2019 Hyundai Santa Fe

South KoreaDiesel4WDSUV

Photos

Specifications

Vehicle Details

Year
2019
Make
Hyundai
Model
Santa Fe
Body Style
SUV
Generation
TM
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
4WD
Transmission
  • Automatic
  • Manual, 6
  • 8-speed

Powertrain

Engine Name
2.2 CRDi 4WD
Engine Configuration
Inline
Power (hp)
200 hp
Power (kW)
147 kW
Torque
440 Nm (325 lb-ft)
Top speed
205 km/h (127 mph)
0–60 mph
9.0 seconds (estimated)
0–100 km/h
9.4 seconds
Displacement
2,199 cc

Dimensions

Length
4,770 mm (187.8 in)
Width
1,890 mm (74.4 in)
Height
1,705 mm (67.1 in)
Wheelbase
2,765 mm (108.9 in)
Curb weight
1,925 kg (4,244 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
3,800 rpm
Rev. at Max Torque
1,750 - 2,750 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Oil, Volume
6.3 litres
Engine Configuration
Bore
85.4 mm (3.4 in)
Stroke
96 mm (3.8 in)
Compression Ratio
16 :1
Engine Configuration
Inline
Service Intervals
Air Filter
60,000 km / 4 years
Fuel Filter
60,000 km / 4 years
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
30,000 km / 2 years
Engine Coolant
30,000 km / 2 years
Interior Filter
30,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6
  • 8-speed

Fuel

General
Tank Volume
71 litres
Emission
Emission Standard
Euro 6d
Emission Class
B
WLTP Consumption
Combined (l/100km)
6.9 – 7.4 litres / 100 km
Fuel Consumption NEDC
City
7 – 7.5 litres / 100 km
Highway
5.4 – 5.6 litres / 100 km
Combined
6 – 6.3 litres / 100 km
Emission WLTP
CO₂, Combined
182 – 193 g/km
Emission NEDC
CO₂, Combined
158 – 165 g/km

Dimensions & Weight

Exterior

Track, Front
1,643 mm (64.7 in)
Track, Rear
1,652 mm (65.0 in)
Ground Clearance
185 mm (7.3 in)

Interior

Head Room, Front
1,046 mm (41.2 in)
Head Room, Rear
995 mm (39.2 in)
Leg Room, Front
1,120 mm (44.1 in)
Leg Room, Rear
1,040 mm (40.9 in)
Hip Room, Front
1,460 mm (57.5 in)
Hip Room, Rear
1,430 mm (56.3 in)
Shoulder Room, Front
1,500 mm (59.1 in)
Shoulder Room, Rear
1,480 mm (58.3 in)
Head Room (est.), Third Row
907 mm (35.7 in)
Leg Room (est.), Third Row
785 mm (30.9 in)

Weight

Gross Weight
2400 – 2407 kg (5,291 – 5,307 lb)
Max Trailer Load, braked 12%
2000 – 2500 kg (4,409 – 5,512 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
573 – 574 kg (1,263 – 1,265 lb)
Max Roof Load
100 kg (220 lb)
Max Towbar Download
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Rims & Tires

Tightening Torque
107 - 127 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
  • AM
  • FM
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
625 litres
Volume, Back Seat Collapsed
1,695 litres
Volume (third seat row)
547 litres
Volume (Opt. third seat row, Collapsed seat)
1,625 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Third/Fourth Seat Row
Third Seat Row
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Lane Assist System
Yes
Speed Assist
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Autonomous Emergency Brake System (AEB)
Pedestrian
Yes
Cyclist
Yes
City
Yes
Inter-urban
Yes

Safety Testing

General
Test Year
2018
Adult Occupant
94 %
Child Occupant
88 %
Vulnerable Road Users
67 %
Safety Assist
76 %
Overall
5/5 stars
Test Year
2018
ANCAP Safety Rating
5
Adult Occupant
Protection
94 %
Protection
35.9
Full Width
7.81
Frontal Offset
7.91
Side Impact
7.5
Pole
7.33
Whiplash Protection (Front)
1.25
Whiplash Protection (Rear)
0.09
AEB (City)
4
Child Occupant
Protection
89 %
Protection
42.2
Dynamic (Front)
15.15
Dynamic (Side)
8
Child Restraint Installation
12
On-Board Features
7
Pedestrian
Protection
67 %
Protection
32.2
Head Impact
15.1
Upper Leg Impact
4.96
Lower Leg Impact
5.34
AEB VRU (Pedestrian)
4.1
AEB VRU (Cyclist)
2.67
Safety Assist
Safety Assist
78 %
Safety Assist
10.1
Speed Assistance System
1.25
Seat Belt Reminders
2.9
Lane Support System
3.5
AEB (Interurban)
2.49
IIHS
Test Year
2019
Award
Top Safety Pick+
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: Yes
  • Rear: Yes

Other

Warranty

Manufacturer
5 years
Paintwork
5 years
Rust Damage
12 years

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Front of Hood
Yes

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment JD-Segment
Car.info Classification
Large SUV

Spare Parts BETA

Bulb Types
Low Beam
HB3
Main Beam
HB3
Fog Light, Front
H8
Fog Light, Rear
W2.1×9.5d (W16W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Category
Standard (S)

Tests

Autotest
Body/Trunk
2.3
Interior
2
Comfort
2.4
Motor/Drivetrain
2.2
Driving Characteristics
2.6
Environment/EcoTest
4.3
Security
1.9
Judgment Technology/Environment
2.7
Judgment Technology/Environment
Satisfactory
Judgment Car Cost
3.3
Judgment Car Cost
Satisfactory
