2017 Jeep Cherokee

United StatesDiesel4WDSUV

Photos

Specifications

Vehicle Details

Year
2017
Make
Jeep
Model
Cherokee
Body Style
SUV
Generation
KL
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
4WD
Transmission
Automatic, 9-speed

Powertrain

Engine Name
2.2 CRD 4WD Automatic
Engine Configuration
Inline
Power (hp)
200 hp
Power (kW)
147 kW
Torque
440 Nm (325 lb-ft)
Top speed
203 km/h (126 mph)
0–60 mph
8.3 seconds (estimated)
0–100 km/h
8.7 seconds
Displacement
2,184 cc

Dimensions

Length
4,624 mm (182.0 in)
Width
1,859 mm (73.2 in)
Height
1,670 mm (65.7 in)
Wheelbase
2,700 mm (106.3 in)
Curb weight
1,850 kg (4,079 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
3,500 rpm
Rev. at Max Torque
2,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 5W-30
Engine Oil, Volume
4.3 litres
Engine Configuration
Bore
83.8 mm (3.3 in)
Stroke
99 mm (3.9 in)
Compression Ratio
15.5 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Belt
Type of Combustion Engine
Piston
Service Intervals
Timing Interval
120,000 km / 6 years
Brake Fluid
2 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
240,000 km / 10 years

Transmission & Drivetrain

Transmission
Automatic, 9-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
60 litres
Emission
Emission Standard
Euro 6
Fuel Consumption NEDC
City
7.5 litres / 100 km
Highway
5.3 litres / 100 km
Combined
6.1 litres / 100 km
Emission NEDC
CO₂, Combined
160 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,089 mm (82.2 in)
Track, Front
1,600 mm (63.0 in)
Track, Rear
1,600 mm (63.0 in)
Turning Circle
11.6 m
Ground Clearance
220 mm (8.7 in)

Interior

Head Room, Front
999 mm (39.3 in)
Head Room, Rear
978 mm (38.5 in)
Leg Room, Front
1,045 mm (41.1 in)
Leg Room, Rear
1,023 mm (40.3 in)
Hip Room, Front
1,367 mm (53.8 in)
Hip Room, Rear
1,268 mm (49.9 in)
Shoulder Room, Front
1,462 mm (57.6 in)
Shoulder Room, Rear
1,399 mm (55.1 in)

Weight

Gross Weight
2,475 kg (5,456 lb)
Max Trailer Load, braked 12%
2,370 kg (5,225 lb)
Max Trailer Load, unbraked
450 kg (992 lb)
Cargo Capacity
625 kg (1,378 lb)
Max Roof Load
68 kg (150 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Platform
Fiat Platforms
Compact Platform

Equipment

Side Mirrors
Heated
Yes
Turning Signal
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)

Lights

Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
110
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
65.1
Tightening Torque
135 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
Yes
Connectivity › Radio
USB
Optional
Displays
Center Display
Yes

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes

Trunk

Rear Trunk
Yes
Automatic Open
Optional
Automatic Close
Optional
Rear Trunk
Volume
700 litres
Volume, Back Seat Collapsed
1,555 litres

Seats

Colour & Material
Upholstery
Leather
Front Seats
Power Seat, Driver
Yes
Heated Seats
Yes

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Yes
Parking Heater
Optional
Cameras: Camera Position
Rear
Cruise Control
Adaptive Cruise Control
Optional
Parking Heater
Cabin Heater
Optional
Parking Heater › Cabin Heater
Engine Heater
Optional
Remote
Optional
Timer
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Front Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Lane Departure Warning (LDW)
Optional

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2013
Adult Occupant
92 %
Child Occupant
79 %
Vulnerable Road Users
67 %
Safety Assist
74 %
Overall
5/5 stars
Overall Score
36.16
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
15.16
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
3

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
3 years
Rust Damage
7 years
Roadside Assistance
Yes

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Driver Seat
Door
Passenger Seat
  • in Front of
  • Door

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV

Spare Parts BETA

Bulb Types
Low Beam
  • D3S (xenon)
  • HIR2
Main Beam
HIR2
Bi-Xenon
D3S
Fog Light, Front
H11
Fog Light, Rear
W3×16d (W21W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
WX3×16d (WY21W)
Turn Indicators, Rear
WX3×16d (WY21W)
License Plate Light
W2.1×9.5d (W5W)

Awards

Canadian
Utility Vehicle of the Year
2014
