Specifications
Vehicle Details
- Year
- 2024
- Make
- Volkswagen
- Model
- Passat
- Variant
- Variant
- Body Style
- Wagon
- Generation
- B9 (Type CJ)
- Seats
- 5
- Doors
- 5
- Fuel
- Mild Hybrid Gasoline
- Drivetrain
- FWD
- Transmission
- Automatic (Dual-clutch), 7-speed
Powertrain
- Engine Name
- 1.5 eTSI ACT OPF DSG Sequential
- Engine Configuration
- Inline
- Power (hp)
- 150 hp
- Power (kW)
- 110 kW
- Torque
- 250 Nm (184 lb-ft)
- Top speed
- 222 km/h (138 mph)
- 0–60 mph
- 8.9 seconds (estimated)
- 0–100 km/h
- 9.3 seconds
- Displacement
- 1,498 cc
Dimensions
- Length
- 4,917 mm (193.6 in)
- Width
- 1,849 mm (72.8 in)
- Height
- 1,497 mm (58.9 in)
- Wheelbase
- 2,841 mm (111.9 in)
- Curb weight
- 1,572 kg (3,466 lb)
Engine
Engine Specification
- Rev. at Max Power
- 5,000 rpm
- Rev. at Max Torque
- 1,500 - 3,500 rpm
Engine Fluids
- Synthetic Oil (viscosity)
- 0W-20
- Engine Oil, Volume
- 4 litres
Engine Configuration
- Bore
- 74.5 mm (2.9 in)
- Stroke
- 85.9 mm (3.4 in)
- Compression Ratio
- 10.5 :1
- Engine Configuration
- Inline
- Turbocharger
- Single-turbo
- Synchronization
- Timing Belt
- Engine Placement
- Front
- Engine Mount
- Transversally
- Type of Combustion Engine
- Piston
- Fuel System
- Electronic (Direct) Fuel Injection
- Camshaft Type
- DOHC
- Engine Block
- Aluminium
- Engine Heads
- Aluminium
- Engine Cooling
- Liquid Cooling
- Mild-Hybrid
- Yes
Service Intervals
- Air Filter
- 90,000 km / 6 years
- Brake Fluid
- 2 years
- Oil Change & Engine Filter
- 15,000 km / 1 years
- Interior Filter
- 60,000 km / 2 years
Transmission & Drivetrain
- Transmission
- Automatic (Dual-clutch), 7-speed
- Gear Selector
- Stalk
- Gear Selector Location
- Steering Column
Brakes
Parking Brake
- Electric
- Auto Hold
- Front Brakes
- Disc Brakes
- Rear Brakes
- Disc Brakes
- Brake Caliper Pistons
- Front
- Brakes Material
- Steel
Front Brakes
- Diameter
- 312 mm (12.3 in)
- Width
- 25 mm (1.0 in)
- Cooling
- Ventilated
Rear Brakes
- Diameter
- 300 mm (11.8 in)
- Width
- 12 mm (0.5 in)
- Cooling
- Solid
Suspensions
- Spring, Front
- Coil
- Spring, Rear
- Coil
- Anti-roll Bar
- Front
- Electronic Damper Control (EDC)
- Optional
Suspension, Front
- Independent
- MacPherson Strut
Suspension, Rear
- Independent
- Multi-link
Fuel
General
- Tank Volume
- 66 litres
General › Fuel Cap Position
- Rear
- Right
Emission
- Emission Standard
- Euro 6 (Euro 6e)
- Emission Class
- D
- Emission Control
- Catalyst
- Particle Filter
- Adaptive Cylinder Management
- Evaporative Control System
- Exhaust Gas Recirculation
- Positive Crankcase Ventilation
WLTP Consumption
- Low (l/100km) (WLTP)
- 7.2 - 7.6 litres / 100 km
- Medium (l/100km)
- 5.2 - 5.5 litres / 100 km
- High (l/100km)
- 4.6 - 4.8 litres / 100 km
- Extra High (l/100km)
- 5.5 - 5.7 litres / 100 km
- Combined (l/100km)
- 5.4 - 5.7 litres / 100 km
Emission WLTP
- CO₂, Combined
- 122 - 129 g/km
Exterior
- Width, with Mirrors
- 2,090 mm (82.3 in)
- Track, Front
- 1,577 - 1,585 mm (62.1 - 62.4 in)
- Track, Rear
- 1,560 - 1,574 mm (61.4 - 62.0 in)
- Overhang, Front
- 957 mm (37.7 in)
- Overhang, Rear
- 1,119 mm (44.1 in)
