2018 Ford Flex

United StatesGasolineAWDCrossover

Photos

Specifications

Vehicle Details

Year
2018
Make
Ford
Model
Flex
Body Style
Crossover
Generation
1st Generation Facelift (D471)
Seats
6
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
3.5 V6 EcoBoost AWD SelectShift
Engine Configuration
V
Power (hp)
370 hp
Power (kW)
272 kW
Torque
475 Nm (350 lb-ft)
Displacement
3,496 cc

Dimensions

Length
5,120 mm (201.6 in)
Width
2,030 mm (79.9 in)
Height
1,720 mm (67.7 in)
Wheelbase
2,990 mm (117.7 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
3,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Bore
92.5 mm (3.6 in)
Stroke
86.7 mm (3.4 in)
Compression Ratio
10 :1
Engine Configuration
V-Engine
Turbocharger
Yes

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Brakes

Parking Brake
Electric

Fuel

General
Tank Volume
71 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 4
Fuel Consumption NEDC
City
14.7 litres / 100 km
Highway
10.2 litres / 100 km
Combined
13.1 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,660 mm (65.4 in)
Track, Rear
1,660 mm (65.4 in)
Turning Circle
12.4 m
Ground Clearance
130 mm (5.1 in)

Interior

Head Room, Front
1,062 mm (41.8 in)
Head Room, Rear
1,029 mm (40.5 in)
Head Room, Third Row
983 mm (38.7 in)
Leg Room, Front
1,082 mm (42.6 in)
Leg Room, Rear
1,125 mm (44.3 in)
Leg Room, Third Row
846 mm (33.3 in)
Hip Room, Front
1,410 mm (55.5 in)
Hip Room, Rear
1,410 mm (55.5 in)
Hip Room, Third Row
1,044 mm (41.1 in)
Shoulder Room, Front
1,483 mm (58.4 in)
Shoulder Room, Rear
1,476 mm (58.1 in)
Shoulder Room, Third Row
1,290 mm (50.8 in)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Ford Motor Company
D3 Platform (D4)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Normal Roof
Yes
Antenna
Optional

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
63.4
Fastening Type
Lug Nuts
Tightening Torque
135 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
App-Connect
  • Android Auto
  • Apple CarPlay
Displays
Center Display
Yes
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Other Equipment
12V Outlet
Front
Carpets
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
Tilt
Colour
Black
Steering Mechanism
Rack and Pinion
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
565 litres
Volume, Back Seat Collapsed
2,355 litres

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black
Transmission Knob Material
Plastic
Colour
Black

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Second Seat Row
Type of Seat
Adult
Third/Fourth Seat Row
Third Seat Row
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Safety Testing

General
Not Tested by Euro NCAP
Yes
IIHS
Test Year
2014
Small Overlap Front: Driver Side
Acceptable
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Basic
Latch Ease of Use
Acceptable

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment JD-Segment
Car.info Classification
Large SUV
