2007 Honda FR-V

Japan Diesel FWD Minivan

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2007
Make: Honda
Model: FR-V
Body Style: Minivan

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2007
Make: Honda
Model: FR-V
Body Style: Minivan

Generation

BE

Seats

6

Doors

5

Fuel

Diesel

Drivetrain

FWD

Transmission

Manual, 6-speed

Powertrain

Engine Name: 2.2 i-CTDi Manual
Engine Configuration: Inline
Power (hp): 140 hp
Power (kW): 103 kW
Torque: 340 Nm (251 lb-ft)
Top speed: 192 km/h (119 mph)
0–60 mph: 9.7 seconds (estimated)
0–100 km/h: 10.2 seconds
Displacement

Dimensions

Length: 4,285 mm (168.7 in)
Width: 1,810 mm (71.3 in)
Height: 1,610 mm (63.4 in)
Wheelbase: 2,680 mm (105.5 in)
Curb weight: 1,598 kg (3,523 lb)

Engine & Performance

Engine

Engine Specification

Rev. at Max Power: 4,000 rpm
Rev. at Max Torque: 2,000 rpm

Engine Fluids

Synthetic Oil (viscosity): 0W-30
Engine Oil, Volume: 5.9 litres

Engine Configuration

Similar minivans

Suggested vehicles

View all

2007 Brabus Sprinter

2,204 cc

Bore

85 mm (3.3 in)

Stroke

97.1 mm (3.8 in)

Compression Ratio

16.7 :1

Engine Configuration

Inline

Turbocharger

Yes

Synchronization

Timing Chain

Engine Mount

Transversally

Service Intervals

Air Filter: 40,000 km (24,855 mi)
Fuel Filter: 40,000 km / 2 years
Brake Fluid: 3 years
Oil Change & Engine Filter: 20,000 km / 1 years
Engine Coolant: 60,000 km / 3 years
Interior Filter: 30,000 km / 1 years

Brakes

Parking Brake: Electric
Front Brakes: Disc Brakes
Rear Brakes: Disc Brakes

Front Brakes

Cooling: Ventilated

Fuel

General

Tank Volume: 58 litres

Emission

Emission Standard: Euro 4

Fuel Consumption NEDC

City: 8 litres / 100 km
Highway: 5.3 litres / 100 km
Combined: 6.3 litres / 100 km

Emission NEDC

Dimensions & Weight

Exterior

Track, Front: 1,555 mm (61.2 in)
Track, Rear: 1,575 mm (62.0 in)
Turning Circle: 11.2 m
Ground Clearance: 150 mm (5.9 in)

Interior

Exterior

Chassis & Body

Chassis

Chassis: MPV

Equipment

Side Mirrors

Turning Signal: Yes

Windows

Window Lifts, Front: Powered

Interior

Equipment

Instrument Cluster

Trip Computer: Yes
Tachometer: Analogue

Instrument Cluster › Trip Computer

Display: Yes

Climate Control

Climate Control: Automatic

Features

Comfort Features

Cruise Control: Yes

Other Features

GPS: Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC): Yes

Brake Systems

Anti-lock Braking System (ABS): Yes
Traction Control System (TCS): Yes
Electronic Brake Assist (BA/EBA): Yes

Other

Identification

VIN Location

Engine Compartment, Bulkhead: Left
Centre
Left Side Casing of Window: Yes

Car Classification

American Classification: MPV
British Classification: Compact MPV

CO₂, Combined

167 g/km

Head Room, Front

1,020 mm (40.2 in)

Weight

Gross Weight: 2,130 kg (4,696 lb)
Max Trailer Load, braked 12%: 1,500 kg (3,307 lb)
Max Trailer Load, unbraked: 500 kg (1,102 lb)
Cargo Capacity: 532 kg (1,173 lb)
Max Roof Load: 55 kg (121 lb)
Max Towbar Download: 90 kg (198 lb)

Window Lifts, Rear

Powered

Tinted Windows

Optional

Windows › Tinted Windows

Second Row: Optional
Rear Window: Optional

Other Equipment

Sunroof: Optional
Roof Railing: Optional

Lights

Fog Lights: Optional

Rims & Tires

Number of Bolts: 5 pcs
Bolt Distance: 114.3
Nut/Bolt Dimensions: M12x1.5
Central Bore (CB), front: 64.1
Fastening Type: Lug Nuts

Air Condition

Yes

Connectivity

Radio: Yes

Connectivity › Media Format

CD: Yes
DVD: Optional

Displays

Center Display: Yes

Displays › Center Display

Touchscreen: Optional

Steering Wheel

Multifunction Steering Wheel: Yes

Trunk

Rear Trunk: Yes

Rear Trunk

Volume: 439 litres
Volume, Back Seat Collapsed: 1,600 litres

Seats

Front Seats

Heated Seats: Optional

Second Seat Row

Collapsible: Yes

Sensors

Rain Sensors: Optional

Other Features

Immobiliser: Yes
Anti-theft Alarm: Yes
Central Locking: Yes

Safety Testing

General

Test Year: 2005
Adult Occupant: 4/5 stars
Child Occupant: 3/5 stars
Pedestrian: 2/4 stars

Airbags

Feature

Driver

Passenger

Rear

Frontal Airbag

DriverYes

PassengerYes

Rear-

Side Chest Airbag

Seat Belt

Feature

Driver

Passenger

Rear

Seat Belt Reminder

DriverYes

PassengerYes

Rear-

Belt Pretensioner

Driver

Child Protection

Isofix: Passenger: Yes
Rear: Yes

Australian Classification

People Mover

European Segment

M-Segment

Car.info Classification

Medium MPV

Spare Parts BETA

Bulb Types

Low Beam: D2S (xenon)
H4
Main Beam: H4
Bi-Xenon: D2S
Fog Light, Front: H11
Fog Light, Rear: W3×16d (W21W)
Positioning-/Parking Lights, Front: W2.1×9.5d (W5W)
Rear/Brake Light: W3×16q (W21/5W)
Reversing Light

FR-V

8.9

€67,000

MSRP · EUR

Body

DriverYes

PassengerYes

Rear-

Yes

PassengerYes

Rear-

W3×16d (W21W)

Turn Indicators, Front

WX3×16d (WY21W)

Turn Indicators, Rear

WX3×16d (WY21W)

License Plate Light

W2.1×9.5d (W5W)

Minivan

Variant

FR-V Standard2005–2009

FR-V Minivan Generations1 of 2

Year

Powertrain

2.2 i-CTDi Manual

Horsepower

140 hp

Drivetrain

FWD

Fuel

Transmission

Manual, 6-speed
