2006 GMC Savana H2500

United StatesGasolineAWDLCV

Specifications

Vehicle Details

Year
2006
Make
GMC
Model
Savana
Variant
H2500
Body Style
LCV
Generation
GMT610
Seats
1
Doors
4
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Electrohydraulic), 4-speed

Powertrain

Engine Name
H2500 Cargo Van Hydra-Matic
Engine Configuration
V
Power (hp)
299 hp
Power (kW)
220 kW
Torque
447 Nm (330 lb-ft)
Displacement
5,328 cc

Dimensions

Width
2,017 mm (79.4 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,200 rpm
Rev. at Max Torque
4,000 rpm
Redline
5,600 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
12.7 litres
Engine Fluids › Engine Coolant
OAT
GM OE DEX-COOL
Car Battery
Voltage
12 V
Battery Capacity
61 - 80 Ah
Cold Start Power
600 - 800 A
Alternator Charge Current
105 A
Alternator Voltage
12 V
Engine Configuration
Bore
96.01 mm (3.8 in)
Stroke
92 mm (3.6 in)
Compression Ratio
9.5 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
OHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
83,000 km (51,574 mi)
Spark Plug
166,000 km (103,148 mi)
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Transmission, Fluid
166,000 km (103,148 mi)
Transmission, Fluid Filter
166,000 km (103,148 mi)
Accessory Belt
240,000 km (149,129 mi)

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 4-speed
Gear Selector
Stalk
Gear Selector Location
Steering Column
Overdrive
Yes
Gear Ratio
1st Gear
3.06 :1
2nd Gear
1.63 :1
3rd Gear
1 :1
4th Gear
0.7 :1
Final Drive
3.73 :1
Reverse
2.29 :1

Brakes

Parking Brake
Manual
Pedal
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
305 mm (12.0 in)
Width
29 mm (1.1 in)
Rear Brakes
Diameter
330 mm (13.0 in)
Width
30 mm (1.2 in)

Suspensions

Spring, Front
Torsion
Spring, Rear
Leaf (Longitudinal Spring)
Anti-roll Bar
Yes
Suspension, Rear
Dependent
Beam Axle (Dead Axle)
Anti-roll Bar
Front
35 mm (1.4 in)

Fuel

General
Tank Volume
177 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption EPA
City
13 MPG
Highway
17 MPG
Combined
14 MPG

Dimensions & Weight

Exterior

Track, Front
1,721 mm (67.8 in)
Track, Rear
1,721 mm (67.8 in)
Overhang, Front
1,008 mm (39.7 in)
Ground Clearance
193 - 206 mm (7.6 - 8.1 in)

Interior

Head Room, Front
1,021 mm (40.2 in)
Leg Room, Front
1,049 mm (41.3 in)
Hip Room, Front
1,664 mm (65.5 in)
Shoulder Room, Front
1,748 mm (68.8 in)

Weight

Gross Weight
3,901 kg (8,600 lb)
Max Trailer Load, braked 12%
2,903 kg (6,400 lb)
Gross Train Weight
5,443 kg (12,000 lb)
Max Towbar Download
181 kg (399 lb)

LCV Specific

General
Version
  • L1H1
  • L2H1
Dimensions › Length
L1
5,692 mm (224.1 in)
L2
6,192 mm (243.8 in)
Dimensions › Height
L1H1
2,149 mm (84.6 in)
L2H1
2,141 mm (84.3 in)
Dimensions › Wheel Base
L1
3,429 mm (135.0 in)
L2
3,937 mm (155.0 in)
Dimensions › Turning Circle
L1
14.8 m
L2
16.6 m
Side Door › Side Door Height
H1
1,283 mm (50.5 in)
Side Door › Side Door Width
L1
1,120 mm (44.1 in)
L2
1,120 mm (44.1 in)
Side Door › Ground to Door Height
L1H1
511 mm (20.1 in)
L2H1
498 mm (19.6 in)
Rear Doors › Rear Doors Height
L1H1
1,255 mm (49.4 in)
Rear Doors
Rear Doors Width
1,448 mm (57.0 in)
Rear Doors › Sill Height
L1H1
704 mm (27.7 in)
L2H1
693 mm (27.3 in)
Cargo Space › Cargo Volume
L1H1
7,569 litres
L1H2
8,970 litres
Cargo Space › Depth
L1
3,246 mm (127.8 in)
L2
3,754 mm (147.8 in)
Cargo Space › Height
H1
1,318 mm (51.9 in)
Cargo Space › Space Width, Between Wheel Arches
L1
1,283 mm (50.5 in)

