2018 Mitsubishi Shogun Sport

JapanDiesel4WDSUV

Photos

Specifications

Vehicle Details

Year
2018
Make
Mitsubishi
Model
Shogun Sport
Body Style
SUV
Generation
KS0
Seats
7
Doors
5
Fuel
Diesel
Drivetrain
4WD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
2.4 DI-D MIVEC SS-4WD-II Automatic
Engine Configuration
Inline
Power (hp)
181 hp
Power (kW)
133 kW
Torque
430 Nm (317 lb-ft)
Top speed
180 km/h (112 mph)
0–60 mph
10.5 seconds (estimated)
0–100 km/h
11 seconds
Displacement
2,442 cc

Dimensions

Length
4,785 mm (188.4 in)
Width
1,815 mm (71.5 in)
Height
1,805 mm (71.1 in)
Wheelbase
2,800 mm (110.2 in)
Curb weight
2,100 kg (4,630 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
3,500 rpm
Rev. at Max Torque
2,500 rpm
Engine Fluids
Engine Oil, Volume
8.4 litres
Transmission Fluid, Volume
12.8 litres
Engine Coolant, Volume
7.7 litres
Car Battery
Voltage
12 V
Battery Capacity
55 Ah
Alternator Charge Current
130 A
Alternator Voltage
14 V
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
105.1 mm (4.1 in)
Compression Ratio
15.5 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic, 8-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
320 mm (12.6 in)
Cooling
Ventilated
Rear Brakes
Diameter
300 mm (11.8 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Dependent
Beam Axle (Live Axle)

Fuel

General
Tank Volume
68 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6b
Fuel Consumption NEDC
City
10.4 litres / 100 km
Highway
7.6 litres / 100 km
Combined
8.6 litres / 100 km
Emission NEDC
CO₂, Combined
227 g/km

Dimensions & Weight

Exterior

Track, Front
1,520 mm (59.8 in)
Track, Rear
1,515 mm (59.6 in)
Overhang, Front
880 mm (34.6 in)
Overhang, Rear
1,105 mm (43.5 in)
Approach Angle
30 °
Breakover Angle
23.1
Departure Angle
24.2 °
Turning Circle
11.2 m
Ground Clearance
218 mm (8.6 in)

Weight

Gross Weight
2,710 kg (5,975 lb)
Max Trailer Load, braked 12%
3,100 kg (6,834 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
605 - 610 kg (1,334 - 1,345 lb)
Max Roof Load
80 kg (176 lb)
Max Towbar Download
125 kg (276 lb)
Permitted Axle Load, front
1,360 kg (2,998 lb)
Permitted Axle Load, rear
1,600 kg (3,527 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV

Interior

Seats

Third/Fourth Seat Row
Third Seat Row
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Depth, Back Seat Collapsed
1,660 mm (65.4 in)
Width
1,280 mm (50.4 in)
Width, Between Wheel Arches
1,000 mm (39.4 in)
Height
880 mm (34.6 in)

Other

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment JD-Segment
Car.info Classification
  • Medium SUV
  • Large SUV
