Child Occupant
3/5 stars
Pedestrian
2/4 stars

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Seat Belt

Feature
Seat Belt Reminder
Belt Pretensioner

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Longerun Frame
Behind Right Front Wheel

Car Classification

American Classification
Mid-Size Pickup Truck
British Classification
Pick-up
Australian Classification
Ute
European Segment
J-Segment JD-Segment
Car.info Classification
Pickup
