2014 Mercedes-Benz V-Class Viano

GermanyGasolineRWDMinivan

Specifications

Vehicle Details

Year
2014
Make
Mercedes-Benz
Model
V-Class
Variant
Viano
Body Style
Minivan
Generation
W639 Facelift
Seats
6
Doors
5
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 5-speed

Powertrain

Engine Name
Viano 3.5 2.8t TouchShift
Engine Configuration
V
Power (hp)
258 hp
Power (kW)
190 kW
Torque
340 Nm (251 lb-ft)
Top speed
217 km/h (135 mph)
0–60 mph
8.3 seconds (estimated)
0–100 km/h
8.7 seconds
Displacement
3,498 cc

Dimensions

Length
4,763 mm (187.5 in)
Width
1,901 mm (74.8 in)
Height
1,872 mm (73.7 in)
Curb weight
2,040 kg (4,497 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,900 rpm
Rev. at Max Torque
2,500 - 5,000 rpm
Engine Configuration
Engine Configuration
V-Engine
Turbocharger
Yes

Transmission & Drivetrain

Transmission
Automatic, 5-speed

Brakes

Parking Brake
Manual
Pedal
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Anti-roll Bar
Front
Sports Suspension
Optional
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Yes

Fuel

General
Tank Volume
75 litres
Emission
Emission Standard
Euro 5
Emission Class
G
Fuel Consumption NEDC
City
16.3 - 16.5 litres / 100 km
Highway
9.3 - 9.5 litres / 100 km
Combined
11.9 - 12.1 litres / 100 km
Emission NEDC
CO₂, Combined
279 - 284 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,253 mm (88.7 in)
Ground Clearance
149 mm (5.9 in)

Weight

Gross Weight
2,800 kg (6,173 lb)
Max Trailer Load, braked 12%
2,000 kg (4,409 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
675 - 1,010 kg (1,488 - 2,227 lb)
Max Roof Load
150 kg (331 lb)
Max Towbar Download
100 kg (220 lb)

LCV Specific

Cargo Space › Cargo Volume
L1H1
430 litres
L2H1
730 litres
L3H1
970 litres

Exterior

Chassis & Body

Chassis
Chassis
MPV
Doors
Front Doors
Conventional
Rear Doors
Sliding (Left | Right)
Powered Opening/Closing
Optional
Door Handles
Pull-out

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
Mirror Shape, Driver side
Aspheric
Mirror Shape, Passenger side
Aspheric
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
One-touch up/down
  • Driver
  • Passenger
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Roof Railing
Optional
Antenna
Glass-integrated
Side Steps
Stationary

Lights

Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Front
Halogen
Rear
Halogen
Headlight Washers
Optional

Colour

Door Handles
Same as Car

Rims & Tires

Tightening Torque
180 Nm
Rim Material
Alloy
Rim Colour
Silver
Rim Type
Disc Wheel
Spare Wheel
Optional
Spare Wheel
Full-size
Optional
Temporary
Optional
Spare Wheel › Full-size
Steel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Digital
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
  • Buttons
  • Rotary Dials
Connectivity
Radio
  • AM
  • FM
Cellular Network
Optional
Connectivity › Media Format
CD
Optional
DVD
Optional
Connectivity › Media Inputs
AUX
Optional
Connectivity › Media Inputs › AUX
Front
Optional
Displays
Center Display
Optional
Displays › Center Display
Rotary Dial
Optional
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable (Manual)
Card Holder
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Guide Light
Optional
Ambient Light
Yes
Lights › Guide Light
Entry Guard
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
  • Front
  • Rear
Carpets
  • Front
  • Rear
Ashtray
Rear
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › Carpets
Material
Textile

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
4
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes

Design

Accent
Painted Inserts (Silver)
Entry Guard Material
Plastic
Pedals
Standard
Pedals
Stainless Steel
Optional
Sport
Optional

Seats

Front Seats › Adjustments, Driver
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
  • Driver
  • Passenger
Type of Seat
Comfort Seat (Driver | Passenger)
Front Seats › Heated Seats
Cushion
Optional
Second Seat Row
Armrest
Yes
Collapsible
Manual
Foldable Table
Yes
Adjustments
Backrest Angle
Number of Seats
2
Type of Seat
Adult
Second Seat Row › Headrests
Outer Seats
  • Height Adjustment
  • Tilt Adjustment
Third/Fourth Seat Row
Third Seat Row
Yes
Third/Fourth Seat Row › Third Seat Row
Collapsible
Yes
Number of Seats
2
Type of Seat
Adult
Seat Angle
Front Facing
Third/Fourth Seat Row › Third Seat Row › Collapsible
Fold Type
Manual

Features

Comfort Features

Cruise Control
Optional

Other Features

GPS
Optional
Start & Stop
Yes

Accessories

Tool Kit and Jack
Yes
Warning Triangle
Yes
First Aid Kit
Yes
Bicycle Holder
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Parking Assist
Optional

Brake Systems

Anti-lock Braking System (ABS)
Four-channel
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Yes
Rain Sensors
Yes
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Manual

Safety Testing

General
Test Year
2008
Adult Occupant
4/5 stars
Child Occupant
3/5 stars
Pedestrian
1/4 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Curtain Airbag

Other

Car Classification

American Classification
Passenger Van
British Classification
Minibus
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Passenger Van