- Approach Angle
- 12.8 °
- Breakover Angle
- 10.5
- Departure Angle
- 11.7 °
- Turning Circle
- 12 m
Interior
- Head Room, Front
- 1,001 - 1,049 mm (39.4 - 41.3 in)
- Head Room, Rear
- 968 - 1,008 mm (38.1 - 39.7 in)
- Shoulder Room, Front
- 1,508 mm (59.4 in)
- Shoulder Room, Rear
- 1,506 mm (59.3 in)
Weight
- Gross Weight
- 2,130 kg (4,696 lb)
- Max Trailer Load, braked 12%
- 1,600 kg (3,527 lb)
- Max Trailer Load, braked 8%
- 1,900 kg (4,189 lb)
- Max Trailer Load, unbraked
- 750 kg (1,653 lb)
- Cargo Capacity
- 558 kg (1,230 lb)
- Max Roof Load
- 100 kg (220 lb)
- Max Towbar Download
- 90 kg (198 lb)
- Permitted Axle Load, front
- 1,080 kg (2,381 lb)
- Permitted Axle Load, rear
- 1,100 kg (2,425 lb)
Chassis & Body
Chassis
- Chassis
- Station Wagon
- Pillars
- A-D
- Chassis Construction
- Unibody
- Body Material
- Steel
Doors
- Front Doors
- Conventional
- Rear Doors
- Conventional
Equipment
Side Mirrors
- Mirror Type
- Conventional
- Adjustments
- Electrical
- Heated
- Yes
- Automatic Tilt Down
- Optional
- Turning Signal
- Yes
- House Colour
- Same as Car
- Mirror Shape, Driver side
- Aspheric
- Mirror Shape, Passenger side
- Convex
Side Mirrors › Adjustments
- Driver side
- Optional
Windscreen Wipers
- Heated Washer Nozzles
- Optional
- Intermittent Control
- Yes
- Rear Wiper
- Yes
Windows
- Window Lifts, Front
- Powered
- Window Lifts, Rear
- Powered
- Heated Windows
- Rear
- Heat-Insulating Windows
- Front
- First Row
- Second Row
- Rear
- Noise Reducing Windows
- Optional
- Sun Visors
- Optional
- Tinted Windows
- Optional
- Safety Glass
- Yes
Windows › Window Lifts, Features
- Pinch Protection
- Driver
- Passenger
- One-touch up/down
- Driver
- Passenger
Windows › Noise Reducing Windows
- First Row
- Optional
- Second Row
- Optional
Windows › Tinted Windows
- Second Row
- Optional
- Rear Window
- Optional
Windows › Safety Glass
- Front
- Laminated
Other Equipment
- Sunroof
- Optional
- Roof Railing
- Yes
- Antenna
- Shark Fin
Other Equipment › Sunroof
- Sun Blind
- Optional
Other Equipment › Sunroof › Sun Blind
- Tinted Glass
- Optional
Other Equipment › Roof Railing
- Roof Railing Type
- Flush Rails (Closed Rails)
Lights
- Main Beam
- LED
- Low Beam
- LED
- Rear Lights
- LED
- Daytime Running Light
- LED
- Fog Lights
- Optional
- Special Features
- Automatic Headlight Activation
- Come Home/Leaving Lights
Special Features
- Main Beam Assist
- Optional
- Adaptive Headlights
- Optional
- Dynamic Turn Signal
- Optional
- Dynamic Cornering Lights
- Optional
- Headlight Range Adjustment
- Yes
Colour
- Door Handles
- Same as Car
Rims & Tires
- Tire Pressure Monitoring System (TPMS)
- Direct
- Number of Bolts
- 5 pcs
- Bolt Distance
- 112
- Nut/Bolt Dimensions
- M14x1.5
- Central Bore (CB), front
- 57.1
- Central Bore (CB), rear
- 57.1
- Fastening Type
- Lug Bolts
- Anti-Theft Locking Lug Nuts/Bolts
- Optional
- Tightening Torque
- 120 - 140 Nm
- Rim Material
- Alloy
- Number of Spokes
- 5
- Rim Type
- Disc Wheel
Equipment
Instrument Cluster
- Trip Computer
- Yes
- Head-up Display (HUD)
- Optional
- Speedometer
- Digital
- Tachometer
