2017 Subaru BRZ

JapanGasolineRWDCoupe

Photos

Specifications

Vehicle Details

Year
2017
Make
Subaru
Model
BRZ
Body Style
Coupe
Generation
ZC6 Facelift
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
2.0 H4
Engine Configuration
Flat
Power (hp)
200 hp
Power (kW)
147 kW
Torque
205 Nm (151 lb-ft)
Top speed
210 km/h (130 mph)
0–60 mph
7.2 seconds (estimated)
0–100 km/h
7.6 seconds
Displacement
1,998 cc

Dimensions

Length
4,240 mm (166.9 in)
Width
1,775 mm (69.9 in)
Height
1,285 mm (50.6 in)
Wheelbase
2,750 mm (108.3 in)
Curb weight
1,205 kg (2,657 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,000 rpm
Rev. at Max Torque
6,400 - 6,600 rpm
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
86 mm (3.4 in)
Compression Ratio
12.5 :1
Engine Configuration
Flat

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
  • Leatherette
  • Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Steel
Brake Caliper Colour
Grey
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Double Wishbone

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 6d
WLTP Consumption
Low (l/100km) (WLTP)
12.7 – 14.1 litres / 100 km
Medium (l/100km)
8.1 – 8.2 litres / 100 km
High (l/100km)
7 – 7.2 litres / 100 km
Extra High (l/100km)
8.1 – 8.2 litres / 100 km
Combined (l/100km)
8.5 – 8.6 litres / 100 km
Fuel Consumption NEDC
City
9.6 – 10.4 litres / 100 km
Highway
5.7 – 6.4 litres / 100 km
Combined
7.1 – 7.8 litres / 100 km
Emission WLTP
CO₂, Low
286 – 318 g/km
CO₂, Medium
183 – 185 g/km
CO₂, High
157 – 162 g/km
CO₂, Extra High
182 – 185 g/km
CO₂, Combined
191 – 193 g/km
Emission NEDC
CO₂, Combined
164 – 181 g/km

Dimensions & Weight

Exterior

Track, Front
1,520 mm (59.8 in)
Track, Rear
1,540 mm (60.6 in)
Ground Clearance
120 mm (4.7 in)

Interior

Head Room, Front
942 mm (37.1 in)
Head Room, Rear
889 mm (35.0 in)
Leg Room, Front
1,064 mm (41.9 in)
Leg Room, Rear
760 mm (29.9 in)
Hip Room, Front
1,349 mm (53.1 in)
Hip Room, Rear
1,151 mm (45.3 in)
Shoulder Room, Front
1,384 mm (54.5 in)
Shoulder Room, Rear
1,313 mm (51.7 in)

Weight

Gross Weight
1670 – 1700 kg (3,682 – 3,748 lb)
Cargo Capacity
465 – 472 kg (1,025 – 1,041 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-C
Chassis Construction
Unibody

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Heated
Yes
Mirror Shape, Driver side
Convex
Mirror Shape, Passenger side
Convex
Windscreen Wipers
Number of Wiper Speeds
3
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Tinted Windows
  • Front
  • Second Row
  • Rear Window
Other Equipment
Normal Roof
Yes
Spoiler
Fixed
Antenna
Shark Fin

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
  • Automatic Headlight Activation
  • Headlight Washers
Fog Lights
Front
Yes
Special Features
Headlight Range Adjustment
Manual

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
56.1
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
120 Nm
Rim Material
Alloy
Number of Spokes
5

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
4.2"
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Micro Filter
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
5 pcs
Controls
  • Buttons
  • Rotary Dials
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
  • AM
  • FM
  • DAB
Media Format
  • MP3
  • WMA
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Phone
Connectivity › Media Inputs
USB
Yes
Connectivity › Media Inputs › USB
Number of Ports
2 pcs
Displays
Center Display
7"
Center Display Controls
Touchscreen
Equalizer
Yes
Speakers
Total Number of Speakers
6 pcs
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
Front
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
Carpets
Optional
Ashtray
Yes
Cigarette Lighter
Optional
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Material
Leather
Colour
Black
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Yes
Mute Audio
Yes
Multifunction Steering Wheel
Menu Navigation
Yes
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down
  • Resume

Trunk

Rear Trunk
Yes
Release Button
Yes
Carpet
  • Rubber
  • Rug
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
243 litres
Volume, Back Seat Collapsed
330 litres
Depth
812 mm (32.0 in)
Depth, Back Seat Collapsed
1,359 mm (53.5 in)
Width
1,397 mm (55.0 in)
Width, Between Wheel Arches
1,067 mm (42.0 in)

Design

Interior Decor Colour
Black
Transmission Knob Material
Leather

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Number of Driver Seat Adjustments, Total
8
Number of Passenger Seat Adjustments, Total
6
Heated Seats
Yes
Armrest
Middle
Type of Seat
Sport Seats
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Heated Seats
Areas
Cushion
Second Seat Row
Collapsible
Manual
Number of Seats
2
Type of Seat
Adult
Second Seat Row › Collapsible
Split Fold Ratio
60/40

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Yes
Media
Yes
Phone
Yes

Other Features

GPS
Navigation

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner

Assist Systems

Electronic Stability Control (ESC)
Yes
Dynamic Steering Response (DSR)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Differential Lock
Limited Slip Differential (LSD)

Sensors

Parking Sensors
Optional
Light Sensor
Yes
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote

Safety Testing

General
Not Tested by Euro NCAP
Yes
Frontal Crash
Front Driver Side
4/5 stars
Front Passenger Side
4/5 stars
Rollover
Rollover Resistance
7.1 %
Overall Frontal Rating
4/5 stars
Rollver
5/5 stars
IIHS
Test Year
2014
Small Overlap Front: Driver Side
Acceptable
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good

Airbags

Feature
Frontal Airbag
Side Head Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
100,000 km / 3 years
Body Protection
3 years
Paintwork
3 years
Rust Damage
12 years

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Spare Parts BETA

Bulb Types
Bi-Xenon
D4S
Fog Light, Front
PG20 (PSX24W)
Positioning-/Parking Lights, Rear Side
W2.1×9.5d (W5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
WX3×16d (WY21W)
Turn Indicators, Rear
WX3×16d (WY21W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)
