2014 Toyota Yaris

JapanHybrid GasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2014
Make
Toyota
Model
Yaris
Body Style
Hatchback
Generation
XP130
Seats
5
Doors
5
Fuel
Hybrid Gasoline
Drivetrain
FWD
Transmission
Automatic (Continuously variable)

Powertrain

Engine Name
Hybrid e-CVT
Engine Configuration
Inline
Power (hp)
101 hp
Power (kW)
74 kW
Torque
111 Nm (82 lb-ft)
Top speed
165 km/h (103 mph)
0–60 mph
11.2 seconds (estimated)
0–100 km/h
11.8 seconds
Displacement
1,497 cc

Dimensions

Length
3,885 mm (153.0 in)
Width
1,695 mm (66.7 in)
Height
1,510 mm (59.4 in)
Wheelbase
2,510 mm (98.8 in)
Curb weight
1,160 kg (2,557 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,800 rpm
Rev. at Max Torque
4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-20
  • 5W-20
  • 5W-30
  • 10W-30
  • 15W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
  • 15W-40
  • 20W-50
Engine Oil, Volume
3.7 litres
Configuration Combustion
Bore
75 mm (3.0 in)
Stroke
84.7 mm (3.3 in)
Compression Ratio
13.4 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Configuration Electric
Type of Electric Car
Hybrid
Electric Engine Power
45 kW
Electric Engine Horsepower (Metric)
61 hp
Torque
111 Nm (82 lb-ft)
Front Engines
Yes
Configuration Electric › Front Engines
Power (kW)
45 kW
Horsepower
61 hp
Number of Engines
2
Service Intervals
Oil Change & Engine Filter
15,000 km / 1 years

Transmission & Drivetrain

Transmission
Automatic (Continuously variable)

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
36 litres
Emission
Emission Standard
Euro 5
Emission Class
A+
Fuel Consumption NEDC
City
3.1 - 3.4 litres / 100 km
Highway
3.7 - 3.5 litres / 100 km
Combined
3.7 - 3.5 litres / 100 km
Emission NEDC
CO₂, Combined
79 - 85 g/km

Dimensions & Weight

Exterior

Track, Front
1,485 mm (58.5 in)
Track, Rear
1,470 mm (57.9 in)
Turning Circle
9.4 m
Ground Clearance
140 mm (5.5 in)

Weight

Gross Weight
1,565 kg (3,450 lb)
Cargo Capacity
405 kg (893 lb)
Max Roof Load
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Folding
Manual
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Optional
Heat-Insulating Windows
Yes
Tinted Windows
Optional
Windows › Heated Windows
Rear
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Normal Roof
Yes

Lights

Main Beam
Halogen
Low Beam
Halogen
Daytime Running Light
LED
Fog Lights
Optional
Special Features
Come Home/Leaving Lights

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
54.1
Fastening Type
Lug Nuts
Tightening Torque
103 Nm
Rim Type
Disc Wheel
Spare Wheel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Optional
Outside Temperature Indicator
Yes
Connectivity
Radio
Optional
App-Connect
Optional
Bluetooth
Optional
Connectivity › Radio
CD
Optional
MP3
Optional
WMA
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Speakers
Total Number of Speakers
6 pcs
Interior Storage › Storage Compartments
Glove Compartment
Yes
Back Pocket
Yes
Interior Storage › Storage Compartments › Glove Compartment
Cooled
Optional
Lights
Read Light
Front
Other Equipment
Clock
Digital
12V Outlet
Front

Steering Wheel

Multifunction Steering Wheel
Optional
Sport
Optional

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
286 litres
Volume, Back Seat Collapsed
856 litres
Depth
630 mm (24.8 in)
Width
1,004 mm (39.5 in)

Seats

Front Seats
Armrest
Optional
Second Seat Row
Collapsible
Yes

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional
Cruise Control
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Front Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Central Locking
Remote

Safety Testing

General
Test Year
2011
Adult Occupant
89 %
Child Occupant
81 %
Vulnerable Road Users
60 %
Safety Assist
86 %
Overall
5/5 stars
Frontal Crash
Front Driver Side
5/5 stars
Front Passenger Side
4/5 stars
Side Crash
Side Crash, Driver
5/5 stars
Side Crash, Passenger
5/5 stars
Front Seat Rating
5/5 stars
Combined Rear Seat Rating
5/5 stars
Side Barrier Rating
5/5 stars
Overall Side Pole Star Rating
4/5 stars
Rollover
Rollover Resistance
13.6 %
Overall Safety Rating
4/5 stars
Overall Frontal Rating
4/5 stars
Overall Side Rating
5/5 stars
Rollver
4/5 stars
IIHS
Test Year
2013
Small Overlap Front: Driver Side
Marginal
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
100,000 km / 3 years
Body Protection
3 years
Paintwork
3 years
Rust Damage
12 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
3 years

Identification

VIN Location
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

Spare Parts BETA

Bulb Types
Low Beam
H4
Main Beam
H4
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
  • BAY15d (P21/5W)
  • W3×16q (W21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
  • BAU15s (PY21W)
  • WX3×16d (WY21W)
Turn Indicators, Side
W2.1×9.5d (W5W)
Turn Indicators, Rear
  • BAU15s (PY21W)
  • WX3×16d (WY21W)
Read Light
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)