- Digital
- Fuel Gauge
- Digital
- Coolant Temperature
- Digital
- Odometer Limit
- 1,000,000 km/miles
Instrument Cluster › Trip Computer
- Display
- Yes
Instrument Cluster › Trip Computer › Display
- Type
- Colour
- Shape
- Cockpit
Climate Control
- Climate Control
- Automatic
- Air Condition
- Yes
- Pollen Filter
- Yes
- Outside Temperature Indicator
- Yes
- Controls
- Touchscreen
- Back Seat Controls
- Optional
Climate Control › Air Condition
- Refrigerant
- R1234yf
Connectivity
- Radio
- AM
- FM
- DAB+
- App-Connect
- Android Auto
- Apple CarPlay (Wireless)
- Bluetooth
- Phone
- Audio
- WiFi
- Yes
Connectivity › Media Inputs
- USB
- USB-C
Connectivity › Media Inputs › USB
- Placement
- Armrest Hatch/Mid-console
- Rear
- Optional
Displays
- Center Display
- 12.9"
- Center Display Controls
- Touchscreen
Displays › Center Display
- Type
- Colour
Features
- Active Noise Cancellation
- Optional
Speakers
- Total Number of Speakers
- 8 - 13 pcs
- Speakers Max. Watt
- 700 W
- Subwoofer
- Optional
Rear-view Mirror
- Adjustments
- Mechanical
- Rear-view Mirror: Mirror Type
- Standard
Interior Storage › Storage Compartments
- Glove Compartment
- Yes
- Armrest Hatch
- Front
- Door
- Driver Side
- Passenger Side
- Rear
Interior Storage
- Cup Holders
- Yes
Interior Storage › Cup Holders
- Front
- 2
Interior Storage › Cup Holders › Front
- Placement
- Middle Console
Lights
- Read Light
- Front
- Rear
- Guide Light
- Entry Guard
- Footwell (Front)
- Door Handles (Interior)
- Ambient Light
- Yes
- Selectable Light Colour
- Yes
Other Equipment
- Make-up Mirror
- Driver Side
- Passenger Side
- Clock
- Yes
- 12V Outlet
- Front
- 230V Outlet
- Optional
- Carpets
- Front
- Rear
Other Equipment › Make-up Mirror
- Make-up Light
- Driver
- Passenger
Other Equipment › Clock
- Digital
- Center Display
- Instrument Cluster
Other Equipment › 12V Outlet
- Trunk
- Optional
Other Equipment › 230V Outlet
- Trunk
- Optional
Other Equipment › Carpets
- Material
- Textile
- Colour
- Black
Steering Wheel
- Multifunction Steering Wheel
- Yes
- Heated
- Optional
- Power Steering
- Electro-mechanical
- Adjustments
- Tilt
- Telescope
- Sport
- Optional
- Number of Spokes
- 3
- Material
- Leather
- Colour
- Black
- Steering Mechanism
- Rack and Pinion
Multifunction Steering Wheel
- Menu Navigation
- Buttons
- Cruise Control
- Speed Up/Down (Buttons)
- Resume
- Media
- Yes
- Mode Selection
- Yes
Multifunction Steering Wheel › Media
- Answer Phone
- Yes
- Channels
- Yes
- Volume
- Buttons
Trunk
- Rear Trunk
- Yes
- Automatic Open
- Button on Trunk Door
- Automatic Close
- Yes
- Cover
- Sliding (Electrical | Manual)
- Barrier Net/Grid
- Optional
- Hatch Through Rear Seats
- Yes
- Hatch Opening Type
- From Roof
Rear Trunk
- Volume
- 690 litres
- Volume, Back Seat Collapsed
- 1,920 litres
- Depth
- 1,127 mm (44.4 in)
- Depth, Back Seat Collapsed
- 2,018 mm (79.4 in)
- Width, Between Wheel Arches
- 1,010 mm (39.8 in)
- Height
- 693 mm (27.3 in)
- Trunk Door Opening Height
- 2,087 mm (82.2 in)
- Sill Height
- 626 mm (24.6 in)
Automatic Open
- Key Button
- Optional
- Motion Activated
- Optional
Design
