2018 Volkswagen Arteon

GermanyDiesel2WDHatchback

Photos

Specifications

Vehicle Details

Year
2018
Make
Volkswagen
Model
Arteon
Body Style
Hatchback
Generation
Type 3H
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
2WD
Transmission
Automatic (Dual-clutch), 6-speed

Powertrain

Engine Name
2.0 TDI DSG Sequential
Engine Configuration
Inline
Power (hp)
177 hp
Power (kW)
130 kW
Torque
350 Nm (258 lb-ft)
Top speed
220 km/h (137 mph)
0–60 mph
8.3 seconds (estimated)
0–100 km/h
8.7 seconds
Displacement
1,968 cc

Dimensions

Length
4,862 mm (191.4 in)
Width
1,871 mm (73.7 in)
Height
1,427 mm (56.2 in)
Wheelbase
2,841 mm (111.9 in)
Curb weight
1,619 kg (3,569 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,600 - 6,500 rpm
Rev. at Max Torque
1,700 - 5,600 rpm
Engine Fluids
Engine Oil, Volume
4.7 litres
Car Battery
Voltage
12 V
Alternator Voltage
14 V
Engine Configuration
Bore
81 mm (3.2 in)
Stroke
95.5 mm (3.8 in)
Compression Ratio
16.2 :1
Engine Configuration
Inline
Turbocharger
Single-turbo
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Timing Interval
120,000 km (74,565 mi)
Air Filter
30,000 km / 2 years
Fuel Filter
30,000 km (18,641 mi)
Brake Fluid
2 years
Oil Change & Engine Filter
15,000 km / 1 years
Transmission, Fluid
120,000 km (74,565 mi)
Transmission, Fluid Filter
120,000 km (74,565 mi)
Interior Filter
30,000 km / 1 years
Accessory Belt
60,000 km (37,282 mi)

Transmission & Drivetrain

Transmission
Automatic (Dual-clutch), 6-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Sports Suspension
Optional
Electronic Damper Control (EDC)
Optional
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
66 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Exhaust Gas Recirculation
Fuel Consumption NEDC
City
7.2 litres / 100 km
Highway
4.6 litres / 100 km
Combined
5.6 litres / 100 km
Emission NEDC
CO₂, Combined
145 g/km

Performance

Drag Coefficient
0.3

Dimensions & Weight

Exterior

Width, with Mirrors
2,127 mm (83.7 in)
Track, Front
1,587 - 1,591 mm (62.5 - 62.6 in)
Track, Rear
1,577 - 1,581 mm (62.1 - 62.2 in)
Turning Circle
11.9 m

Interior

Head Room, Front
975 - 1,008 mm (38.4 - 39.7 in)
Head Room, Rear
940 mm (37.0 in)
Shoulder Room, Front
1,500 mm (59.1 in)
Shoulder Room, Rear
1,481 mm (58.3 in)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback (Fastback)
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Volkswagen Group
MQB Platform

Interior

Steering Wheel

Power Steering
Electro-mechanical
Steering Ratio
13.6 :1
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
563 litres
Volume, Back Seat Collapsed
1,557 litres
Depth
1,181 mm (46.5 in)
Depth, Back Seat Collapsed
2,092 mm (82.4 in)

Seats

Second Seat Row
Number of Seats
3
Type of Seat
Adult