Exterior

Chassis & Body

Chassis
Chassis
LCV (Panel Van)
Pillars
A-D
Chassis Construction
Body-on-Frame (Ladder Frame)
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
  • Sliding Right
  • Dual Swing-out
Door Handles
Pull-up
Platform
General Motors Platforms
GMT Platform (GMT610)

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Manual
Heated
Optional
Turning Signal
Optional
House Colour
Black
Windscreen Wipers
Number of Wiper Speeds
2
Integrated Water Nozzles in Wipers
Yes
Intermittent Control
Yes
Windows
Heated Windows
Optional
Heat-Insulating Windows
  • Front
  • First Row
Tinted Windows
Optional
Rear Windows, Pop-out
Optional
Windows › Heated Windows
Rear
Optional
Windows › Heat-Insulating Windows
Second Row
Optional
Windows › Tinted Windows
Windscreen, upper part
Optional
Second Row
Optional
Rear Window
Optional
Windows › Rear Windows, Pop-out
Manual
Optional
Other Equipment
Antenna
Optional
Air Intakes
1-port
Number of Exhaust Pipes
1
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Daytime Running Light
Halogen

Colour

Bumper
Optional
Door Handles
Non-painted

Rims & Tires

Number of Bolts
8 pcs
Nut/Bolt Dimensions
M14x1.5
Fastening Type
Lug Nuts
Tightening Torque
190 Nm
Rim Material
Steel
Rim Type
Disc Wheel
Spare Wheel
Optional
Spare Wheel
Full-size
Optional
Spare Wheel › Full-size
Steel
Optional

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Voltmeter
Analogue
Oil Pressure
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Optional
Number of Vents, Front
5 pcs
Controls
Rotary Dials
Climate Control › Air Condition
Refrigerant
R134A
Refrigerant, Capacity
900 g
Connectivity
Radio
Optional
Connectivity › Radio
AM
Optional
FM
Optional
Connectivity › Media Format
CD
Optional
Cassette
Optional
Displays
Equalizer
Optional
Speakers
Total Number of Speakers
2 pcs
Rear-view Mirror
Compass
Optional
Oustide Temperature
Optional
Interior Storage › Storage Compartments
Door
  • Driver Side
  • Passenger Side
Total Number of Compartments
12 pcs
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
3
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Other Equipment › Make-up Mirror
Driver Side
Optional
Passenger Side
Optional
Make-up Light
Optional
Other Equipment
Dual Sun Visors
  • Driver
  • Passenger
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Power Steering
Hydraulic
Number of Spokes
4
Colour
Black
Steering Ratio
17.2 :1
Steering Mechanism
  • Rack and Pinion
  • Recirculating Ball
Power Steering
Tilt
Optional

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
2 - 4
Number of Driver Seat Adjustments, Powered
6
Number of Driver Seat Adjustments, Total
4 - 8
Number of Passenger Seat Adjustments, Manual
2 - 4
Number of Passenger Seat Adjustments, Powered
6
Number of Passenger Seat Adjustments, Total
4 - 8
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Armrest
  • Driver
  • Passenger
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Manual

Trunk

Hatch Opening Type
Two-parted Doors

Design

Interior Decor Material
Plastic
Transmission Knob Material
Plastic
Entry Guard Material
Plastic

Features

Comfort Features

Keyless Entry
Optional
Cruise Control
Optional
Speed Limiter
Yes
Parking Heater
Optional
Parking Heater
Engine Heater
Optional

Accessories

Tool Kit and Jack
Optional
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes

Other Features

Immobiliser
Yes
Central Locking
Optional
Reversing Alarm
Optional
Number of Remote Keys
2
Number of Standard Keys
2
Total Number of Keys
4
Central Locking
Remote
Optional

Airbags

Feature
Frontal Airbag
Airbag cut-off Switch

Other

Identification

VIN Location
Left Side Casing of Window
Yes
On-board Diagnostic, Port Location
Steering Wheel, Lower Left

Car Classification

American Classification
Cargo Van
British Classification
Van
Australian Classification
Van
European Segment
M-Segment
Car.info Classification
Cargo Van