- Interior Decor Material
- Plastic
- Interior Decor Colour
- Black
- Pedals
- Standard
Pedals
- Stainless Steel
- Optional
Seats
Colour & Material
- Upholstery
- Textile
Front Seats › Adjustments, Driver
- Seat Depth
- Manual
- Seat Height
- Manual
- Cushion Edge
- Manual
- Cushion Tilt
- Optional
- Backrest Angle
- Powered
- Lumbar Support
- Powered
- Headrest, Height
- Manual
- Headrest, Tilt
- Manual
Front Seats › Adjustments, Passenger
- Seat Depth
- Manual
- Seat Height
- Manual
- Cushion Edge
- Manual
- Cushion Tilt
- Optional
- Backrest Angle
- Powered
- Lumbar Support
- Powered
- Headrest, Height
- Manual
- Headrest, Tilt
- Manual
Front Seats
- Power Seat, Driver
- Yes
- Power Seat, Passenger
- Yes
- Heated Seats
- Optional
- Armrest
- Middle
- Massage
- Driver
- Passenger
Front Seats › Power Seat, Driver
- Semi-Powered
- Yes
Front Seats › Power Seat, Passenger
- Semi-Powered
- Yes
Front Seats › Heated Seats
- Cushion
- Optional
Front Seats › Heated Seats › Cushion
- Backrest
- Optional
Second Seat Row
- Collapsible
- Manual
- Number of Seats
- 3
- Type of Seat
- Adult
Second Seat Row › Collapsible
- Backrest Release
- On Top of Backrest
- Split Fold Ratio
- 60/40
- Heated Seats
- Optional
Second Seat Row › Headrests
- Outer Seats
- Height Adjustment
- Centre Seat
- Yes
Second Seat Row › Headrests › Centre Seat
- Height Adjustment
- Yes
Comfort Features
- Keyless Entry
- Optional
- Keyless Start
- Yes
- Cruise Control
- Yes
- Speed Limiter
- Yes
- Cameras
- Rear
- Voice Control
- Optional
- Wireless Phone Charger
- Optional
Cameras
- View Location
- Center Display
Voice Control
- Climate Control
- Optional
- Media
- Optional
- Navigation
- Optional
- Phone
- Optional
Wireless Phone Charger
- Front
- Optional
Other Features
- GPS
- Optional
- Start & Stop
- Yes
- Driving Mode Selection
- Optional
- Dynamic Chassis Control (DCC)
- Optional
- Horn
- Dual Note
GPS
- Internet
- Optional
Driving Mode Selection
- Comfort
- Optional
- Eco
- Optional
- Individual
- Optional
- Normal
- Optional
- Sport
- Optional
Accessories
- Tool Kit and Jack
- Optional
- Tire Repair Kit
- Yes
- Compressor
- Yes
- Fire Extinguisher
- Optional
- Warning Triangle
- Optional
- First Aid Kit
- Optional
- Trunk Modules
- Optional
- Bicycle Holder
- Optional
Seat Belt
- Height Adjustable Retractor
- Yes
- Seat Belt Colour
- Black
Feature
Driver
Passenger
Rear
Seat Belt Reminder
Yes
Yes
Yes
Belt Pretensioner
Yes
Yes
Yes
Belt Load Limiter
Yes
Yes
Yes
Height Adjustable Retractor
- Manual
- Yes
Type of Belt
- Three-Point-Belt
- Front Seats
- Outer Rear Seats
- Centre Rear Seat
Assist Systems
- Electronic Stability Control (ESC)
- Yes
- Rear Collision Warning (RCW)
- Yes
- Safe Exit Warning (SEW)
- Yes
- Lane Assist System
- Yes
- Hill Start Assist (HSA)
- Yes
- Parking Assist
- Optional
- Sign Assist
- Yes
- Trailer Assist
- Optional
- Trailer Stability Assist (TSA)
- Optional
- Emergency Assist
- Yes
- Emergency Stop Signal (ESS)
- Yes
Lane Assist System
- Lane Departure Warning (LDW)
- Yes
- Lane Keeping Assist (LKA)
- Yes
- Active Lane Change
- Yes
Brake Systems
