2018 Chrysler Pacifica

United StatesEthanol E85FWDMinivan

Photos

Specifications

Vehicle Details

Year
2018
Make
Chrysler
Model
Pacifica
Body Style
Minivan
Generation
RU
Seats
7
Doors
5
Fuel
Ethanol E85
Drivetrain
FWD
Transmission
Automatic, 9-speed

Powertrain

Engine Name
3.6 V6 FlexFuel Automatic
Engine Configuration
V
Power (hp)
291 hp
Power (kW)
214 kW
Torque
355 Nm (262 lb-ft)
Displacement
3,605 cc

Dimensions

Length
5,176 mm (203.8 in)
Width
2,022 mm (79.6 in)
Height
1,777 mm (70.0 in)
Wheelbase
3,089 mm (121.6 in)
Curb weight
1,964 kg (4,330 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,400 rpm
Rev. at Max Torque
4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-20
Engine Oil, Volume
4.7 litres
Engine Configuration
Bore
96 mm (3.8 in)
Stroke
83 mm (3.3 in)
Compression Ratio
11.3 :1
Engine Configuration
V-Engine
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Service Intervals
Oil Change & Engine Filter
4,000 km / 0.5 years

Transmission & Drivetrain

Transmission
Automatic, 9-speed
Gear Ratio
1st Gear
4.7 :1
2nd Gear
2.84 :1
3rd Gear
1.91 :1
4th Gear
1.38 :1
5th Gear
1 :1
6th Gear
0.81 :1
7th Gear
0.7 :1
8th Gear
0.58 :1
9th Gear
0.48 :1
Final Drive
3.25 :1
Reverse
3.81 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
330 mm (13.0 in)
Width
28 mm (1.1 in)
Cooling
Ventilated
Rear Brakes
Diameter
320 - 330 mm (12.6 - 13.0 in)
Width
12 mm (0.5 in)

Suspensions

Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Yes

Fuel

General
Tank Volume
72 litres
General › Fuel Cap Position
Front
Left
Fuel Consumption NEDC
City
12.4 litres / 100 km
Highway
8.4 litres / 100 km
Combined
10.7 litres / 100 km

Performance

Drag Coefficient
0.3

Dimensions & Weight

Exterior

Width, with Mirrors
2,297 mm (90.4 in)
Track, Front
1,735 mm (68.3 in)
Track, Rear
1,736 mm (68.3 in)
Overhang, Front
960 mm (37.8 in)
Overhang, Rear
1,127 mm (44.4 in)
Turning Circle
12.1 m
Ground Clearance
131 mm (5.2 in)

Interior

Head Room, Front
1,020 mm (40.2 in)
Head Room, Rear
1,006 mm (39.6 in)
Head Room, Third Row
984 mm (38.7 in)
Leg Room, Front
1,045 mm (41.1 in)
Leg Room, Rear
992 mm (39.1 in)
Leg Room, Third Row
929 mm (36.6 in)
Hip Room, Front
1,500 mm (59.1 in)
Hip Room, Rear
1,647 mm (64.8 in)
Hip Room, Third Row
1,258 mm (49.5 in)
Shoulder Room, Front
1,622 mm (63.9 in)
Shoulder Room, Rear
1,602 mm (63.1 in)
Shoulder Room, Third Row
1,555 mm (61.2 in)

Weight

Gross Weight
2,747 kg (6,056 lb)
Cargo Capacity
783 kg (1,726 lb)
Max Roof Load
70 kg (154 lb)
Weight Distribution, front
55 %
Weight Distribution, rear
45 %

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D + Extra Pillar(s)
Doors
Front Doors
Conventional
Rear Doors
Sliding

Equipment

Side Mirrors
Folding
Electrical
Heated
Yes
Windows
Window Lifts, Front
Powered
Rear
Yes
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Optional
Fog Lights
Main Beam Assist
Optional

Rims & Tires

Tightening Torque
135 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
Yes
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Yes
Connectivity › Radio
DVD
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Heated
Optional

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
915 litres
Width
1,239 mm (48.8 in)
Height
1,208 mm (47.6 in)
Sill Height
617 mm (24.3 in)

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Tilt Adjustment
Yes
Second Seat Row › Collapsible
Heated Seats
Optional
Third/Fourth Seat Row
Third Seat Row
Yes

Features

Comfort Features

Keyless Start
Optional
Cruise Control
Yes
360° Camera
Optional
Cameras: Camera Position
Rear
Cruise Control
Adaptive Cruise Control
Optional

Other Features

GPS
Optional
Start & Stop
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Departure Warning (LDW)
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Yes
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes
Frontal Crash
Front Driver Side
5/5 stars
Front Passenger Side
5/5 stars
Side Crash
Side Crash, Driver
5/5 stars
Overall Side Pole Star Rating
5/5 stars
Overall Safety Rating
5/5 stars
Overall Frontal Rating
5/5 stars
Overall Side Rating
5/5 stars
Rollver
4/5 stars
IIHS
Test Year
2017
Award
Top Safety Pick
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Acceptable
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Marginal

Airbags

Feature
Frontal Airbag
Side Chest Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Minivan
British Classification
Large MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Large MPV

Awards

North American
Utility Vehicle of the Year
2017
Canadian
Utility Vehicle of the Year
2018
