2014 Mazda CX-9

Japan Gasoline FWD SUV

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2014
Make: Mazda
Model: CX-9
Body Style: SUV

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2014
Make: Mazda
Model: CX-9
Body Style: SUV

Generation

1st Generation 2nd Facelift

Seats

7

Doors

5

Fuel

Gasoline

Drivetrain

FWD

Transmission

Automatic, 6-speed

Powertrain

Engine Name: 3.7 Automatic
Engine Configuration: Inline
Power (hp): 277 hp
Power (kW): 204 kW
Torque: 365 Nm (269 lb-ft)
Top speed: 181 km/h (112 mph)
0–60 mph: 9.6 seconds (estimated)
0–100 km/h: 10.1 seconds
Displacement

Dimensions

Length: 5,070 mm (199.6 in)
Width: 1,940 mm (76.4 in)
Height: 1,730 mm (68.1 in)
Wheelbase: 2,930 mm (115.4 in)
Curb weight: 2,040 kg (4,497 lb)

Engine & Performance

Engine

Engine Specification

Rev. at Max Power: 6,250 rpm
Rev. at Max Torque: 4,250 rpm

Engine Configuration

Bore: 95.5 mm (3.8 in)
Stroke: 86.7 mm (3.4 in)
Compression Ratio

Similar suvs

Suggested vehicles

View all

2014 Kia Sorento

3,721 cc

10.3 :1

Engine Configuration

Inline

Transmission & Drivetrain

Transmission: Automatic, 6-speed

Brakes

Parking Brake: Electric
Front Brakes: Disc Brakes
Rear Brakes: Disc Brakes
Brake Caliper Pistons: Front
Rear

Front Brakes

Diameter: 320 mm (12.6 in)
Cooling: Ventilated

Rear Brakes

Fuel

General

Tank Volume: 76 litres

Fuel Consumption NEDC

City: 18.4 litres / 100 km
Highway: 9.9 litres / 100 km
Combined: 13 litres / 100 km

Emission NEDC

CO₂, Combined: 309 g/km

Dimensions & Weight

Exterior

Track, Front: 1,654 mm (65.1 in)
Track, Rear: 1,644 mm (64.7 in)
Turning Circle: 11.4 m
Ground Clearance: 200 mm (7.9 in)

Weight

Exterior

Chassis & Body

Chassis

Chassis: SUV

Platform

Mazda Platforms: GG

Equipment

Windows

Window Lifts, Front: Powered

Interior

Equipment

Instrument Cluster

Trip Computer: Yes
Tachometer: Analogue

Instrument Cluster › Trip Computer

Display: Yes

Climate Control

Climate Control: Automatic

Features

Comfort Features

Cruise Control: Yes
Cameras: Camera Position: Rear

Other Features

GPS: Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC): Yes

Brake Systems

Anti-lock Braking System (ABS): Yes
Traction Control System (TCS): Yes
Electronic Brake Assist (BA/EBA): Yes

Other

Car Classification

American Classification: Mid-Size SUV
British Classification: Large 4x4
Australian Classification: Large SUV
European Segment: J-Segment JD-Segment
Car.info Classification: Large SUV

Spare Parts BETA

Bulb Types

Diameter

325 mm (12.8 in)

Cooling

Solid

Gross Weight

2,712 kg (5,979 lb)

Max Trailer Load, braked 12%

1,600 kg (3,527 lb)

Max Trailer Load, unbraked

750 kg (1,653 lb)

Cargo Capacity

672 kg (1,482 lb)

Max Roof Load

45 kg (99 lb)

Window Lifts, Rear

Powered

Tinted Windows

Front
Second Row
Rear Window

Other Equipment

Sunroof: Optional
Normal Roof: Yes
Roof Railing: Optional
Electric: Optional

Lights

Main Beam: Halogen
Low Beam: Halogen
Fog Lights: Yes

Fog Lights

Front: Yes

Rims & Tires

Number of Bolts: 5 pcs
Bolt Distance: 114.3
Nut/Bolt Dimensions: M12x1.5
Central Bore (CB), front: 67.1
Fastening Type: Lug Nuts
Tightening Torque: 108 - 147 Nm

Air Condition

Yes

Outside Temperature Indicator

Yes

Controls

Buttons
Rotary Dials

Climate Control › Air Condition

Refrigerant: R134A
Refrigerant, Capacity: 685 g

Connectivity

Radio: Yes
Media Format: CD
MP3
WMA
Media Inputs: USB
Bluetooth: Yes

Connectivity › Media Inputs

AUX: Yes

Displays

Center Display: Optional

Steering Wheel

Multifunction Steering Wheel: Yes

Trunk

Rear Trunk: Yes

Rear Trunk

Volume: 265 litres
Volume, Back Seat Collapsed: 1,885 litres
Depth: 528 mm (20.8 in)
Depth, Back Seat Collapsed: 1,554 mm (61.2 in)
Width: 1,483 mm (58.4 in)
Width, Between Wheel Arches

Seats

Front Seats

Power Seat, Driver: Optional
Power Seat, Passenger: Optional
Heated Seats: Optional

Second Seat Row

Collapsible: Yes

Third/Fourth Seat Row

Third Seat Row: Yes

Sensors

Rain Sensors: Yes

Other Features

Immobiliser: Yes
Central Locking: Yes

Safety Testing

General

Not Tested by Euro NCAP: Yes

Frontal Crash

Front Driver Side: 3/5 stars
Front Passenger Side: 3/5 stars

Side Crash

Side Crash, Driver: 5/5 stars
Side Crash, Passenger: 5/5 stars
Front Seat Rating

Airbags

Feature

Driver

Passenger

Rear

Frontal Airbag

DriverYes

PassengerYes

Rear-

Side Chest Airbag

Low Beam: H11
Main Beam: HB3
Bi-Xenon: D4S
Datyime Running Light: HB3
Fog Light, Front: H11
Positioning-/Parking Lights, Front: W2.1×9.5d (W5W)
Positioning-/Parking Lights, Front Side: W2.1×9.5d (WY5W)
Positioning-/Parking Lights, Rear Side: W2.1×9.5d (W5W)
Rear/Brake Light: W3×16q (W21/5W)

CX-9

8.9

€67,000

MSRP · EUR

Body

1,025 mm (40.4 in)

5/5 stars

Combined Rear Seat Rating

5/5 stars

Side Barrier Rating

5/5 stars

Overall Side Pole Star Rating

3/5 stars

Rollover

Rollover Resistance: 15.1 %
Overall Safety Rating: 4/5 stars
Overall Frontal Rating: 3/5 stars
Overall Side Rating: 5/5 stars
Rollver: 4/5 stars

DriverYes

PassengerYes

Rear-

W2.1×9.5d (W5W)

Reversing Light

W2.1×9.5d (W16W)

Turn Indicators, Front

WX3×16d (WY21W)

Turn Indicators, Rear

WX3×16d (WY21W)

Entry Light

W2.1×9.5d (W5W)

License Plate Light

W2.1×9.5d (W5W)