- Autonomous Emergency Brake System (AEB)
- Yes
- Power Brakes
- Yes
- Anti-lock Braking System (ABS)
- Four-channel
- Traction Control System (TCS)
- Yes
- Electronic Brakeforce Distribution (EBD)
- Yes
- Cornering Brake Control (CBC)
- Yes
- Electronic Brake Assist (BA/EBA)
- Yes
- Brake Pad Wear Indicator
- Yes
Autonomous Emergency Brake System (AEB)
- Car-to-car
- Yes
- Pedestrian
- Yes
- Cyclist
- Yes
- City
- Yes
- Inter-urban
- Yes
Sensors
- Parking Sensors
- Front
- Rear
- Blind Spot Detection (BLIS)
- Optional
- Door Open Warning
- Yes
- Driver Alertness Warning (DAW)
- Yes
- Light Sensor
- Yes
- Rain Sensors
- Yes
Other Features
- Immobiliser
- Yes
- Anti-theft Alarm
- Optional
- Central Locking
- Remote
- Auto Lock (Speed Sensitive)
- Child Safety Locks
- Electrical
- Reversing Alarm
- Yes
Immobiliser
- Electronic
- Yes
Safety Testing
General
- Test Year
- 2024
- Adult Occupant
- 93 %
- Child Occupant
- 87 %
- Vulnerable Road Users
- 82 %
- Safety Assist
- 80 %
- Overall
- 5/5 stars
Adult Occupant
- Total Points
- 37.3 /38
- Frontal Impact
- 13.9 /16
- Lateral Impact
- 16 /16
- Rear Impact
- 3.4 /4
- Rescue and Extrication
- 4 /2
Child Occupant
- Total Points
- 43 /49
- Crash Test Performance
- 16
- 8 /16
- Safety Features
- 7 /13
- CRS Installation Check
- 12 /12
Vulnerable Road Users
- Pedestrian
- 11.5
- 4.5
- 7.4
- AEB Pedestrian
- 7 /9
- AEB Pedestrian (assesment)
- Good
- AEB Cyclist
- 8 /9
- AEB Cyclist (assesment)
- Good
Safety Assist
- Speed Assistance (points)
- 1.7 /3
- Speed Assistance (assesment)
- Adequate
- Occupant Status Monitoring (points)
- 1.3 /3
- Occupant Status Monitoring (assesment)
- Marginal
- Seat Belt Reminder (points)
- 1 /2
- Seat Belt Reminder (assesment)
- Good
- Driver Monitoring (points)
- 0.3
- Driver Monitoring (assesment)
- Weak
- Lane Support (points)
- 3 /4
- Lane Support (assesment)
- Good
- Emergency Lane Keeping (assesment)
- Good
- Lane Keep Assist (assesment)
- Good
- Human Machine Interface (assesment)
- Good
- AEB Car-to-Car (points)
- 8.5 /6
- AEB Car-to-Car (assesment)
- Good
Airbags
Feature
Driver
Passenger
Rear
Frontal Airbag
Yes
Yes
-
Side Chest Airbag
Yes
Yes
Optional
Side Head Airbag
Yes
Yes
Yes
Side Pelvis Airbag
Yes
Yes
Optional
Knee Airbag
Yes
-
-
Curtain Airbag
Yes
Yes
Yes
Center Airbag
Yes
-
-
Airbag cut-off Switch
-
Yes
-
Child Protection
- Isofix
- Passenger: Yes
- Rear: Yes
Warranty
- Manufacturer
- 2 years
- Paintwork
- 3 years
- Rust Damage
- 12 years
- EV Battery
- 160,000 km / 8 years
Car Classification
- American Classification
- Mid-Size Car
- British Classification
- Large Family Car
- Australian Classification
- Medium Car
- European Segment
- D-Segment
- Car.info Classification
- Large Family Car
Similar wagons
Suggested vehicles
2025–2026
2025 Peugeot 2008
2023–2026
2023 Opel Astra Sports
2021–2025
2023 Peugeot 308 E-308 SW
2024–2026
2024 Subaru Levorg Layback
2023–2025
2023 Suzuki Swace
2022–2024
2022 MG 5
2024–2026
2024 BMW 5 Series
2022–2024
2022 Mini Clubman Cooper S Clubman
2022–2025
2022 BMW 3 Series
2021–2023
2021 Subaru Outback
2023–2026
2023 Mercedes-Benz CLA
2019–2023
